| General information | |
|---|---|
| Brand | Caterham |
| Model | CSR |
| Generation | CSR |
| Type (Engine) | CSR (200 Hp) |
| Start of production | 2004 year |
| End of production | 2014 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 2 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption (economy) – urban | 16.6 l/100 km 14.2 US mpg 17 UK mpg 6 km/l |
| Fuel consumption (economy) – extra urban | 8.5 l/100 km 27.7 US mpg 33.2 UK mpg 11.8 km/l |
| Fuel consumption (economy) – combined | 11.5 l/100 km 20.5 US mpg 24.6 UK mpg 8.7 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 3.7 sec |
| Acceleration 0 – 62 mph | 3.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 3.5 sec |
| Maximum speed | 225 km/h 139.81 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 2.8 kg/Hp, 354 Hp/tonne |
| Weight-to-torque ratio | 2.6 kg/Nm, 391.2 Nm/tonne |
| Engine specs | |
| Power | 200 Hp @ 7000 rpm. |
| Power per litre | 88.5 Hp/l |
| Torque | 221 Nm 163 lb.-ft. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | Duratec |
| Engine displacement | 2261 cm3 137.97 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.5 l 4.76 US qt | 3.96 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.5 l 5.81 US qt | 4.84 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 565 kg 1245.61 lbs. |
| Max. weight | 875 kg 1929.04 lbs. |
| Max load | 310 kg 683.43 lbs. |
| Fuel tank capacity | 42 l 11.1 US gal | 9.24 UK gal |
| Dimensions | |
| Length | 3300 mm 129.92 in. |
| Width | 1685 mm 66.34 in. |
| Height | 1140 mm 44.88 in. |
| Wheelbase | 2315 mm 91.14 in. |
| Front track | 1505 mm 59.25 in. |
| Rear (Back) track | 1465 mm 57.68 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent coil spring |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Steering type | Steering rack and pinion |
| Tires size | 195/45R15; 255/40 R15 |
| What is the body type, Caterham CSR? | Cabriolet, 2 Doors, 2 Seats |
|---|---|
| What is the fuel economy, Caterham CSR CSR (200 Hp)? | 11.5 l/100 km 20.5 US mpg 24.6 UK mpg 8.7 km/l |
| How ECO is the car, Caterham CSR CSR (200 Hp)? | Euro 4 |
| How fast is the car, 2004 CSR CSR (200 Hp)? | 225 km/h | 139.81 mph 0-100 km/h: 3.7 sec 0-60 mph: 3.5 sec |
| How much power, Caterham CSR Cabriolet 2004 CSR (200 Hp)? | 200 Hp, 221 Nm 163 lb.-ft. |
| What is the engine size, Caterham CSR Cabriolet 2004 CSR (200 Hp)? | 2.3 l 2261 cm3 137.97 cu. in. |
| How many cylinders, 2004 Caterham CSR (200 Hp)? | 4, Inline |
| What is the drivetrain, Caterham CSR Cabriolet 2004 CSR (200 Hp)? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2004 Caterham CSR Cabriolet? | 3300 mm 129.92 in. |
| How wide is the vehicle, 2004 Caterham CSR Cabriolet? | 1685 mm 66.34 in. |
| What is the curb weight, 2004 Caterham CSR CSR (200 Hp)? | 565 kg 1245.61 lbs. |
| What is the gross weight, 2004 Caterham CSR CSR (200 Hp)? | 875 kg 1929.04 lbs. |
| How many gears, What type is the gearbox, 2004 Caterham CSR CSR (200 Hp)? | 6, manual transmission |
