| General information | |
|---|---|
| Brand | BYD |
| Model | Shark 6 |
| Generation | Shark 6 |
| Type (Engine) | DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS |
| Start of production | 2024 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Pick-up |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – combined (NEDC) | 2-7.9 l/100 km 117.6 – 29.8 US mpg 141.2 – 35.8 UK mpg 50 – 12.7 km/l |
| CO2 emissions (NEDC) | 46 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 5.7 sec |
| Acceleration 0 – 62 mph | 5.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 5.4 sec |
| Maximum speed | 160 km/h 99.42 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 6.2 kg/Hp, 160.5 Hp/tonne |
| Weight-to-torque ratio | 4.2 kg/Nm, 239.9 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 29.6 kWh |
| Battery technology | Lithium iron phosphate (LiFePO4) |
| Battery location | Below the floor |
| All-electric range (NEDC) | 100 km 62.14 mi |
| Average Energy consumption (NEDC) | 21.2 kWh/100 km
34.12 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 231 Hp |
| Electric motor Torque | 310 Nm
228.64 lb.-ft. |
| Electric motor model/code | TZ220XYV |
| Maximum revolutions of the electric motor | 18000 rpm. |
| Electric motor location | Front axle, Longitudinal |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 204 Hp |
| Electric motor Torque | 340 Nm
250.77 lb.-ft. |
| Electric motor model/code | TZ200XSV |
| Maximum revolutions of the electric motor | 16000 rpm. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 435 Hp |
| System torque | 650 Nm 479.42 lb.-ft. |
| Internal combustion engine specs | |
| Power | 184 Hp @ 5400 rpm. |
| Power per litre | 122.9 Hp/l |
| Torque | 260 Nm @ 2000-4800 rpm. 191.77 lb.-ft. @ 2000-4800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | BYD476ZQF |
| Engine displacement | 1497 cm3 91.35 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.5 l 4.76 US qt | 3.96 UK qt |
| Engine oil specification | Log in to see. |
| Coolant | 8.8 l 9.3 US qt | 7.74 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2710 kg 5974.53 lbs. |
| Max. weight | 3500 kg 7716.18 lbs. |
| Max load | 790 kg 1741.65 lbs. |
| Trunk (boot) space – minimum | 1200 l 42.38 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Permitted trailer load with brakes (12%) | 2500 kg 5511.56 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 5457 mm 214.84 in. |
| Width | 1971 mm 77.6 in. |
| Height | 1925 mm 75.79 in. |
| Wheelbase | 3260 mm 128.35 in. |
| Front track | 1660 mm 65.35 in. |
| Rear (Back) track | 1660 mm 65.35 in. |
| Front overhang | 927 mm 36.5 in. |
| Rear overhang | 1270 mm 50 in. |
| Ride height (ground clearance) | 230 mm 9.06 in. |
| Minimum turning circle (turning diameter) | 13.5 m 44.29 ft. |
| Approach angle | 31° |
| Departure angle | 19.3° |
| Ramp-over (brakeover) angle | 17° |
| Climb angle | 31° |
| Wading depth | 700 mm 27.56 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. One electric motor drives the front wheels, one electric motor drives the rear wheels. There is a capability of running in full electric mode, only by the Internal combustion engine (ICE) or in mixed mode. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | automatic transmission EHS |
| Front suspension | Coil spring, Double wishbone |
| Rear suspension | Double wishbone, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 265/65 R18 |
| Wheel rims size | 8J x 18 |
| What is the body type, BYD Shark 6? | Pick-up, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, BYD Shark 6 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 2-7.9 l/100 km 117.6 – 29.8 US mpg 141.2 – 35.8 UK mpg 50 – 12.7 km/l |
| How ECO is the car, BYD Shark 6 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 46 g/km CO2 Euro 5 |
| What is the range of pure electric driving, DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 100 km 62.14 mi |
| What is electricity consumption, BYD Shark 6 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 21.2 kWh/100 km 34.12 kWh/100 mi 99 MPGe 4.7 km/kWh 2.9 mi/kWh |
| How fast is the car, 2024 Shark 6 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 160 km/h | 99.42 mph 0-100 km/h: 5.7 sec 0-60 mph: 5.4 sec |
| How much power, BYD Shark 6 Pick-up 2024 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 435 Hp, 650 Nm 479.42 lb.-ft. |
| What is the engine size, BYD Shark 6 Pick-up 2024 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 1.5 l 1497 cm3 91.35 cu. in. |
| How many cylinders, 2024 BYD DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 4, Inline |
| What is the drivetrain, BYD Shark 6 Pick-up 2024 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) drives the front wheels of the vehicle. One electric motor drives the front wheels, one electric motor drives the rear wheels. There is a capability of running in full electric mode, only by the Internal combustion engine (ICE) or in mixed mode. |
| How long is this vehicle, 2024 BYD Shark 6 Pick-up? | 5457 mm 214.84 in. |
| How wide is the vehicle, 2024 BYD Shark 6 Pick-up? | 1971 mm 77.6 in. |
| What is the curb weight, 2024 BYD Shark 6 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 2710 kg 5974.53 lbs. |
| What is the gross weight, 2024 BYD Shark 6 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | 3500 kg 7716.18 lbs. |
| How much trunk (boot) space, 2024 BYD Shark 6 Pick-up? | 1200 l 42.38 cu. ft. |
| How many gears, What type is the gearbox, 2024 BYD Shark 6 DMO 1.5T 29.6 kWh (435 Hp) Plug-in Hybrid AWD EHS? | automatic transmission EHS |
