| General information | |
|---|---|
| Brand | Chery |
| Model | Tiggo 2 |
| Generation | Tiggo 2 |
| Type (Engine) | 1.5 (105 Hp) CVT |
| Start of production | 2016 year |
| End of production | 2021 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 9.9 l/100 km 23.8 US mpg 28.5 UK mpg 10.1 km/l |
| Fuel consumption (economy) – extra urban | 4.1 l/100 km 57.4 US mpg 68.9 UK mpg 24.4 km/l |
| Fuel consumption (economy) – combined | 6.2 l/100 km 37.9 US mpg 45.6 UK mpg 16.1 km/l |
| CO2 emissions | 149 g/km |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 160 km/h 99.42 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 11.9 kg/Hp, 84.3 Hp/tonne |
| Weight-to-torque ratio | 9.2 kg/Nm, 108.4 Nm/tonne |
| Engine specs | |
| Power | 105 Hp @ 6000 rpm. |
| Power per litre | 70.1 Hp/l |
| Torque | 135 Nm @ 2750 rpm. 99.57 lb.-ft. @ 2750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | SQRD4G15B |
| Engine displacement | 1497 cm3 91.35 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 77.4 mm 3.05 in. |
| Piston Stroke | 79.52 mm 3.13 in. |
| Compression ratio | 11.4:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 4 l 4.23 US qt | 3.52 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.8 l 8.24 US qt | 6.86 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1245 kg 2744.76 lbs. |
| Max. weight | 1620 kg 3571.49 lbs. |
| Max load | 375 kg 826.73 lbs. |
| Trunk (boot) space – minimum | 341 l 12.04 cu. ft. |
| Trunk (boot) space – maximum | 592 l 20.91 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Dimensions | |
| Length | 4200 mm 165.35 in. |
| Width | 1760 mm 69.29 in. |
| Height | 1570 mm 61.81 in. |
| Wheelbase | 2555 mm 100.59 in. |
| Front track | 1495 mm 58.86 in. |
| Rear (Back) track | 1484 mm 58.43 in. |
| Front overhang | 854 mm 33.62 in. |
| Rear overhang | 791 mm 31.14 in. |
| Ride height (ground clearance) | 178 mm 7.01 in. |
| Minimum turning circle (turning diameter) | 10.5 m 34.45 ft. |
| Approach angle | 23° |
| Departure angle | 32° |
| Climb angle | 21.8° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | automatic transmission CVT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring, Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/65 R15; 205/55 R16; 205/50 R17 |
| Wheel rims size | 6J x 15; 6.5J x 16; 6.5J x 17 |
| What is the body type, Chery Tiggo 2? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Chery Tiggo 2 1.5 (105 Hp) CVT? | 6.2 l/100 km 37.9 US mpg 45.6 UK mpg 16.1 km/l |
| How ECO is the car, Chery Tiggo 2 1.5 (105 Hp) CVT? | 149 g/km CO2 Euro 6 |
| How fast is the car, 2016 Tiggo 2 1.5 (105 Hp) CVT? | 160 km/h | 99.42 mph |
| How much power, Chery Tiggo 2 SUV 2016 1.5 (105 Hp) CVT? | 105 Hp, 135 Nm 99.57 lb.-ft. |
| What is the engine size, Chery Tiggo 2 SUV 2016 1.5 (105 Hp) CVT? | 1.5 l 1497 cm3 91.35 cu. in. |
| How many cylinders, 2016 Chery 1.5 (105 Hp) CVT? | 4, Inline |
| What is the drivetrain, Chery Tiggo 2 SUV 2016 1.5 (105 Hp) CVT? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2016 Chery Tiggo 2 SUV? | 4200 mm 165.35 in. |
| How wide is the vehicle, 2016 Chery Tiggo 2 SUV? | 1760 mm 69.29 in. |
| What is the curb weight, 2016 Chery Tiggo 2 1.5 (105 Hp) CVT? | 1245 kg 2744.76 lbs. |
| What is the gross weight, 2016 Chery Tiggo 2 1.5 (105 Hp) CVT? | 1620 kg 3571.49 lbs. |
| How much trunk (boot) space, 2016 Chery Tiggo 2 SUV? | 341 – 592 l 12.04 – 20.91 cu. ft. |
| How many gears, What type is the gearbox, 2016 Chery Tiggo 2 1.5 (105 Hp) CVT? | automatic transmission CVT |
