| General information | |
|---|---|
| Brand | Aion |
| Model | Y |
| Generation | Y Plus |
| Type (Engine) | 63.2 kWh (136 Hp) |
| Start of production | April, 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 9.8 sec |
| Acceleration 0 – 62 mph | 9.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.3 sec |
| Maximum speed | 150 km/h 93.21 mph |
| Electric cars and hybrids specs | |
| Gross battery capacity | 63.2 kWh |
| Battery voltage | 374.4 V |
| Battery technology | Lithium iron phosphate (LiFePO4) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 430 km 267.19 mi |
| Average Energy consumption (WLTP) | 16.7 kWh/100 km
26.88 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 136 Hp |
| Electric motor Torque | 225 Nm
165.95 lb.-ft. |
| Electric motor model/code | TZ184XYA2002 |
| Maximum revolutions of the electric motor | 14000 rpm. |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 136 Hp |
| System torque | 225 Nm 165.95 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Max. weight | 2180 kg 4806.08 lbs. |
| Trunk (boot) space – minimum | 405 l 14.3 cu. ft. |
| Trunk (boot) space – maximum | 1200 l 42.38 cu. ft. |
| Dimensions | |
| Length | 4535 mm 178.54 in. |
| Width | 1870 mm 73.62 in. |
| Height | 1650 mm 64.96 in. |
| Wheelbase | 2750 mm 108.27 in. |
| Front track | 1600 mm 62.99 in. |
| Rear (Back) track | 1600 mm 62.99 in. |
| Front overhang | 898 mm 35.35 in. |
| Rear overhang | 887 mm 34.92 in. |
| Ride height (ground clearance) | 150 mm 5.91 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Approach angle | 18° |
| Departure angle | 27° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring, Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/55 R17 |
| Wheel rims size | 17 |
| What is the body type, Aion Y Plus? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 63.2 kWh (136 Hp)? | 430 km 267.19 mi |
| What is electricity consumption, Aion Y Plus 63.2 kWh (136 Hp)? | 16.7 kWh/100 km 26.88 kWh/100 mi 125 MPGe 6 km/kWh 3.7 mi/kWh |
| How fast is the car, 2024 Y Plus 63.2 kWh (136 Hp)? | 150 km/h | 93.21 mph 0-100 km/h: 9.8 sec 0-60 mph: 9.3 sec |
| How much power, Aion Y SUV 2024 63.2 kWh (136 Hp)? | 136 Hp, 225 Nm 165.95 lb.-ft. |
| What is the drivetrain, Aion Y Plus SUV 2024 63.2 kWh (136 Hp)? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2024 Aion Y SUV? | 4535 mm 178.54 in. |
| How wide is the vehicle, 2024 Aion Y SUV? | 1870 mm 73.62 in. |
| What is the gross weight, 2024 Aion Y Plus 63.2 kWh (136 Hp)? | 2180 kg 4806.08 lbs. |
| How much trunk (boot) space, 2024 Aion Y SUV? | 405 – 1200 l 14.3 – 42.38 cu. ft. |
| How many gears, What type is the gearbox, 2024 Aion Y Plus 63.2 kWh (136 Hp)? | 1, automatic transmission |
