| General information | |
|---|---|
| Brand | BMW |
| Model | i3 |
| Generation | i3 (l01) |
| Type (Engine) | 22 kWh (170 Hp) |
| Start of production | 2013 year |
| End of production | 2017 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Hatchback |
| Seats | 4 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 7.2 sec |
| Acceleration 0 – 62 mph | 7.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 6.8 sec |
| Maximum speed | 150 km/h, Electronically limited 93.21 mph |
| Weight-to-power ratio | 7 kg/Hp, 142.3 Hp/tonne |
| Weight-to-torque ratio | 4.8 kg/Nm, 209.2 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 22 kWh |
| Net (usable) battery capacity | 18.8 kWh |
| Battery voltage | 360 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery weight | 230 kg 507.06 lbs. |
| Battery location | Below the floor |
| Recuperation output | 50 kW |
| All-electric range | 190 km 118.06 mi |
| Average Energy consumption | 12.9 kWh/100 km
20.76 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 170 Hp |
| Electric motor Torque | 250 Nm @ 0 rpm.
184.39 lb.-ft. |
| Electric motor model/code | IB1P23M0 |
| Maximum revolutions of the electric motor | 11400 rpm. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 170 Hp |
| System torque | 250 Nm 184.39 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1195 kg 2634.52 lbs. |
| Max. weight | 1620 kg 3571.49 lbs. |
| Max load | 425 kg 936.96 lbs. |
| Trunk (boot) space – minimum | 260 l 9.18 cu. ft. |
| Trunk (boot) space – maximum | 1100 l 38.85 cu. ft. |
| Dimensions | |
| Length | 3999 mm 157.44 in. |
| Width | 1775 mm 69.88 in. |
| Height | 1578 mm 62.13 in. |
| Wheelbase | 2570 mm 101.18 in. |
| Front track | 1571 mm 61.85 in. |
| Rear (Back) track | 1576 mm 62.05 in. |
| Front overhang | 707 mm 27.83 in. |
| Rear overhang | 722 mm 28.43 in. |
| Ride height (ground clearance) | 140 mm 5.51 in. |
| Drag coefficient (Cd) | 0.29 |
| Minimum turning circle (turning diameter) | 9.86 m 32.35 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the rear wheels. |
| Drive wheel | Rear wheel drive |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 155/70 R19 |
| Wheel rims size | 5J x 19 |
| What is the body type, BMW i3 (l01)? | Hatchback, 5 Doors, 4 Seats |
|---|---|
| What is the range of pure electric driving, 22 kWh (170 Hp)? | 190 km 118.06 mi |
| What is electricity consumption, BMW i3 (l01) 22 kWh (170 Hp)? | 12.9 kWh/100 km 20.76 kWh/100 mi 162 MPGe 7.8 km/kWh 4.8 mi/kWh |
| How fast is the car, 2013 i3 (l01) 22 kWh (170 Hp)? | 150 km/h | 93.21 mph 0-100 km/h: 7.2 sec 0-60 mph: 6.8 sec |
| How much power, BMW i3 Hatchback 2013 22 kWh (170 Hp)? | 170 Hp, 250 Nm 184.39 lb.-ft. |
| What is the drivetrain, BMW i3 (l01) Hatchback 2013 22 kWh (170 Hp)? | Rear wheel drive. BEV (Electric Vehicle). One electric motor drives the rear wheels. |
| How long is this vehicle, 2013 BMW i3 Hatchback? | 3999 mm 157.44 in. |
| How wide is the vehicle, 2013 BMW i3 Hatchback? | 1775 mm 69.88 in. |
| What is the curb weight, 2013 BMW i3 (l01) 22 kWh (170 Hp)? | 1195 kg 2634.52 lbs. |
| What is the gross weight, 2013 BMW i3 (l01) 22 kWh (170 Hp)? | 1620 kg 3571.49 lbs. |
| How much trunk (boot) space, 2013 BMW i3 Hatchback? | 260 – 1100 l 9.18 – 38.85 cu. ft. |
