| General information | |
|---|---|
| Brand | BMW |
| Model | iX3 |
| Generation | iX3 (NA5) |
| Type (Engine) | 50 108.7 kWh (469 Hp) xDrive |
| Start of production | November, 2025 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SAV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 4.9 sec |
| Acceleration 0 – 62 mph | 4.9 sec |
| Acceleration 0 – 60 mph | 4.7 sec |
| Maximum speed | 210 km/h, Electronically limited 130.49 mph |
| Weight-to-power ratio | 4.9 kg/Hp, 205.3 Hp/tonne |
| Weight-to-torque ratio | 3.5 kg/Nm, 282.3 Nm/tonne |
| Electric cars and hybrids specs | |
| Net (usable) battery capacity | 108.7 kWh |
| Battery voltage | 698.9 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 679-805 km 421.91 – 500.2 mi |
| All-electric range (CLTC) | 900 km 559.23 mi |
| Average Energy consumption (WLTP) | 15.1-22.7 kWh/100 km
24.3 – 36.53 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 326 Hp @ 5000 rpm. |
| Electric motor Torque | 435 Nm @ 0-5000 rpm.
320.84 lb.-ft. @ 0-5000 rpm. |
| Electric motor model/code | HD1002N0 |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 167 Hp @ 4607 rpm. |
| Electric motor Torque | 255 Nm @ 0-4607 rpm.
188.08 lb.-ft. @ 0-4607 rpm. |
| Electric motor model/code | HF1001N0 |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Asynchronous |
| System power | 469 Hp |
| System torque | 645 Nm 475.73 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2285 kg 5037.56 lbs. |
| Max. weight | 2825 kg 6228.06 lbs. |
| Max load | 540 kg 1190.5 lbs. |
| Trunk (boot) space – minimum | 520 l 18.36 cu. ft. |
| Trunk (boot) space – maximum | 1750 l 61.8 cu. ft. |
| Fuel tank capacity | 58 l 15.32 US gal | 12.76 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 80 kg 176.37 lbs. |
| Dimensions | |
| Length | 4782 mm 188.27 in. |
| Width | 1895 mm 74.61 in. |
| Width including mirrors | 2093 mm 82.4 in. |
| Height | 1635 mm 64.37 in. |
| Wheelbase | 2897 mm 114.06 in. |
| Front track | 1628 mm 64.09 in. |
| Rear (Back) track | 1633 mm 64.29 in. |
| Front overhang | 895 mm 35.24 in. |
| Rear overhang | 990 mm 38.98 in. |
| Ride height (ground clearance) | 176 mm 6.93 in. |
| Drag coefficient (Cd) | 0.24 |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Approach angle | 18.6° |
| Departure angle | 20.2° |
| Ramp-over (brakeover) angle | 15.9° |
| Wading depth | 400 mm 15.75 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Spring Strut, Transverse stabilizer |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 330 mm |
| Rear brakes | Ventilated discs, 345 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 255/45 R20 |
| Wheel rims size | 8.5J x 20 |
| What is the body type, BMW iX3 (NA5)? | SAV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 50 108.7 kWh (469 Hp) xDrive? | 679-805 km 421.91 – 500.2 mi |
| What is electricity consumption, BMW iX3 (NA5) 50 108.7 kWh (469 Hp) xDrive? | 15.1-22.7 kWh/100 km 24.3 – 36.53 kWh/100 mi 139 – 92 MPGe 6.6 – 4.4 km/kWh 4.1 – 2.7 mi/kWh |
| How fast is the car, 2025 iX3 (NA5) 50 108.7 kWh (469 Hp) xDrive? | 210 km/h | 130.49 mph 0-100 km/h: 4.9 sec 0-60 mph: 4.7 sec |
| How much power, BMW iX3 SAV 2025 50 108.7 kWh (469 Hp) xDrive? | 469 Hp, 645 Nm 475.73 lb.-ft. |
| What is the drivetrain, BMW iX3 (NA5) SAV 2025 50 108.7 kWh (469 Hp) xDrive? | All wheel drive (4×4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| How long is this vehicle, 2025 BMW iX3 SAV? | 4782 mm 188.27 in. |
| How wide is the vehicle, 2025 BMW iX3 SAV? | 1895 mm 74.61 in. |
| What is the curb weight, 2025 BMW iX3 (NA5) 50 108.7 kWh (469 Hp) xDrive? | 2285 kg 5037.56 lbs. |
| What is the gross weight, 2025 BMW iX3 (NA5) 50 108.7 kWh (469 Hp) xDrive? | 2825 kg 6228.06 lbs. |
| How much trunk (boot) space, 2025 BMW iX3 SAV? | 520 – 1750 l 18.36 – 61.8 cu. ft. |
| How many gears, What type is the gearbox, 2025 BMW iX3 (NA5) 50 108.7 kWh (469 Hp) xDrive? | 1, automatic transmission |
