| General information | |
|---|---|
| Brand | Chevrolet |
| Model | HHR |
| Generation | HHR |
| Type (Engine) | 2.4 i 16V (175 Hp) Automatic |
| Start of production | 2005 year |
| End of production | May, 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| Fuel consumption (economy) – extra urban | 9.4 l/100 km 25 US mpg 30.1 UK mpg 10.6 km/l |
| Fuel consumption (economy) – combined | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 8.3 kg/Hp, 120.3 Hp/tonne |
| Weight-to-torque ratio | 6.4 kg/Nm, 156.7 Nm/tonne |
| Engine specs | |
| Power | 175 Hp @ 6200 rpm. |
| Power per litre | 73.4 Hp/l |
| Torque | 228 Nm @ 5000 rpm. 168.16 lb.-ft. @ 5000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | LE5 |
| Engine displacement | 2384 cm3 145.48 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 88 mm 3.46 in. |
| Piston Stroke | 98 mm 3.86 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.7 l 4.97 US qt | 4.14 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8 l 8.45 US qt | 7.04 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1455 kg 3207.73 lbs. |
| Trunk (boot) space – minimum | 638 l 22.53 cu. ft. |
| Trunk (boot) space – maximum | 1785 l 63.04 cu. ft. |
| Fuel tank capacity | 49 l 12.94 US gal | 10.78 UK gal |
| Dimensions | |
| Length | 4475 mm 176.18 in. |
| Width | 1755 mm 69.09 in. |
| Height | 1603 mm 63.11 in. |
| Wheelbase | 2628 mm 103.46 in. |
| Front track | 1491 mm 58.7 in. |
| Rear (Back) track | 1491 mm 58.7 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Spring Strut |
| Rear suspension | Transverse stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 215/55 R16 |
| Wheel rims size | 6.5J X 16 |
| What is the body type, Chevrolet HHR? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Chevrolet HHR 2.4 i 16V (175 Hp) Automatic? | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| How much power, Chevrolet HHR Station wagon (estate) 2005 2.4 i 16V (175 Hp) Automatic? | 175 Hp, 228 Nm 168.16 lb.-ft. |
| What is the engine size, Chevrolet HHR Station wagon (estate) 2005 2.4 i 16V (175 Hp) Automatic? | 2.4 l 2384 cm3 145.48 cu. in. |
| How many cylinders, 2005 Chevrolet 2.4 i 16V (175 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Chevrolet HHR Station wagon (estate) 2005 2.4 i 16V (175 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2005 Chevrolet HHR Station wagon (estate)? | 4475 mm 176.18 in. |
| How wide is the vehicle, 2005 Chevrolet HHR Station wagon (estate)? | 1755 mm 69.09 in. |
| What is the curb weight, 2005 Chevrolet HHR 2.4 i 16V (175 Hp) Automatic? | 1455 kg 3207.73 lbs. |
| How much trunk (boot) space, 2005 Chevrolet HHR Station wagon (estate)? | 638 – 1785 l 22.53 – 63.04 cu. ft. |
| How many gears, What type is the gearbox, 2005 Chevrolet HHR 2.4 i 16V (175 Hp) Automatic? | 4, automatic transmission |
