| General information | |
|---|---|
| Brand | Alfa Romeo |
| Model | 159 |
| Generation | 159 Sportwagon |
| Type (Engine) | 2.0 JTDM (136 Hp) |
| Start of production | 2010 year |
| End of production | 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 6.8 l/100 km 34.6 US mpg 41.5 UK mpg 14.7 km/l |
| Fuel consumption (economy) – extra urban | 4.3 l/100 km 54.7 US mpg 65.7 UK mpg 23.3 km/l |
| Fuel consumption (economy) – combined | 5.2 l/100 km 45.2 US mpg 54.3 UK mpg 19.2 km/l |
| CO2 emissions | 137 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 10.1 sec |
| Acceleration 0 – 62 mph | 10.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.6 sec |
| Maximum speed | 200 km/h 124.27 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 11.3 kg/Hp, 88.3 Hp/tonne |
| Weight-to-torque ratio | 4.4 kg/Nm, 227.3 Nm/tonne |
| Engine specs | |
| Power | 136 Hp @ 4000 rpm. |
| Power per litre | 69.5 Hp/l |
| Torque | 350 Nm @ 1750 rpm. 258.15 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 939 B4.000 |
| Engine displacement | 1956 cm3 119.36 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 83 mm 3.27 in. |
| Piston Stroke | 90.4 mm 3.56 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.6 l 4.86 US qt | 4.05 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.1 l 6.45 US qt | 5.37 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1540 kg 3395.12 lbs. |
| Max. weight | 2090 kg 4607.66 lbs. |
| Max load | 550 kg 1212.54 lbs. |
| Trunk (boot) space – minimum | 445 l 15.72 cu. ft. |
| Trunk (boot) space – maximum | 1235 l 43.61 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| Max. roof load | 80 kg 176.37 lbs. |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Permitted towbar download | 60 kg 132.28 lbs. |
| Dimensions | |
| Length | 4660 mm 183.46 in. |
| Width | 1828 mm 71.97 in. |
| Height | 1417-1422 mm 55.79 – 55.98 in. |
| Wheelbase | 2700 mm 106.3 in. |
| Front track | 1578 mm 62.13 in. |
| Rear (Back) track | 1555 mm 61.22 in. |
| Front overhang | 1000 mm 39.37 in. |
| Rear overhang | 960 mm 37.8 in. |
| Minimum turning circle (turning diameter) | 11.1 m 36.42 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent multi-link suspension |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs, 305×28 mm |
| Rear brakes | Disc, 278×12 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Power steering | Hydraulic Steering |
| Tires size | 205/55 R 16 |
| Wheel rims size | 7 J x 16 |
| What is the body type, Alfa Romeo 159 Sportwagon? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Alfa Romeo 159 Sportwagon 2.0 JTDM (136 Hp)? | 5.2 l/100 km 45.2 US mpg 54.3 UK mpg 19.2 km/l |
| How ECO is the car, Alfa Romeo 159 2.0 JTDM (136 Hp)? | 137 g/km CO2 Euro 5 |
| How fast is the car, 2010 159 Sportwagon 2.0 JTDM (136 Hp)? | 200 km/h | 124.27 mph 0-100 km/h: 10.1 sec 0-60 mph: 9.6 sec |
| How much power, Alfa Romeo 159 Station wagon (estate) 2010 2.0 JTDM (136 Hp)? | 136 Hp, 350 Nm 258.15 lb.-ft. |
| What is the engine size, Alfa Romeo 159 Station wagon (estate) 2010 2.0 JTDM (136 Hp)? | 2.0 l 1956 cm3 119.36 cu. in. |
| How many cylinders, 2010 Alfa Romeo 2.0 JTDM (136 Hp)? | 4, Inline |
| What is the drivetrain, Alfa Romeo 159 Sportwagon Station wagon (estate) 2010 2.0 JTDM (136 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2010 Alfa Romeo 159 Station wagon (estate)? | 4660 mm 183.46 in. |
| How wide is the vehicle, 2010 Alfa Romeo 159 Station wagon (estate)? | 1828 mm 71.97 in. |
| What is the curb weight, 2010 Alfa Romeo 159 Sportwagon 2.0 JTDM (136 Hp)? | 1540 kg 3395.12 lbs. |
| What is the gross weight, 2010 Alfa Romeo 159 Sportwagon 2.0 JTDM (136 Hp)? | 2090 kg 4607.66 lbs. |
| How much trunk (boot) space, 2010 Alfa Romeo 159 Station wagon (estate)? | 445 – 1235 l 15.72 – 43.61 cu. ft. |
| How many gears, What type is the gearbox, 2010 Alfa Romeo 159 Sportwagon 2.0 JTDM (136 Hp)? | 6, manual transmission |
