| General information | |
|---|---|
| Brand | Aion |
| Model | S |
| Generation | S |
| Type (Engine) | 48.4 kWh (204 Hp) |
| Start of production | August, 2019 year |
| End of production | July, 2020 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Electricity |
| Weight-to-power ratio | 7.7 kg/Hp, 129.5 Hp/tonne |
| Weight-to-torque ratio | 5.3 kg/Nm, 190.5 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 48.4 kWh |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| Battery location | Below the floor |
| All-electric range (NEDC) | 410 km 254.76 mi |
| Average Energy consumption (NEDC) | 12.9 kWh/100 km
20.76 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 204 Hp |
| Electric motor Torque | 300 Nm
221.27 lb.-ft. |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 204 Hp |
| System torque | 300 Nm 221.27 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1575 kg 3472.28 lbs. |
| Trunk (boot) space – minimum | 453 l 16 cu. ft. |
| Dimensions | |
| Length | 4768 mm 187.72 in. |
| Width | 1880 mm 74.02 in. |
| Height | 1530 mm 60.24 in. |
| Wheelbase | 2750 mm 108.27 in. |
| Front track | 1600 mm 62.99 in. |
| Rear (Back) track | 1602 mm 63.07 in. |
| Ride height (ground clearance) | 125 mm 4.92 in. |
| Drag coefficient (Cd) | 0.245 |
| Minimum turning circle (turning diameter) | 11.3 m 37.07 ft. |
| Approach angle | 13° |
| Departure angle | 14° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring, Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/45 R18 |
| Wheel rims size | 18 |
| What is the body type, Aion S? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 48.4 kWh (204 Hp)? | 410 km 254.76 mi |
| What is electricity consumption, Aion S 48.4 kWh (204 Hp)? | 12.9 kWh/100 km 20.76 kWh/100 mi 162 MPGe 7.8 km/kWh 4.8 mi/kWh |
| How much power, Aion S Sedan 2019 48.4 kWh (204 Hp)? | 204 Hp, 300 Nm 221.27 lb.-ft. |
| What is the drivetrain, Aion S Sedan 2019 48.4 kWh (204 Hp)? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2019 Aion S Sedan? | 4768 mm 187.72 in. |
| How wide is the vehicle, 2019 Aion S Sedan? | 1880 mm 74.02 in. |
| What is the curb weight, 2019 Aion S 48.4 kWh (204 Hp)? | 1575 kg 3472.28 lbs. |
| How much trunk (boot) space, 2019 Aion S Sedan? | 453 l 16 cu. ft. |
| How many gears, What type is the gearbox, 2019 Aion S 48.4 kWh (204 Hp)? | 1, automatic transmission |
