| General information | |
|---|---|
| Brand | Audi |
| Model | Fox |
| Generation | Fox (B1) |
| Type (Engine) | 1.5 (75 Hp) |
| Start of production | 1973 year |
| End of production | 1979 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Engine specs | |
| Power | 75 Hp @ 6000 rpm. |
| Power per litre | 51 Hp/l |
| Engine layout | Front, Longitudinal |
| Engine displacement | 1471 cm3 89.77 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 76.5 mm 3.01 in. |
| Piston Stroke | 80 mm 3.15 in. |
| Compression ratio | 8.2:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 2.8 l 2.96 US qt | 2.46 UK qt |
| Coolant | 6.2 l 6.55 US qt | 5.46 UK qt |
|
|
|
| Space, Volume and weights | |
| Trunk (boot) space – minimum | 439 l 15.5 cu. ft. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Dimensions | |
| Length | 4369 mm 172.01 in. |
| Width | 1643 mm 64.69 in. |
| Height | 1361 mm 53.58 in. |
| Wheelbase | 2469 mm 97.2 in. |
| Front track | 1339 mm 52.72 in. |
| Rear (Back) track | 1334 mm 52.52 in. |
| Minimum turning circle (turning diameter) | 9.8 m 32.15 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Trailing arm, Torsion |
| Front brakes | Disc, 238.76 mm |
| Rear brakes | Drum, 199.39 mm |
| Steering type | Steering rack and pinion |
| Wheel rims size | 5J x 13 |
| What is the body type, Audi Fox (B1)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| How much power, Audi Fox Sedan 1973 1.5 (75 Hp)? | 75 Hp |
| What is the engine size, Audi Fox Sedan 1973 1.5 (75 Hp)? | 1.5 l 1471 cm3 89.77 cu. in. |
| How many cylinders, 1973 Audi 1.5 (75 Hp)? | 4, Inline |
| What is the drivetrain, Audi Fox (B1) Sedan 1973 1.5 (75 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 1973 Audi Fox Sedan? | 4369 mm 172.01 in. |
| How wide is the vehicle, 1973 Audi Fox Sedan? | 1643 mm 64.69 in. |
| How much trunk (boot) space, 1973 Audi Fox Sedan? | 439 l 15.5 cu. ft. |
| How many gears, What type is the gearbox, 1973 Audi Fox (B1) 1.5 (75 Hp)? | 4, manual transmission |
