| General information | |
|---|---|
| Brand | Audi |
| Model | A6 |
| Generation | A6 (4F,C6 facelift 2008) |
| Type (Engine) | 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF |
| Start of production | September, 2008 year |
| End of production | August, 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban | 9.4 l/100 km 25 US mpg 30.1 UK mpg 10.6 km/l |
| Fuel consumption (economy) – extra urban | 5.8 l/100 km 40.6 US mpg 48.7 UK mpg 17.2 km/l |
| Fuel consumption (economy) – combined | 7.1 l/100 km 33.1 US mpg 39.8 UK mpg 14.1 km/l |
| CO2 emissions | 189 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 8.2 sec |
| Acceleration 0 – 62 mph | 8.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.8 sec |
| Maximum speed | 230 km/h 142.92 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 9.3 kg/Hp, 107.6 Hp/tonne |
| Weight-to-torque ratio | 4.4 kg/Nm, 226.6 Nm/tonne |
| Engine specs | |
| Power | 190 Hp @ 3500 rpm. |
| Power per litre | 70.4 Hp/l |
| Torque | 400 Nm @ 1750 rpm. 295.02 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | CANA, CANC |
| Engine displacement | 2698 cm3 164.64 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 83 mm 3.27 in. |
| Piston Stroke | 83.1 mm 3.27 in. |
| Compression ratio | 16.8:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 8.2 l 8.66 US qt | 7.21 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1765 kg 3891.16 lbs. |
| Max. weight | 2345 kg 5169.84 lbs. |
| Max load | 580 kg 1278.68 lbs. |
| Trunk (boot) space – maximum | 546 l 19.28 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (8%) | 2100 kg 4629.71 lbs. |
| Permitted trailer load with brakes (12%) | 1900 kg 4188.78 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 85 kg 187.39 lbs. |
| Dimensions | |
| Length | 4927 mm 193.98 in. |
| Width | 1855 mm 73.03 in. |
| Width including mirrors | 2030 mm 79.92 in. |
| Height | 1459 mm 57.44 in. |
| Wheelbase | 2843 mm 111.93 in. |
| Front track | 1612 mm 63.46 in. |
| Rear (Back) track | 1618 mm 63.7 in. |
| Front overhang | 994 mm 39.13 in. |
| Rear overhang | 1090 mm 42.91 in. |
| Drag coefficient (Cd) | 0.29 |
| Minimum turning circle (turning diameter) | 11.9 m 39.04 ft. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 6 gears, automatic transmission Tiptronic |
| Front suspension | Independent multi-link suspension |
| Rear suspension | Independent on trapezoidal lever |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 205/60 R16 |
| Wheel rims size | 7J x 16 |
| What is the body type, Audi A6 (4F,C6 facelift 2008)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Audi A6 (4F,C6 facelift 2008) 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 7.1 l/100 km 33.1 US mpg 39.8 UK mpg 14.1 km/l |
| How ECO is the car, Audi A6 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 189 g/km CO2 Euro 5 |
| How fast is the car, 2008 A6 (4F,C6 facelift 2008) 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 230 km/h | 142.92 mph 0-100 km/h: 8.2 sec 0-60 mph: 7.8 sec |
| How much power, Audi A6 Sedan 2008 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 190 Hp, 400 Nm 295.02 lb.-ft. |
| What is the engine size, Audi A6 Sedan 2008 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 2.7 l 2698 cm3 164.64 cu. in. |
| How many cylinders, 2008 Audi 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 6, V-engine |
| What is the drivetrain, Audi A6 (4F,C6 facelift 2008) Sedan 2008 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | All wheel drive (4×4). Internal Combustion engine. |
| How long is this vehicle, 2008 Audi A6 Sedan? | 4927 mm 193.98 in. |
| How wide is the vehicle, 2008 Audi A6 Sedan? | 1855 mm 73.03 in. |
| What is the curb weight, 2008 Audi A6 (4F,C6 facelift 2008) 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 1765 kg 3891.16 lbs. |
| What is the gross weight, 2008 Audi A6 (4F,C6 facelift 2008) 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 2345 kg 5169.84 lbs. |
| How much trunk (boot) space, 2008 Audi A6 Sedan? | 546 l 19.28 cu. ft. |
| How many gears, What type is the gearbox, 2008 Audi A6 (4F,C6 facelift 2008) 2.7 TDI V6 (190 Hp) quattro Tiptronic DPF? | 6, automatic transmission Tiptronic |
