| General information | |
|---|---|
| Brand | Audi |
| Model | Q5 |
| Generation | Q5 II Sportback (FY, facelift 2020) |
| Type (Engine) | 35 TDI (163 Hp) Mild Hybrid S tronic |
| Start of production | 2021 year |
| End of production | November, 2024 year |
| Powertrain Architecture | MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 5.6-6.2 l/100 km 42 – 37.9 US mpg 50.4 – 45.6 UK mpg 17.9 – 16.1 km/l |
| CO2 emissions (WLTP) | 147-162 g/km |
| Fuel consumption (economy) – urban (NEDC, WLTP equivalent) | 5.4-5.5 l/100 km 43.6 – 42.8 US mpg 52.3 – 51.4 UK mpg 18.5 – 18.2 km/l |
| Fuel consumption (economy) – extra urban (NEDC, WLTP equivalent) | 4.3-4.4 l/100 km 54.7 – 53.5 US mpg 65.7 – 64.2 UK mpg 23.3 – 22.7 km/l |
| Fuel consumption (economy) – combined (NEDC, WLTP equivalent) | 4.7-4.8 l/100 km 50 – 49 US mpg 60.1 – 58.9 UK mpg 21.3 – 20.8 km/l |
| CO2 emissions (NEDC, WLTP equivalent) | 123-126 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 9 sec |
| Acceleration 0 – 62 mph | 9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 8.6 sec |
| Maximum speed | 213 km/h 132.35 mph |
| Emission standard | Euro 6d-ISC-FCM |
| Weight-to-power ratio | 10.8 kg/Hp, 92.9 Hp/tonne |
| Weight-to-torque ratio | 4.7 kg/Nm, 210.8 Nm/tonne |
| Electric cars and hybrids specs | |
| Battery voltage | 12 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Electric motor 1 | |
| Electric motor power | 3 Hp |
| Electric motor Torque | 60 Nm
44.25 lb.-ft. |
| Electric motor location | Front, Longitudinal |
| Internal combustion engine specs | |
| Power | 163 Hp @ 3250-4200 rpm. |
| Power per litre | 82.8 Hp/l |
| Torque | 370 Nm @ 1500-3000 rpm. 272.9 lb.-ft. @ 1500-3000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | EA288 evo / DEZE, DTNA |
| Engine displacement | 1968 cm3 120.09 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 16:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.5 l 5.81 US qt | 4.84 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11.5 l 12.15 US qt | 10.12 UK qt |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1755 kg 3869.11 lbs. |
| Max. weight | 2405 kg 5302.12 lbs. |
| Max load | 650 kg 1433 lbs. |
| Trunk (boot) space – minimum | 510 l 18.01 cu. ft. |
| Trunk (boot) space – maximum | 1480 l 52.27 cu. ft. |
| Fuel tank capacity | 65 l 17.17 US gal | 14.3 UK gal |
| AdBlue tank | 12 l 3.17 US gal | 2.64 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4689 mm 184.61 in. |
| Width | 1893 mm 74.53 in. |
| Width including mirrors | 2140 mm 84.25 in. |
| Height | 1635 mm 64.37 in. |
| Wheelbase | 2819 mm 110.98 in. |
| Front track | 1616-1623 mm 63.62 – 63.9 in. |
| Rear (Back) track | 1609-1611 mm 63.35 – 63.43 in. |
| Front overhang | 910 mm 35.83 in. |
| Rear overhang | 960 mm 37.8 in. |
| Drag coefficient (Cd) | 0.31 |
| Minimum turning circle (turning diameter) | 11.8 m 38.71 ft. |
| Approach angle | 16° |
| Departure angle | 19.3° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission S tronic |
| Front suspension | Coil spring, Independent multi-link suspension, Transverse stabilizer |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 338 mm |
| Rear brakes | Ventilated discs, 330 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/65 R17; 235/60 R18; 235/55 R19; 255/45 R20 |
| Wheel rims size | 8J x 17; 8J x 18; 8J x 19; 8J x 20 |
| What is the body type, Audi Q5 II Sportback (FY, facelift 2020)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Audi Q5 II Sportback (FY, facelift 2020) 35 TDI (163 Hp) Mild Hybrid S tronic? | 5.6-6.2 l/100 km 42 – 37.9 US mpg 50.4 – 45.6 UK mpg 17.9 – 16.1 km/l |
| How ECO is the car, Audi Q5 35 TDI (163 Hp) Mild Hybrid S tronic? | 147-162 g/km CO2 Euro 6d-ISC-FCM |
| How fast is the car, 2021 Q5 II Sportback (FY, facelift 2020) 35 TDI (163 Hp) Mild Hybrid S tronic? | 213 km/h | 132.35 mph 0-100 km/h: 9 sec 0-60 mph: 8.6 sec |
| How much power, Audi Q5 SUV 2021 35 TDI (163 Hp) Mild Hybrid S tronic? | 163 Hp, 370 Nm 272.9 lb.-ft. |
| What is the engine size, Audi Q5 SUV 2021 35 TDI (163 Hp) Mild Hybrid S tronic? | 2.0 l 1968 cm3 120.09 cu. in. |
| How many cylinders, 2021 Audi 35 TDI (163 Hp) Mild Hybrid S tronic? | 4, Inline |
| What is the drivetrain, Audi Q5 II Sportback (FY, facelift 2020) SUV 2021 35 TDI (163 Hp) Mild Hybrid S tronic? | Front wheel drive. MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode. |
| How long is this vehicle, 2021 Audi Q5 SUV? | 4689 mm 184.61 in. |
| How wide is the vehicle, 2021 Audi Q5 SUV? | 1893 mm 74.53 in. |
| What is the curb weight, 2021 Audi Q5 II Sportback (FY, facelift 2020) 35 TDI (163 Hp) Mild Hybrid S tronic? | 1755 kg 3869.11 lbs. |
| What is the gross weight, 2021 Audi Q5 II Sportback (FY, facelift 2020) 35 TDI (163 Hp) Mild Hybrid S tronic? | 2405 kg 5302.12 lbs. |
| How much trunk (boot) space, 2021 Audi Q5 SUV? | 510 – 1480 l 18.01 – 52.27 cu. ft. |
| How many gears, What type is the gearbox, 2021 Audi Q5 II Sportback (FY, facelift 2020) 35 TDI (163 Hp) Mild Hybrid S tronic? | 7, automatic transmission S tronic |
