2010-2012 Audi S3 Sportback (8PA) 2.0 TFSI (256 Hp) quattro

The Audi S3 Sportback (8PA) 2.0 TFSI quattro, produced between 2010 and 2012, represents a compelling blend of performance and practicality within the Audi A3 Sportback range. Positioned as the high-performance variant, it capitalized on the popularity of the 8PA platform – a generation known for its refined handling and upscale interior. This specific iteration, equipped with the 2.0-liter turbocharged four-cylinder engine producing 256 horsepower and paired with Audi’s quattro all-wheel-drive system, aimed to deliver a sporty driving experience without sacrificing the everyday usability expected of a compact hatchback. It served as a direct competitor to models like the BMW 135i and the Mercedes-Benz A250, appealing to enthusiasts seeking a premium, performance-oriented vehicle.

Technical Specifications

Brand Audi
Model S3
Generation S3 Sportback (8PA)
Type (Engine) 2.0 TFSI (256 Hp) quattro
Start of production 2010
End of production 2012
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Fuel consumption (economy) – urban 11.8 l/100 km (19.9 US mpg, 23.9 UK mpg, 8.5 km/l)
Fuel consumption (economy) – extra urban 6.7 l/100 km (35.1 US mpg, 42.2 UK mpg, 14.9 km/l)
Fuel consumption (economy) – combined 8.5 l/100 km (27.7 US mpg, 33.2 UK mpg, 11.8 km/l)
CO2 emissions 199 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6 sec
Acceleration 0 – 62 mph 6 sec
Acceleration 0 – 60 mph 5.7 sec
Maximum speed 250 km/h (155.34 mph)
Emission standard Euro 5
Weight-to-power ratio 5.8 kg/Hp, 171.2 Hp/tonne
Weight-to-torque ratio 4.5 kg/Nm, 220.7 Nm/tonne
Power 256 Hp @ 6000 rpm
Power per litre 129 Hp/l
Torque 330 Nm @ 2500-5000 rpm (243.4 lb.-ft. @ 2500-5000 rpm)
Engine layout Front, Transverse
Engine Model/Code CDLC
Engine displacement 1984 cm3 (121.07 cu. in.)
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm (3.25 in.)
Piston Stroke 92.8 mm (3.65 in.)
Compression ratio 9.8:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.6 l (4.86 US qt | 4.05 UK qt)
Coolant 8.6 l (9.09 US qt | 7.57 UK qt)
Kerb Weight 1495 kg (3295.91 lbs.)
Max. weight 2055 kg (4530.5 lbs.)
Max load 560 kg (1234.59 lbs.)
Trunk (boot) space – minimum 302 l (10.67 cu. ft.)
Fuel tank capacity 60 l (15.85 US gal | 13.2 UK gal)
Max. roof load 75 kg (165.35 lbs.)
Length 4302 mm (169.37 in.)
Width 1765 mm (69.49 in.)
Height 1402 mm (55.2 in.)
Wheelbase 2578 mm (101.5 in.)
Front track 1522 mm (59.92 in.)
Rear (Back) track 1506 mm (59.29 in.)
Drag coefficient (Cd) 0.33
Minimum turning circle 10.7 m (35.1 ft.)
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/40 R18
Wheel rims size 7.5J x 18

Powertrain & Engine Architecture

At the heart of the S3 Sportback (8PA) 2.0 TFSI quattro lies the CDLC engine code, a 2.0-liter inline-four cylinder gasoline engine. This engine is a member of the Volkswagen Group’s EA888 family, known for its robust design and tuning potential. The CDLC variant features direct fuel injection (FSI) and a K04 turbocharger, delivering a substantial boost in power compared to the standard A3 models. The engine utilizes a dual overhead camshaft (DOHC) valvetrain with four valves per cylinder, optimizing airflow for increased performance. The turbocharger and intercooler work in tandem to cool the intake air, increasing its density and further enhancing combustion efficiency. The 6-speed manual transmission was standard, providing precise gear changes and a direct connection to the engine. The quattro all-wheel-drive system, a hallmark of Audi performance models, distributes power between the front and rear axles as needed, maximizing traction and stability, particularly in adverse weather conditions.

Driving Characteristics

The 256 horsepower and 330 Nm (243 lb-ft) of torque, available from 2500-5000 rpm, provide the S3 Sportback with brisk acceleration. The 0-60 mph sprint takes approximately 5.7 seconds, and it reaches a top speed of 155 mph (electronically limited). The manual transmission offers a satisfyingly direct feel, allowing drivers to fully engage with the engine’s powerband. Compared to the standard A3 models, the S3 delivers a noticeably more responsive and engaging driving experience. While not as raw or visceral as some rear-wheel-drive performance cars, the quattro system provides exceptional grip and confidence, especially on corner exit. The gear ratios are well-matched to the engine’s characteristics, providing strong acceleration in each gear. Compared to the higher-output S3 variants (like those found in later generations), this 256 hp version offers a more accessible and manageable power delivery, making it a suitable choice for drivers who prioritize everyday usability alongside performance.

Equipment & Trim Levels

The S3 Sportback (8PA) came well-equipped as standard, reflecting its premium positioning. Key features included sport seats upholstered in a combination of cloth and Alcantara, a leather-wrapped steering wheel, and aluminum interior trim. Standard exterior features included S-line styling cues, such as unique front and rear bumpers, side skirts, and a rear spoiler. Optional extras included full leather upholstery, a panoramic sunroof, a premium sound system, and advanced driver-assistance systems like parking sensors and a navigation system. The interior dashboard configuration was typical of the 8PA A3 range, with a focus on functionality and a clean, modern design. The S3 trim added unique gauges and displays to monitor engine performance.

Chassis & Braking

The S3 Sportback featured a sport-tuned suspension, lowering the ride height and stiffening the dampers for improved handling. The front suspension utilized McPherson struts with coil springs and an anti-roll bar, while the rear employed a multi-link setup. This configuration provided a good balance between ride comfort and handling precision. Braking duties were handled by ventilated discs on all four wheels, providing ample stopping power. The ABS (Anti-lock Braking System) was standard, enhancing safety and stability during hard braking. The steering system was a rack-and-pinion setup with electric power assistance, offering precise and responsive steering feel.

Market Reception & Comparison

The Audi S3 Sportback (8PA) 2.0 TFSI quattro was generally well-received by automotive critics. It was praised for its blend of performance, practicality, and refinement. Fuel economy was considered reasonable for a performance car, averaging around 27.7 US mpg in combined driving. Reliability was generally good, although some owners reported minor issues with the turbocharger and direct injection system. Compared to other trims in the A3 lineup, the S3 offered a significant performance upgrade, but at a higher price point. The manual transmission was favored by enthusiasts, while the automatic option (available in some markets) offered greater convenience. Compared to rivals like the BMW 135i, the S3 offered a more refined and understated driving experience, while the BMW provided a more raw and engaging feel.

Legacy

The S3 Sportback (8PA) 2.0 TFSI quattro remains a popular choice in the used car market. The CDLC engine, while capable of high performance, requires regular maintenance, including oil changes and spark plug replacements. The turbocharger and direct injection system are potential areas of concern, and it’s important to inspect these components thoroughly before purchasing a used example. Despite its age, the S3 Sportback continues to offer a compelling combination of performance, practicality, and style, making it a desirable option for enthusiasts seeking a premium, all-wheel-drive hatchback.
