| General information | |
|---|---|
| Brand | BAIC |
| Model | BJ60 |
| Generation | BJ60 |
| Type (Engine) | 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic |
| Start of production | September, 2023 year |
| Powertrain Architecture | MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
| Body type | SUV |
| Seats | 5-7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – extra urban | 8 l/100 km 29.4 US mpg 35.3 UK mpg 12.5 km/l |
| Fuel consumption (economy) – combined | 8.5 l/100 km 27.7 US mpg 33.2 UK mpg 11.8 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 14.8 sec |
| Acceleration 0 – 62 mph | 14.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 14.1 sec |
| Maximum speed | 160 km/h 99.42 mph |
| Weight-to-power ratio | 14.7 kg/Hp, 67.9 Hp/tonne |
| Weight-to-torque ratio | 6 kg/Nm, 166.7 Nm/tonne |
| Electric cars and hybrids specs | |
| Battery voltage | 48 V |
| Electric motor 1 | |
| Electric motor power | 14 Hp |
| Electric motor Torque | 50 Nm
36.88 lb.-ft. |
| Electric motor location | Front, Longitudinal |
| Internal combustion engine specs | |
| Power | 163 Hp @ 3600 rpm. |
| Power per litre | 82.8 Hp/l |
| Torque | 400 Nm @ 1500-2400 rpm. 295.02 lb.-ft. @ 1500-2400 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 4F20TC30 |
| Engine displacement | 1968 cm3 120.09 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 16.2:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.2 l 5.49 US qt | 4.58 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11 l 11.62 US qt | 9.68 UK qt |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2400-2450 kg 5291.09 – 5401.33 lbs. |
| Max. weight | 2900-3050 kg 6393.41 – 6724.1 lbs. |
| Max load | 500-600 kg 1102.31 – 1322.77 lbs. |
| Trunk (boot) space – minimum | 972 l 34.33 cu. ft. |
| Trunk (boot) space – maximum | 1836 l 64.84 cu. ft. |
| Fuel tank capacity | 85 l 22.45 US gal | 18.7 UK gal |
| Dimensions | |
| Length | 5040 mm 198.43 in. |
| Width | 1955 mm 76.97 in. |
| Height | 1925 mm 75.79 in. |
| Wheelbase | 2820 mm 111.02 in. |
| Front track | 1620 mm 63.78 in. |
| Rear (Back) track | 1640 mm 64.57 in. |
| Ride height (ground clearance) | 215 mm 8.46 in. |
| Minimum turning circle (turning diameter) | 11.2 m 36.75 ft. |
| Approach angle | 30° |
| Departure angle | 24° |
| Ramp-over (brakeover) angle | 25° |
| Climb angle | 45° |
| Wading depth | 750 mm 29.53 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running only in mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front suspension | Double wishbone, Independent coil spring |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 265/65 R18; 275/50 R20 |
| Wheel rims size | 8J x 18; 8.5J x 20 |
| What is the body type, BAIC BJ60? | SUV, 5 Doors, 5-7 Seats |
|---|---|
| What is the fuel economy, BAIC BJ60 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 8.5 l/100 km 27.7 US mpg 33.2 UK mpg 11.8 km/l |
| How fast is the car, 2023 BJ60 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 160 km/h | 99.42 mph 0-100 km/h: 14.8 sec 0-60 mph: 14.1 sec |
| How much power, BAIC BJ60 SUV 2023 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 163 Hp, 400 Nm 295.02 lb.-ft. |
| What is the engine size, BAIC BJ60 SUV 2023 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 2.0 l 1968 cm3 120.09 cu. in. |
| How many cylinders, 2023 BAIC 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 4, Inline |
| What is the drivetrain, BAIC BJ60 SUV 2023 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | All wheel drive (4×4). MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV). The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running only in mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| How long is this vehicle, 2023 BAIC BJ60 SUV? | 5040 mm 198.43 in. |
| How wide is the vehicle, 2023 BAIC BJ60 SUV? | 1955 mm 76.97 in. |
| What is the curb weight, 2023 BAIC BJ60 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 2400-2450 kg 5291.09 – 5401.33 lbs. |
| What is the gross weight, 2023 BAIC BJ60 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 2900-3050 kg 6393.41 – 6724.1 lbs. |
| How much trunk (boot) space, 2023 BAIC BJ60 SUV? | 972 – 1836 l 34.33 – 64.84 cu. ft. |
| How many gears, What type is the gearbox, 2023 BAIC BJ60 2.0 TDI (163 Hp) Mild Hybrid 4WD Automatic? | 8, automatic transmission |
