The Chevrolet Zafira 2.0 8V (116 hp) was a popular iteration of the first-generation Zafira, produced from 2001 to 2012. Positioned as a mid-range offering within the Zafira lineup, it provided a balance between affordability, practicality, and performance for families. This variant played a significant role in establishing the Zafira as a leading compact minivan in European markets, and later, in select regions globally. It was part of the larger GM/Opel platform strategy, sharing components with other models like the Opel/Vauxhall Astra G and H.
Technical Specifications
| Brand | Chevrolet |
| Model | Zafira |
| Generation | Zafira (First Generation) |
| Type (Engine) | 2.0 8V (116 Hp) |
| Start of production | 2001 |
| End of production | 2012 |
| Powertrain Architecture | Internal Combustion Engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Fuel consumption (urban) | 10.7 l/100 km (22 US mpg, 26.4 UK mpg, 9.3 km/l) |
| Fuel consumption (extra urban) | 7.6 l/100 km (30.9 US mpg, 37.2 UK mpg, 13.2 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 12.4 sec |
| Acceleration 0 – 62 mph | 12.4 sec |
| Acceleration 0 – 60 mph | 11.8 sec |
| Maximum speed | 178 km/h (110.6 mph) |
| Weight-to-power ratio | 11.6 kg/Hp, 85.9 Hp/tonne |
| Weight-to-torque ratio | 7.9 kg/Nm, 125.9 Nm/tonne |
| Power | 116 Hp @ 5200 rpm |
| Power per litre | 58.1 Hp/l |
| Torque | 170 Nm @ 2400 rpm (125.39 lb.-ft. @ 2400 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | C20NE |
| Engine displacement | 1998 cm3 (121.93 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm (3.39 in.) |
| Piston Stroke | 86 mm (3.39 in.) |
| Compression ratio | 9.8:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated |
| Valvetrain | OHC |
| Engine oil capacity | 4 l (4.23 US qt | 3.52 UK qt) |
| Kerb Weight | 1350 kg (2976.24 lbs.) |
| Max. weight | 1950 kg (4299.01 lbs.) |
| Max load | 600 kg (1322.77 lbs.) |
| Fuel tank capacity | 58 l (15.32 US gal | 12.76 UK gal) |
| Width | 1740 mm (68.5 in.) |
| Height | 1650 mm (64.96 in.) |
| Wheelbase | 2705 mm (106.5 in.) |
| Front track | 1470 mm (57.87 in.) |
| Rear track | 1485 mm (58.46 in.) |
| Drivetrain Architecture | Front-wheel drive, Internal Combustion Engine |
| Drive wheel | Front wheel drive |
| Number of gears | 5 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Trailing arm |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/65 R15 |
Introduction
The Chevrolet Zafira 2.0 8V (116 hp) represented a significant step forward for Chevrolet in the European minivan segment. Introduced as part of the first-generation Zafira (1999-2005), this variant offered a larger engine option compared to the base 1.6L models, appealing to buyers needing more power for highway driving and fully loaded vehicles. The Zafira was notable for its innovative Versatile Seating System (VSS), allowing for flexible seating configurations and transforming the vehicle from a seven-seater to a spacious cargo carrier. This 2.0L version aimed to provide a more refined driving experience without the higher cost of the later, more powerful engines.
Powertrain & Engine Architecture
The heart of the Zafira 2.0 8V is the C20NE engine, a 1998cc inline-four cylinder gasoline engine. This engine utilizes a two-valve-per-cylinder (8V) single overhead camshaft (SOHC) configuration. Fuel delivery is managed by a multi-port fuel injection system, providing a balance between efficiency and performance. The C20NE is a relatively simple and robust engine design, known for its durability. The engine’s 9.8:1 compression ratio contributes to its moderate power output. The five-speed manual transmission was the standard offering for this variant, providing adequate gear ratios for everyday driving. The transmission is a conventional setup, prioritizing reliability and ease of maintenance.
Driving Characteristics
The Zafira 2.0 8V offered a noticeable improvement in performance over the 1.6L models. While not a sports car, the 116 hp engine provided sufficient power for comfortable highway cruising and overtaking maneuvers, even with a full load of passengers and luggage. Acceleration from 0-60 mph took around 11.8 seconds, which was competitive for its class at the time. The five-speed manual transmission allowed drivers to effectively utilize the engine’s torque, although the gear ratios were spaced to prioritize fuel economy rather than outright acceleration. The suspension provided a comfortable ride, absorbing bumps and imperfections in the road well, making it suitable for long journeys.
Equipment & Trim Levels
The 2.0 8V Zafira typically came with a reasonable level of standard equipment. This included power steering, central locking, electric front windows, and an adjustable steering column. Interior upholstery was typically cloth, with a functional and durable design. Optional extras included air conditioning, alloy wheels, a CD player, and rear electric windows. Higher trim levels offered additional features such as upgraded interior trim, fog lights, and a trip computer. The Zafira’s interior was designed with practicality in mind, offering ample storage space and a user-friendly layout.
Chassis & Braking
The Zafira 2.0 8V utilized a front-wheel-drive layout with a MacPherson strut suspension at the front and a trailing arm suspension at the rear. This setup provided a good balance between ride comfort and handling. The braking system consisted of ventilated discs at the front and solid discs at the rear, providing adequate stopping power for the vehicle’s weight. Anti-lock Braking System (ABS) was standard, enhancing safety during emergency braking situations. The steering was rack and pinion, offering precise and responsive control.
Market Reception & Comparison
The Chevrolet Zafira 2.0 8V was generally well-received by automotive critics. It was praised for its spacious interior, versatile seating system, and comfortable ride. The 2.0L engine was considered a good compromise between performance and fuel economy. Compared to the base 1.6L model, the 2.0L offered a significant improvement in power and drivability, making it a more suitable choice for families who frequently travel long distances or carry heavy loads. However, it wasn’t as sporty or refined as some of its competitors, such as the Renault Scenic or the Volkswagen Touran. Fuel economy was respectable, averaging around 22 mpg in urban driving and 31 mpg on the highway.
Legacy
The Chevrolet Zafira 2.0 8V has proven to be a relatively reliable vehicle, with the C20NE engine being known for its durability. Common issues include minor oil leaks and occasional sensor failures, but these are generally inexpensive to repair. Today, the Zafira 2.0 8V can be found on the used car market at affordable prices. It remains a practical and versatile option for families on a budget. While it may not have the modern features of newer minivans, its spacious interior, flexible seating, and reliable engine make it a worthwhile consideration for those seeking a functional and affordable people carrier.
