| General information | |
|---|---|
| Brand | Chevrolet |
| Model | Orlando |
| Generation | Orlando I |
| Type (Engine) | 2.0 TD (163 Hp) |
| Start of production | 2011 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 7.9 l/100 km 29.8 US mpg 35.8 UK mpg 12.7 km/l |
| Fuel consumption (economy) – extra urban | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| Fuel consumption (economy) – combined | 6 l/100 km 39.2 US mpg 47.1 UK mpg 16.7 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 10.3 sec |
| Acceleration 0 – 62 mph | 10.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.8 sec |
| Maximum speed | 180 km/h 111.85 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 10.2 kg/Hp, 98.5 Hp/tonne |
| Weight-to-torque ratio | 5.3 kg/Nm, 190.3 Nm/tonne |
| Engine specs | |
| Power | 163 Hp @ 3800 rpm. |
| Power per litre | 81.6 Hp/l |
| Torque | 315 Nm @ 2000 rpm. 232.33 lb.-ft. @ 2000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | LNP |
| Engine displacement | 1998 cm3 121.93 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm 3.39 in. |
| Piston Stroke | 86 mm 3.39 in. |
| Compression ratio | 16.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.6 l 5.92 US qt | 4.93 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.5 l 7.93 US qt | 6.6 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1655 kg 3648.65 lbs. |
| Max. weight | 2287 kg 5041.97 lbs. |
| Max load | 632 kg 1393.32 lbs. |
| Trunk (boot) space – minimum | 89 l 3.14 cu. ft. |
| Trunk (boot) space – maximum | 458 l 16.17 cu. ft. |
| Fuel tank capacity | 64 l 16.91 US gal | 14.08 UK gal |
| Dimensions | |
| Length | 4652 mm 183.15 in. |
| Width | 1836 mm 72.28 in. |
| Height | 1633 mm 64.29 in. |
| Wheelbase | 2760 mm 108.66 in. |
| Front track | 1584 mm 62.36 in. |
| Rear (Back) track | 1588 mm 62.52 in. |
| Minimum turning circle (turning diameter) | 11.3 m 37.07 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 215/R60 R16 |
| Wheel rims size | 16 |
| What is the body type, Chevrolet Orlando I? | Minivan, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Chevrolet Orlando I 2.0 TD (163 Hp)? | 6 l/100 km 39.2 US mpg 47.1 UK mpg 16.7 km/l |
| How ECO is the car, Chevrolet Orlando 2.0 TD (163 Hp)? | Euro 5 |
| How fast is the car, 2011 Orlando I 2.0 TD (163 Hp)? | 180 km/h | 111.85 mph 0-100 km/h: 10.3 sec 0-60 mph: 9.8 sec |
| How much power, Chevrolet Orlando Minivan 2011 2.0 TD (163 Hp)? | 163 Hp, 315 Nm 232.33 lb.-ft. |
| What is the engine size, Chevrolet Orlando Minivan 2011 2.0 TD (163 Hp)? | 2.0 l 1998 cm3 121.93 cu. in. |
| How many cylinders, 2011 Chevrolet 2.0 TD (163 Hp)? | 4, Inline |
| What is the drivetrain, Chevrolet Orlando I Minivan 2011 2.0 TD (163 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2011 Chevrolet Orlando Minivan? | 4652 mm 183.15 in. |
| How wide is the vehicle, 2011 Chevrolet Orlando Minivan? | 1836 mm 72.28 in. |
| What is the curb weight, 2011 Chevrolet Orlando I 2.0 TD (163 Hp)? | 1655 kg 3648.65 lbs. |
| What is the gross weight, 2011 Chevrolet Orlando I 2.0 TD (163 Hp)? | 2287 kg 5041.97 lbs. |
| How much trunk (boot) space, 2011 Chevrolet Orlando Minivan? | 89 – 458 l 3.14 – 16.17 cu. ft. |
| How many gears, What type is the gearbox, 2011 Chevrolet Orlando I 2.0 TD (163 Hp)? | 6, manual transmission |
