| General information | |
|---|---|
| Brand | Cadillac |
| Model | XT5 |
| Generation | XT5 |
| Type (Engine) | 2.0 (261 Hp) Automatic |
| Start of production | 2016 year |
| End of production | 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| Fuel consumption (economy) – extra urban | 8.7 l/100 km 27 US mpg 32.5 UK mpg 11.5 km/l |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 6.9 kg/Hp, 144.4 Hp/tonne |
| Weight-to-torque ratio | 4.5 kg/Nm, 221.2 Nm/tonne |
| Engine specs | |
| Power | 261 Hp @ 5300 rpm. |
| Power per litre | 130.6 Hp/l |
| Torque | 400 Nm @ 3000 rpm. 295.02 lb.-ft. @ 3000 rpm. |
| Maximum engine speed | 7000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | LTG |
| Engine displacement | 1998 cm3 121.93 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm 3.39 in. |
| Piston Stroke | 86 mm 3.39 in. |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC-VVT |
| Engine oil capacity | 6 l 6.34 US qt | 5.28 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8.25 l 8.72 US qt | 7.26 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1808 kg 3985.96 lbs. |
| Trunk (boot) space – minimum | 849 l 29.98 cu. ft. |
| Trunk (boot) space – maximum | 1784 l 63 cu. ft. |
| Fuel tank capacity | 72 l 19.02 US gal | 15.84 UK gal |
| Permitted trailer load with brakes (12%) | 1588 kg 3500.94 lbs. |
| Dimensions | |
| Length | 4815 mm 189.57 in. |
| Width | 1903 mm 74.92 in. |
| Height | 1675 mm 65.94 in. |
| Wheelbase | 2857 mm 112.48 in. |
| Front track | 1638 mm 64.49 in. |
| Rear (Back) track | 1638 mm 64.49 in. |
| Front overhang | 987 mm 38.86 in. |
| Rear overhang | 971 mm 38.23 in. |
| Ride height (ground clearance) | 200 mm 7.87 in. |
| Minimum turning circle (turning diameter) | 11.8-11.9 m 38.71 – 39.04 ft. |
| Approach angle | 15.8° |
| Departure angle | 23.5° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/65 R18; 235/55 R20 |
| Wheel rims size | 18; 20 |
| What is the body type, Cadillac XT5? | SUV, 5 Doors, 5 Seats |
|---|---|
| How ECO is the car, Cadillac XT5 2.0 (261 Hp) Automatic? | Euro 6 |
| How much power, Cadillac XT5 SUV 2016 2.0 (261 Hp) Automatic? | 261 Hp, 400 Nm 295.02 lb.-ft. |
| What is the engine size, Cadillac XT5 SUV 2016 2.0 (261 Hp) Automatic? | 2.0 l 1998 cm3 121.93 cu. in. |
| How many cylinders, 2016 Cadillac 2.0 (261 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Cadillac XT5 SUV 2016 2.0 (261 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2016 Cadillac XT5 SUV? | 4815 mm 189.57 in. |
| How wide is the vehicle, 2016 Cadillac XT5 SUV? | 1903 mm 74.92 in. |
| What is the curb weight, 2016 Cadillac XT5 2.0 (261 Hp) Automatic? | 1808 kg 3985.96 lbs. |
| How much trunk (boot) space, 2016 Cadillac XT5 SUV? | 849 – 1784 l 29.98 – 63 cu. ft. |
| How many gears, What type is the gearbox, 2016 Cadillac XT5 2.0 (261 Hp) Automatic? | 8, automatic transmission |
