| General information | |
|---|---|
| Brand | BMW |
| Model | iX1 |
| Generation | iX1 (U11) |
| Type (Engine) | 68 kWh (313 Hp) xDrive30 |
| Start of production | November, 2022 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SAV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 5.6 sec |
| Acceleration 0 – 62 mph | 5.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 5.3 sec |
| Maximum speed | 180 km/h, Electronically limited 111.85 mph |
| Weight-to-power ratio | 6.4 kg/Hp, 155.7 Hp/tonne |
| Weight-to-torque ratio | 4.1 kg/Nm, 245.8 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 68 kWh |
| Net (usable) battery capacity | 64.7 kWh |
| Battery voltage | 286 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| Recuperation output | 140 kW |
| All-electric range (WLTP) | 417-440 km 259.11 – 273.4 mi |
| Average Energy consumption (WLTP) | 16.8-18.1 kWh/100 km
27.04 – 29.13 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 190 Hp @ 8000 rpm. |
| Electric motor Torque | 247 Nm @ 0-4900 rpm.
182.18 lb.-ft. @ 0-4900 rpm. |
| Electric motor model/code | eDrive 5.0 M170SF |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 190 Hp @ 8000 rpm. |
| Electric motor Torque | 247 Nm @ 0-4900 rpm.
182.18 lb.-ft. @ 0-4900 rpm. |
| Electric motor model/code | eDrive 5.0 M170SR |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 313 Hp |
| System torque | 494 Nm 364.36 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2010 kg 4431.29 lbs. |
| Max. weight | 2580 kg 5687.93 lbs. |
| Max load | 570 kg 1256.63 lbs. |
| Trunk (boot) space – minimum | 490 l 17.3 cu. ft. |
| Trunk (boot) space – maximum | 1495 l 52.8 cu. ft. |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4500 mm 177.17 in. |
| Width | 1845 mm 72.64 in. |
| Width including mirrors | 2104 mm 82.83 in. |
| Height | 1616 mm 63.62 in. |
| Wheelbase | 2692 mm 105.98 in. |
| Front track | 1591 mm 62.64 in. |
| Rear (Back) track | 1593 mm 62.72 in. |
| Front overhang | 875 mm 34.45 in. |
| Rear overhang | 933 mm 36.73 in. |
| Ride height (ground clearance) | 170 mm 6.69 in. |
| Drag coefficient (Cd) | 0.26 |
| Minimum turning circle (turning diameter) | 11.9 m 39.04 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Spring Strut |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/65 R17 |
| Wheel rims size | 7.5J x 17 |
| What is the body type, BMW iX1 (U11)? | SAV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 68 kWh (313 Hp) xDrive30? | 417-440 km 259.11 – 273.4 mi |
| What is electricity consumption, BMW iX1 (U11) 68 kWh (313 Hp) xDrive30? | 16.8-18.1 kWh/100 km 27.04 – 29.13 kWh/100 mi 125 – 116 MPGe 6 – 5.5 km/kWh 3.7 – 3.4 mi/kWh |
| How fast is the car, 2022 iX1 (U11) 68 kWh (313 Hp) xDrive30? | 180 km/h | 111.85 mph 0-100 km/h: 5.6 sec 0-60 mph: 5.3 sec |
| How much power, BMW iX1 SAV 2022 68 kWh (313 Hp) xDrive30? | 313 Hp, 494 Nm 364.36 lb.-ft. |
| What is the drivetrain, BMW iX1 (U11) SAV 2022 68 kWh (313 Hp) xDrive30? | All wheel drive (4×4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| How long is this vehicle, 2022 BMW iX1 SAV? | 4500 mm 177.17 in. |
| How wide is the vehicle, 2022 BMW iX1 SAV? | 1845 mm 72.64 in. |
| What is the curb weight, 2022 BMW iX1 (U11) 68 kWh (313 Hp) xDrive30? | 2010 kg 4431.29 lbs. |
| What is the gross weight, 2022 BMW iX1 (U11) 68 kWh (313 Hp) xDrive30? | 2580 kg 5687.93 lbs. |
| How much trunk (boot) space, 2022 BMW iX1 SAV? | 490 – 1495 l 17.3 – 52.8 cu. ft. |
| How many gears, What type is the gearbox, 2022 BMW iX1 (U11) 68 kWh (313 Hp) xDrive30? | 1, automatic transmission |
