| General information | |
|---|---|
| Brand | Chrysler |
| Model | Pacifica (minivan) |
| Generation | Pacifica (facelift 2021) |
| Type (Engine) | 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT |
| Start of production | 2021 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – combined (EPA) | 2.9 l/100 km 81.1 US mpg 97.4 UK mpg 34.5 km/l |
| Fuel Type | Petrol / electricity |
| Weight-to-power ratio | 8.6 kg/Hp, 116.1 Hp/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 16 kWh |
| Battery voltage | 360 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor, under the rear seats |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 86 Hp |
| Electric motor location | Integrated into the transmission |
| Electric motor 2 | |
| Electric motor power | 116 Hp |
| Electric motor location | Integrated into the transmission |
| System power | 264 Hp |
| Internal combustion engine specs | |
| Engine layout | Front, Transverse |
| Engine Model/Code | Pentastar |
| Engine displacement | 3605 cm3 219.99 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 96 mm 3.78 in. |
| Piston Stroke | 83 mm 3.27 in. |
| Compression ratio | 12.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | CVVT |
| Engine oil capacity | 4.7 l 4.97 US qt | 4.14 UK qt |
| Engine oil specification | Log in to see. |
| Coolant | 13.7 l 14.48 US qt | 12.05 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2273 kg 5011.11 lbs. |
| Max. weight | 2858 kg 6300.81 lbs. |
| Max load | 585 kg 1289.7 lbs. |
| Trunk (boot) space – minimum | 915 l 32.31 cu. ft. |
| Trunk (boot) space – maximum | 3979 l 140.52 cu. ft. |
| Fuel tank capacity | 62.5 l 16.51 US gal | 13.75 UK gal |
| Dimensions | |
| Length | 5189 mm 204.29 in. |
| Width | 2022 mm 79.61 in. |
| Width including mirrors | 2297 mm 90.43 in. |
| Height | 1777 mm 69.96 in. |
| Wheelbase | 3089 mm 121.61 in. |
| Front track | 1734 mm 68.27 in. |
| Rear (Back) track | 1735 mm 68.31 in. |
| Front overhang | 972 mm 38.27 in. |
| Rear overhang | 1127 mm 44.37 in. |
| Ride height (ground clearance) | 130 mm 5.12 in. |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Approach angle | 13.5° |
| Departure angle | 18.6° |
| Ramp-over (brakeover) angle | 12.3° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. Two electric motors drive the front wheels. There is an ability for running in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | automatic transmission eFlite EVT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent coil spring |
| Front brakes | Ventilated discs, 330×28 mm |
| Rear brakes | Disc, 330×12 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/65 R17; 235/60 R18 |
| Wheel rims size | 7J x 17; 7.5J x 18 |
| What is the body type, Chrysler Pacifica (facelift 2021)? | Minivan, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Chrysler Pacifica (facelift 2021) 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | 2.9 l/100 km 81.1 US mpg 97.4 UK mpg 34.5 km/l |
| How much power, Chrysler Pacifica (minivan) Minivan 2021 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | 264 Hp |
| What is the engine size, Chrysler Pacifica (minivan) Minivan 2021 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | 3.6 l 3605 cm3 219.99 cu. in. |
| How many cylinders, 2021 Chrysler 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | 6, V-engine |
| What is the drivetrain, Chrysler Pacifica (facelift 2021) Minivan 2021 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) drives the front wheels of the vehicle. Two electric motors drive the front wheels. There is an ability for running in full electric or mixed mode. |
| How long is this vehicle, 2021 Chrysler Pacifica (minivan) Minivan? | 5189 mm 204.29 in. |
| How wide is the vehicle, 2021 Chrysler Pacifica (minivan) Minivan? | 2022 mm 79.61 in. |
| What is the curb weight, 2021 Chrysler Pacifica (facelift 2021) 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | 2273 kg 5011.11 lbs. |
| What is the gross weight, 2021 Chrysler Pacifica (facelift 2021) 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | 2858 kg 6300.81 lbs. |
| How much trunk (boot) space, 2021 Chrysler Pacifica (minivan) Minivan? | 915 – 3979 l 32.31 – 140.52 cu. ft. |
| How many gears, What type is the gearbox, 2021 Chrysler Pacifica (facelift 2021) 3.6 Pentastar V6 (264 Hp) Plug-in Hybrid EVT? | automatic transmission eFlite EVT |
