| General information | |
|---|---|
| Brand | BMW |
| Model | 3 Series |
| Generation | 3 Series Gran Turismo (F34) |
| Type (Engine) | 325d (218 Hp) |
| Start of production | 2013 year |
| End of production | 2016 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Grand Tourer |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 6.2-6.4 l/100 km 37.9 – 36.8 US mpg 45.6 – 44.1 UK mpg 16.1 – 15.6 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 4.5-4.6 l/100 km 52.3 – 51.1 US mpg 62.8 – 61.4 UK mpg 22.2 – 21.7 km/l |
| Fuel consumption (economy) – combined (NEDC) | 5.1-5.2 l/100 km 46.1 – 45.2 US mpg 55.4 – 54.3 UK mpg 19.6 – 19.2 km/l |
| CO2 emissions (NEDC) | 134-138 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 7.1 sec |
| Acceleration 0 – 62 mph | 7.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 6.7 sec |
| Maximum speed | 240 km/h 149.13 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 7.3 kg/Hp, 136.3 Hp/tonne |
| Weight-to-torque ratio | 3.6 kg/Nm, 281.3 Nm/tonne |
| Engine specs | |
| Power | 218 Hp @ 4400 rpm. |
| Power per litre | 109.3 Hp/l |
| Torque | 450 Nm @ 1500-2500 rpm. 331.9 lb.-ft. @ 1500-2500 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | N47D20D |
| Engine displacement | 1995 cm3 121.74 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84 mm 3.31 in. |
| Piston Stroke | 90 mm 3.54 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Twin-power turbo, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.2 l 5.49 US qt | 4.58 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7 l 7.4 US qt | 6.16 UK qt |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1600 kg 3527.4 lbs. |
| Max. weight | 2170 kg 4784.03 lbs. |
| Max load | 570 kg 1256.63 lbs. |
| Trunk (boot) space – minimum | 520 l 18.36 cu. ft. |
| Trunk (boot) space – maximum | 1600 l 56.5 cu. ft. |
| Fuel tank capacity | 57 l 15.06 US gal | 12.54 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 1800 kg 3968.32 lbs. |
| Permitted trailer load with brakes (12%) | 1800 kg 3968.32 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4824 mm 189.92 in. |
| Width | 1828 mm 71.97 in. |
| Width including mirrors | 2047 mm 80.59 in. |
| Height | 1508 mm 59.37 in. |
| Wheelbase | 2920 mm 114.96 in. |
| Front track | 1541 mm 60.67 in. |
| Rear (Back) track | 1586 mm 62.44 in. |
| Front overhang | 803 mm 31.61 in. |
| Rear overhang | 1101 mm 43.35 in. |
| Ride height (ground clearance) | 165 mm 6.5 in. |
| Minimum turning circle (turning diameter) | 11.8 m 38.71 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Spring Strut, Transverse stabilizer |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 225/55 R17; 225/45 R18; 225/50 R18; 225/45 R19 Rear wheel tires: 225/55 R17; 225/50 R18; 255/40 R18; 255/40 R19 |
| Wheel rims size | Front wheel rims: 8J x 17; 8J x 18; 8J x 19 Rear wheel rims: 8J x 17; 8J x 18; 8.5J x 18; 9J x 19 |
| What is the body type, BMW 3 Series Gran Turismo (F34)? | Grand Tourer, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, BMW 3 Series Gran Turismo (F34) 325d (218 Hp)? | 5.1-5.2 l/100 km 46.1 – 45.2 US mpg 55.4 – 54.3 UK mpg 19.6 – 19.2 km/l |
| How ECO is the car, BMW 3 Series 325d (218 Hp)? | 134-138 g/km CO2 Euro 6 |
| How fast is the car, 2013 3 Series Gran Turismo (F34) 325d (218 Hp)? | 240 km/h | 149.13 mph 0-100 km/h: 7.1 sec 0-60 mph: 6.7 sec |
| How much power, BMW 3 Series Grand Tourer 2013 325d (218 Hp)? | 218 Hp, 450 Nm 331.9 lb.-ft. |
| What is the engine size, BMW 3 Series Grand Tourer 2013 325d (218 Hp)? | 2.0 l 1995 cm3 121.74 cu. in. |
| How many cylinders, 2013 BMW 325d (218 Hp)? | 4, Inline |
| What is the drivetrain, BMW 3 Series Gran Turismo (F34) Grand Tourer 2013 325d (218 Hp)? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2013 BMW 3 Series Grand Tourer? | 4824 mm 189.92 in. |
| How wide is the vehicle, 2013 BMW 3 Series Grand Tourer? | 1828 mm 71.97 in. |
| What is the curb weight, 2013 BMW 3 Series Gran Turismo (F34) 325d (218 Hp)? | 1600 kg 3527.4 lbs. |
| What is the gross weight, 2013 BMW 3 Series Gran Turismo (F34) 325d (218 Hp)? | 2170 kg 4784.03 lbs. |
| How much trunk (boot) space, 2013 BMW 3 Series Grand Tourer? | 520 – 1600 l 18.36 – 56.5 cu. ft. |
| How many gears, What type is the gearbox, 2013 BMW 3 Series Gran Turismo (F34) 325d (218 Hp)? | 6, manual transmission |
