| General information | |
|---|---|
| Brand | Aion |
| Model | V |
| Generation | V Plus |
| Type (Engine) | 80 kWh (245 Hp) |
| Start of production | June, 2023 year |
| End of production | 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 7.6 sec |
| Acceleration 0 – 62 mph | 7.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.2 sec |
| Maximum speed | 185 km/h 114.95 mph |
| Weight-to-power ratio | 7.7 kg/Hp, 129.6 Hp/tonne |
| Weight-to-torque ratio | 6.1 kg/Nm, 163.5 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 80 kWh |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| Battery location | Below the floor |
| All-electric range (NEDC) | 600 km 372.82 mi |
| Average Energy consumption (NEDC) | 14.8 kWh/100 km
23.82 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 245 Hp |
| Electric motor Torque | 309 Nm
227.91 lb.-ft. |
| Electric motor model/code | TZ190XY105 |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 245 Hp |
| System torque | 309 Nm 227.91 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1890 kg 4166.74 lbs. |
| Max. weight | 2420 kg 5335.19 lbs. |
| Max load | 530 kg 1168.45 lbs. |
| Trunk (boot) space – minimum | 405 l 14.3 cu. ft. |
| Trunk (boot) space – maximum | 1563 l 55.2 cu. ft. |
| Dimensions | |
| Length | 4650 mm 183.07 in. |
| Width | 1920 mm 75.59 in. |
| Height | 1720 mm 67.72 in. |
| Wheelbase | 2830 mm 111.42 in. |
| Front track | 1630 mm 64.17 in. |
| Rear (Back) track | 1645 mm 64.76 in. |
| Ride height (ground clearance) | 160 mm 6.3 in. |
| Drag coefficient (Cd) | 0.321 |
| Minimum turning circle (turning diameter) | 12 m 39.37 ft. |
| Approach angle | 18° |
| Departure angle | 22° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 255/45 R20 |
| Wheel rims size | 20 |
| What is the body type, Aion V Plus? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 80 kWh (245 Hp)? | 600 km 372.82 mi |
| What is electricity consumption, Aion V Plus 80 kWh (245 Hp)? | 14.8 kWh/100 km 23.82 kWh/100 mi 141 MPGe 6.8 km/kWh 4.2 mi/kWh |
| How fast is the car, 2023 V Plus 80 kWh (245 Hp)? | 185 km/h | 114.95 mph 0-100 km/h: 7.6 sec 0-60 mph: 7.2 sec |
| How much power, Aion V SUV 2023 80 kWh (245 Hp)? | 245 Hp, 309 Nm 227.91 lb.-ft. |
| What is the drivetrain, Aion V Plus SUV 2023 80 kWh (245 Hp)? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2023 Aion V SUV? | 4650 mm 183.07 in. |
| How wide is the vehicle, 2023 Aion V SUV? | 1920 mm 75.59 in. |
| What is the curb weight, 2023 Aion V Plus 80 kWh (245 Hp)? | 1890 kg 4166.74 lbs. |
| What is the gross weight, 2023 Aion V Plus 80 kWh (245 Hp)? | 2420 kg 5335.19 lbs. |
| How much trunk (boot) space, 2023 Aion V SUV? | 405 – 1563 l 14.3 – 55.2 cu. ft. |
| How many gears, What type is the gearbox, 2023 Aion V Plus 80 kWh (245 Hp)? | 1, automatic transmission |
