| General information | |
|---|---|
| Brand | Chrysler |
| Model | Voyager |
| Generation | Grand Voyager II |
| Type (Engine) | 3.3 V6 (163 Hp) |
| Start of production | 1990 year |
| End of production | 1995 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 3 |
| Performance specs | |
| Fuel consumption (economy) – combined | 11 l/100 km 21.4 US mpg 25.7 UK mpg 9.1 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 12.9 sec |
| Acceleration 0 – 62 mph | 12.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 12.3 sec |
| Maximum speed | 180 km/h 111.85 mph |
| Weight-to-power ratio | 10.8 kg/Hp, 92.6 Hp/tonne |
| Weight-to-torque ratio | 6.8 kg/Nm, 147.7 Nm/tonne |
| Engine specs | |
| Power | 163 Hp @ 4800 rpm. |
| Power per litre | 49.4 Hp/l |
| Torque | 260 Nm @ 3750 rpm. 191.77 lb.-ft. @ 3750 rpm. |
| Engine layout | Front, Transverse |
| Engine displacement | 3301 cm3 201.44 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 93 mm 3.66 in. |
| Piston Stroke | 81 mm 3.19 in. |
| Compression ratio | 8.9:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9.5 l 10.04 US qt | 8.36 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1760 kg 3880.14 lbs. |
| Max. weight | 2550 kg 5621.79 lbs. |
| Max load | 790 kg 1741.65 lbs. |
| Trunk (boot) space – minimum | 328 l 11.58 cu. ft. |
| Trunk (boot) space – maximum | 3990 l 140.91 cu. ft. |
| Fuel tank capacity | 76 l 20.08 US gal | 16.72 UK gal |
| Dimensions | |
| Length | 4896 mm 192.76 in. |
| Width | 1830 mm 72.05 in. |
| Height | 1707 mm 67.2 in. |
| Wheelbase | 3031 mm 119.33 in. |
| Front track | 1522 mm 59.92 in. |
| Rear (Back) track | 1578 mm 62.13 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Wishbone |
| Rear suspension | Rigid axle suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/70 R15 |
| What is the body type, Chrysler Grand Voyager II? | Minivan, 3 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Chrysler Grand Voyager II 3.3 V6 (163 Hp)? | 11 l/100 km 21.4 US mpg 25.7 UK mpg 9.1 km/l |
| How fast is the car, 1990 Grand Voyager II 3.3 V6 (163 Hp)? | 180 km/h | 111.85 mph 0-100 km/h: 12.9 sec 0-60 mph: 12.3 sec |
| How much power, Chrysler Voyager Minivan 1990 3.3 V6 (163 Hp)? | 163 Hp, 260 Nm 191.77 lb.-ft. |
| What is the engine size, Chrysler Voyager Minivan 1990 3.3 V6 (163 Hp)? | 3.3 l 3301 cm3 201.44 cu. in. |
| How many cylinders, 1990 Chrysler 3.3 V6 (163 Hp)? | 6, V-engine |
| What is the drivetrain, Chrysler Grand Voyager II Minivan 1990 3.3 V6 (163 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 1990 Chrysler Voyager Minivan? | 4896 mm 192.76 in. |
| How wide is the vehicle, 1990 Chrysler Voyager Minivan? | 1830 mm 72.05 in. |
| What is the curb weight, 1990 Chrysler Grand Voyager II 3.3 V6 (163 Hp)? | 1760 kg 3880.14 lbs. |
| What is the gross weight, 1990 Chrysler Grand Voyager II 3.3 V6 (163 Hp)? | 2550 kg 5621.79 lbs. |
| How much trunk (boot) space, 1990 Chrysler Voyager Minivan? | 328 – 3990 l 11.58 – 140.91 cu. ft. |
| How many gears, What type is the gearbox, 1990 Chrysler Grand Voyager II 3.3 V6 (163 Hp)? | 4, automatic transmission |
