| General information | |
|---|---|
| Brand | Aion |
| Model | LX |
| Generation | LX |
| Type (Engine) | 93.3 kWh (408 Hp) 4WD |
| Start of production | October, 2019 year |
| End of production | January, 2022 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Weight-to-power ratio | 5.3 kg/Hp, 187.2 Hp/tonne |
| Weight-to-torque ratio | 3.1 kg/Nm, 321.1 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 93.3 kWh |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| Battery location | Below the floor |
| All-electric range (NEDC) | 600 km 372.82 mi |
| Average Energy consumption (NEDC) | 16-17.1 kWh/100 km
25.75 – 27.52 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 204 Hp |
| Electric motor Torque | 350 Nm
258.15 lb.-ft. |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 204 Hp |
| Electric motor Torque | 350 Nm
258.15 lb.-ft. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 408 Hp |
| System torque | 700 Nm 516.29 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2180 kg 4806.08 lbs. |
| Dimensions | |
| Length | 4786 mm 188.43 in. |
| Width | 1935 mm 76.18 in. |
| Height | 1685 mm 66.34 in. |
| Wheelbase | 2920 mm 114.96 in. |
| Ride height (ground clearance) | 150 mm 5.91 in. |
| Drag coefficient (Cd) | 0.288 |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/50 R20 |
| Wheel rims size | 20 |
| What is the body type, Aion LX? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 93.3 kWh (408 Hp) 4WD? | 600 km 372.82 mi |
| What is electricity consumption, Aion LX 93.3 kWh (408 Hp) 4WD? | 16-17.1 kWh/100 km 25.75 – 27.52 kWh/100 mi 131 – 122 MPGe 6.3 – 5.8 km/kWh 3.9 – 3.6 mi/kWh |
| How much power, Aion LX SUV 2019 93.3 kWh (408 Hp) 4WD? | 408 Hp, 700 Nm 516.29 lb.-ft. |
| What is the drivetrain, Aion LX SUV 2019 93.3 kWh (408 Hp) 4WD? | All wheel drive (4×4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| How long is this vehicle, 2019 Aion LX SUV? | 4786 mm 188.43 in. |
| How wide is the vehicle, 2019 Aion LX SUV? | 1935 mm 76.18 in. |
| What is the curb weight, 2019 Aion LX 93.3 kWh (408 Hp) 4WD? | 2180 kg 4806.08 lbs. |
| How many gears, What type is the gearbox, 2019 Aion LX 93.3 kWh (408 Hp) 4WD? | 1, automatic transmission |
