| General information | |
|---|---|
| Brand | BMW |
| Model | 5 Series |
| Generation | 5 Series Sedan (F10 LCI, Facelift 2013) |
| Type (Engine) | 520d (184 Hp) xDrive Steptronic |
| Start of production | 2013 year |
| End of production | 2014 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban | 5.7-6.2 l/100 km 41.3 – 37.9 US mpg 49.6 – 45.6 UK mpg 17.5 – 16.1 km/l |
| Fuel consumption (economy) – extra urban | 4.4-4.8 l/100 km 53.5 – 49 US mpg 64.2 – 58.9 UK mpg 22.7 – 20.8 km/l |
| Fuel consumption (economy) – combined | 4.9-5.3 l/100 km 48 – 44.4 US mpg 57.6 – 53.3 UK mpg 20.4 – 18.9 km/l |
| CO2 emissions | 129-139 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 8.1 sec |
| Acceleration 0 – 62 mph | 8.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.7 sec |
| Maximum speed | 228 km/h 141.67 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 9.4 kg/Hp, 106.4 Hp/tonne |
| Weight-to-torque ratio | 4.6 kg/Nm, 219.7 Nm/tonne |
| Engine specs | |
| Power | 184 Hp @ 4000 rpm. |
| Power per litre | 92.2 Hp/l |
| Torque | 380 Nm @ 1750-2750 rpm. 280.27 lb.-ft. @ 1750-2750 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | N47D20C |
| Engine displacement | 1995 cm3 121.74 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84 mm 3.31 in. |
| Piston Stroke | 90 mm 3.54 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Twin-power turbo, Intercooler |
| Engine oil capacity | 5.2 l 5.49 US qt | 4.58 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.2 l 7.61 US qt | 6.34 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1730 kg 3814 lbs. |
| Max. weight | 2330 kg 5136.77 lbs. |
| Max load | 600 kg 1322.77 lbs. |
| Trunk (boot) space – minimum | 520 l 18.36 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 90 kg 198.42 lbs. |
| Dimensions | |
| Length | 4907 mm 193.19 in. |
| Width | 1860 mm 73.23 in. |
| Height | 1464 mm 57.64 in. |
| Wheelbase | 2968 mm 116.85 in. |
| Front track | 1600 mm 62.99 in. |
| Rear (Back) track | 1627 mm 64.06 in. |
| Ride height (ground clearance) | 141 mm 5.55 in. |
| Drag coefficient (Cd) | 0.25 |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission Steptronic |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/55 R17; 245/45 R18; 275/40 R18; 245/40 R19; 275/35 R19; 245/35 R20; 275/30 R20 |
| Wheel rims size | 8J x 17; 8J x 18; 9J x 18; 8.5J x 19; 9J x 19; 8.5J x 20; 9J x 20 |
| What is the body type, BMW 5 Series Sedan (F10 LCI, Facelift 2013)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, BMW 5 Series Sedan (F10 LCI, Facelift 2013) 520d (184 Hp) xDrive Steptronic? | 4.9-5.3 l/100 km 48 – 44.4 US mpg 57.6 – 53.3 UK mpg 20.4 – 18.9 km/l |
| How ECO is the car, BMW 5 Series 520d (184 Hp) xDrive Steptronic? | 129-139 g/km CO2 Euro 6 |
| How fast is the car, 2013 5 Series Sedan (F10 LCI, Facelift 2013) 520d (184 Hp) xDrive Steptronic? | 228 km/h | 141.67 mph 0-100 km/h: 8.1 sec 0-60 mph: 7.7 sec |
| How much power, BMW 5 Series Sedan 2013 520d (184 Hp) xDrive Steptronic? | 184 Hp, 380 Nm 280.27 lb.-ft. |
| What is the engine size, BMW 5 Series Sedan 2013 520d (184 Hp) xDrive Steptronic? | 2.0 l 1995 cm3 121.74 cu. in. |
| How many cylinders, 2013 BMW 520d (184 Hp) xDrive Steptronic? | 4, Inline |
| What is the drivetrain, BMW 5 Series Sedan (F10 LCI, Facelift 2013) Sedan 2013 520d (184 Hp) xDrive Steptronic? | All wheel drive (4×4). Internal Combustion engine. |
| How long is this vehicle, 2013 BMW 5 Series Sedan? | 4907 mm 193.19 in. |
| How wide is the vehicle, 2013 BMW 5 Series Sedan? | 1860 mm 73.23 in. |
| What is the curb weight, 2013 BMW 5 Series Sedan (F10 LCI, Facelift 2013) 520d (184 Hp) xDrive Steptronic? | 1730 kg 3814 lbs. |
| What is the gross weight, 2013 BMW 5 Series Sedan (F10 LCI, Facelift 2013) 520d (184 Hp) xDrive Steptronic? | 2330 kg 5136.77 lbs. |
| How much trunk (boot) space, 2013 BMW 5 Series Sedan? | 520 l 18.36 cu. ft. |
| How many gears, What type is the gearbox, 2013 BMW 5 Series Sedan (F10 LCI, Facelift 2013) 520d (184 Hp) xDrive Steptronic? | 8, automatic transmission Steptronic |
