| General information | |
|---|---|
| Brand | Aston Martin |
| Model | DB9 |
| Generation | DB9 Volante (facelift 2012) |
| Type (Engine) | 6.0 V12 (517 Hp) Automatic |
| Start of production | 2012 year |
| End of production | 2015 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption (economy) – urban | 21.6 l/100 km 10.9 US mpg 13.1 UK mpg 4.6 km/l |
| Fuel consumption (economy) – extra urban | 10 l/100 km 23.5 US mpg 28.2 UK mpg 10 km/l |
| Fuel consumption (economy) – combined | 14.3 l/100 km 16.4 US mpg 19.8 UK mpg 7 km/l |
| CO2 emissions | 333 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 4.6 sec |
| Acceleration 0 – 62 mph | 4.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 4.4 sec |
| Maximum speed | 295 km/h 183.3 mph |
| Weight-to-power ratio | 3.7 kg/Hp, 273.5 Hp/tonne |
| Weight-to-torque ratio | 3 kg/Nm, 328 Nm/tonne |
| Engine specs | |
| Power | 517 Hp @ 6500 rpm. |
| Power per litre | 87.1 Hp/l |
| Torque | 620 Nm @ 5500 rpm. 457.29 lb.-ft. @ 5500 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | AM11 |
| Engine displacement | 5935 cm3 362.18 cu. in. |
| Number of cylinders | 12 |
| Engine configuration | V-engine |
| Number of valves per cylinder | 4 |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 11 l 11.62 US qt | 9.68 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 15 l 15.85 US qt | 13.2 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1890 kg 4166.74 lbs. |
| Fuel tank capacity | 78 l 20.61 US gal | 17.16 UK gal |
| Dimensions | |
| Length | 4720 mm 185.83 in. |
| Width including mirrors | 2061 mm 81.14 in. |
| Height | 1282 mm 50.47 in. |
| Wheelbase | 2740 mm 107.87 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/35 ZR20; 295/30 ZR20 |
| Wheel rims size | 8.5J x 20; 11J x 20 |
| What is the body type, Aston Martin DB9 Volante (facelift 2012)? | Cabriolet, 2 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Aston Martin DB9 Volante (facelift 2012) 6.0 V12 (517 Hp) Automatic? | 14.3 l/100 km 16.4 US mpg 19.8 UK mpg 7 km/l |
| How ECO is the car, Aston Martin DB9 6.0 V12 (517 Hp) Automatic? | 333 g/km CO2 |
| How fast is the car, 2012 DB9 Volante (facelift 2012) 6.0 V12 (517 Hp) Automatic? | 295 km/h | 183.3 mph 0-100 km/h: 4.6 sec 0-60 mph: 4.4 sec |
| How much power, Aston Martin DB9 Cabriolet 2012 6.0 V12 (517 Hp) Automatic? | 517 Hp, 620 Nm 457.29 lb.-ft. |
| What is the engine size, Aston Martin DB9 Cabriolet 2012 6.0 V12 (517 Hp) Automatic? | 5.9 l 5935 cm3 362.18 cu. in. |
| How many cylinders, 2012 Aston Martin 6.0 V12 (517 Hp) Automatic? | 12, V-engine |
| What is the drivetrain, Aston Martin DB9 Volante (facelift 2012) Cabriolet 2012 6.0 V12 (517 Hp) Automatic? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2012 Aston Martin DB9 Cabriolet? | 4720 mm 185.83 in. |
| How wide is the vehicle, 2012 Aston Martin DB9 Cabriolet? | 2061 mm 81.14 in. |
| What is the curb weight, 2012 Aston Martin DB9 Volante (facelift 2012) 6.0 V12 (517 Hp) Automatic? | 1890 kg 4166.74 lbs. |
| How many gears, What type is the gearbox, 2012 Aston Martin DB9 Volante (facelift 2012) 6.0 V12 (517 Hp) Automatic? | 6, automatic transmission |
