The Chevrolet Orlando 1.4 turbo, produced from 2011 to 2018, represented Chevrolet’s entry into the compact minivan segment, primarily aimed at the European and Asian markets. Positioned as a practical and affordable seven-seater, the 1.4 turbo variant offered a balance between fuel efficiency and acceptable performance. It sat in the middle of the Orlando lineup, offering a step up from the base 1.8L engine while remaining more accessible than the 2.0L diesel options. This model year was part of the first generation Orlando (Orlando I), built on the GM Delta platform, shared with models like the Opel Astra and Buick Verano.
Technical Specifications
| Brand | Chevrolet |
| Model | Orlando |
| Generation | Orlando I |
| Type (Engine) | 1.4 turbo (140 Hp) |
| Start of production | 2011 |
| End of production | 2018 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Fuel consumption (urban) | 8.1 l/100 km (29 US mpg) |
| Fuel consumption (extra urban) | 5.5 l/100 km (42.8 US mpg) |
| Fuel consumption (combined) | 6.4 l/100 km (36.8 US mpg) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 11 sec |
| Acceleration 0 – 62 mph | 11 sec |
| Acceleration 0 – 60 mph | 10.5 sec |
| Maximum speed | 200 km/h (124.27 mph) |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 11 kg/Hp |
| Weight-to-torque ratio | 7.7 kg/Nm |
| Power | 140 Hp @ 4900 rpm |
| Torque | 200 Nm @ 1850 rpm (147.51 lb.-ft. @ 1850 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | LUJ |
| Engine displacement | 1362 cm3 (83.11 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 72.5 mm (2.85 in.) |
| Piston Stroke | 82.5 mm (3.25 in.) |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4 l (4.23 US qt | 3.52 UK qt) |
| Coolant capacity | 6.2 l (6.55 US qt | 5.46 UK qt) |
| Kerb Weight | 1539 kg (3392.91 lbs.) |
| Max. weight | 2179 kg (4803.87 lbs.) |
| Max load | 640 kg (1410.96 lbs.) |
| Trunk (boot) space – minimum | 101 l (3.57 cu. ft.) |
| Trunk (boot) space – maximum | 466 l (16.46 cu. ft.) |
| Fuel tank capacity | 60 l (15.85 US gal | 13.2 UK gal) |
| Length | 4652 mm (183.15 in.) |
| Width | 1836 mm (72.28 in.) |
| Height | 1633 mm (64.29 in.) |
| Wheelbase | 2760 mm (108.66 in.) |
| Front track | 1584 mm (62.36 in.) |
| Rear track | 1588 mm (62.52 in.) |
| Minimum turning circle | 11.3 m (37.07 ft.) |
| Drivetrain | Front wheel drive |
| Number of gears | 6 |
| Gearbox type | Manual transmission |
| Front suspension | Independent type McPherson |
| Front brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric |
Powertrain & Engine Architecture
The heart of the Orlando 1.4 turbo is the LUJ engine, a 1.4-liter inline-four cylinder gasoline engine. This engine is part of GM’s Family 0 small engine family, known for its compact size and efficiency. The LUJ features multi-point fuel injection and a single scroll turbocharger with an intercooler, boosting power output to 140 horsepower at 4900 rpm and 200 Nm (147.5 lb-ft) of torque at 1850 rpm. The engine utilizes a double overhead camshaft (DOHC) valvetrain with four valves per cylinder, contributing to its relatively high power density. The six-speed manual transmission was standard, providing a good balance between fuel economy and driver control. While an automatic transmission was offered in some markets, it wasn’t as commonly paired with the 1.4 turbo as it was with the 1.8L engine.
Driving Characteristics
The Orlando 1.4 turbo offered a noticeable improvement in performance over the base 1.8L model. While not a sports car, the turbocharger provided a useful boost in acceleration, making highway merging and overtaking maneuvers more confident. The 0-60 mph time of around 10.5 seconds was respectable for a seven-seater minivan. The six-speed manual transmission allowed drivers to keep the engine in its optimal power band, maximizing efficiency and responsiveness. Compared to the 2.0L diesel variants, the 1.4 turbo felt less powerful, particularly when fully loaded with passengers and luggage. However, it offered a smoother and quieter driving experience, with less engine vibration. The gear ratios were tuned for a balance of acceleration and fuel economy, with a relatively tall sixth gear for relaxed cruising.
Equipment & Trim Levels
The 1.4 turbo trim typically included features such as air conditioning, power windows, power mirrors, a basic audio system with USB connectivity, and standard safety equipment like ABS and airbags. Higher trim levels added features like alloy wheels, fog lights, a more advanced audio system with Bluetooth connectivity, and rear parking sensors. Interior upholstery was typically cloth, with optional leather seats available on higher trims. The dashboard layout was functional and straightforward, with a focus on practicality rather than luxury. Optional extras included a sunroof, navigation system, and a rear-seat entertainment system.
Chassis & Braking
The Orlando’s chassis featured an independent McPherson strut suspension at the front and a semi-independent torsion beam suspension at the rear. This setup provided a comfortable ride quality, although it wasn’t particularly sporty. The front brakes were ventilated discs, while the rear brakes were typically drum brakes, a cost-saving measure for this trim level. The electric power steering offered light and easy steering, making it convenient for city driving. Stabilizer bars were fitted to both the front and rear axles to reduce body roll during cornering.
Market Reception & Comparison
The Chevrolet Orlando 1.4 turbo was generally well-received by critics as a practical and affordable family vehicle. It was praised for its spacious interior, comfortable ride, and decent fuel economy. However, some reviewers criticized its somewhat bland styling and lack of refinement compared to more premium competitors. Compared to the 1.8L version, the 1.4 turbo offered a significant performance upgrade, making it a more appealing option for drivers who frequently carried passengers or drove on highways. The 2.0L diesel models offered even better fuel economy and torque, but at a higher price point. The Orlando competed with other compact minivans like the Opel Zafira, Renault Scenic, and Citroen C4 Picasso.
Legacy
The Chevrolet Orlando, including the 1.4 turbo variant, has proven to be a relatively reliable vehicle in the used car market. The LUJ engine is generally considered to be durable, although regular maintenance is essential to prevent issues with the turbocharger and fuel injectors. Common issues reported by owners include occasional problems with the electric power steering and the air conditioning system. Today, the Orlando 1.4 turbo represents a budget-friendly option for families seeking a spacious and practical seven-seater. Its combination of affordability, fuel efficiency, and decent performance continues to make it a viable choice in the used car market.
