| General information | |
|---|---|
| Brand | Chrysler |
| Model | Voyager |
| Generation | Voyager VI |
| Type (Engine) | 3.6 Pentastar V6 (291 Hp) TorqueFlite |
| Start of production | September, 2024 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (EPA) | 12.4 l/100 km 19 US mpg 22.8 UK mpg 8.1 km/l |
| Fuel consumption (economy) – extra urban (EPA) | 8.4 l/100 km 28 US mpg 33.6 UK mpg 11.9 km/l |
| Fuel consumption (economy) – combined (EPA) | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 6.7 kg/Hp, 148.2 Hp/tonne |
| Weight-to-torque ratio | 5.5 kg/Nm, 180.8 Nm/tonne |
| Engine specs | |
| Power | 291 Hp @ 6400 rpm. |
| Power per litre | 80.7 Hp/l |
| Torque | 355 Nm @ 4000 rpm. 261.83 lb.-ft. @ 4000 rpm. |
| Maximum engine speed | 6400 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | Pentastar / ERC |
| Engine displacement | 3605 cm3 219.99 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 96 mm 3.78 in. |
| Piston Stroke | 83 mm 3.27 in. |
| Compression ratio | 11.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, CVVT |
| Engine oil capacity | 4.7 l 4.97 US qt | 4.14 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 12.4 l 13.1 US qt | 10.91 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1964 kg 4329.88 lbs. |
| Max. weight | 2747 kg 6056.1 lbs. |
| Max load | 783 kg 1726.22 lbs. |
| Trunk (boot) space – minimum | 915 l 32.31 cu. ft. |
| Trunk (boot) space – maximum | 3979 l 140.52 cu. ft. |
| Fuel tank capacity | 72 l 19.02 US gal | 15.84 UK gal |
| Dimensions | |
| Length | 5176 mm 203.78 in. |
| Width | 2022 mm 79.61 in. |
| Width including mirrors | 2297 mm 90.43 in. |
| Height | 1777 mm 69.96 in. |
| Wheelbase | 3089 mm 121.61 in. |
| Front track | 1735 mm 68.31 in. |
| Rear (Back) track | 1736 mm 68.35 in. |
| Front overhang | 960 mm 37.8 in. |
| Rear overhang | 1127 mm 44.37 in. |
| Ride height (ground clearance) | 131 mm 5.16 in. |
| Drag coefficient (Cd) | 0.300 |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Approach angle | 14° |
| Departure angle | 18.7° |
| Ramp-over (brakeover) angle | 12.5° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 9 gears, automatic transmission TorqueFlite |
| Front suspension | Spring Strut, Independent type McPherson, Transverse stabilizer |
| Rear suspension | Spring Strut, Coil spring, Torsion |
| Front brakes | Ventilated discs, 330×28 mm |
| Rear brakes | Disc, 320×12 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/65 R17 |
| Wheel rims size | 7J x 17 |
| What is the body type, Chrysler Voyager VI? | Minivan, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Chrysler Voyager VI 3.6 Pentastar V6 (291 Hp) TorqueFlite? | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| How much power, Chrysler Voyager Minivan 2024 3.6 Pentastar V6 (291 Hp) TorqueFlite? | 291 Hp, 355 Nm 261.83 lb.-ft. |
| What is the engine size, Chrysler Voyager Minivan 2024 3.6 Pentastar V6 (291 Hp) TorqueFlite? | 3.6 l 3605 cm3 219.99 cu. in. |
| How many cylinders, 2024 Chrysler 3.6 Pentastar V6 (291 Hp) TorqueFlite? | 6, V-engine |
| What is the drivetrain, Chrysler Voyager VI Minivan 2024 3.6 Pentastar V6 (291 Hp) TorqueFlite? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2024 Chrysler Voyager Minivan? | 5176 mm 203.78 in. |
| How wide is the vehicle, 2024 Chrysler Voyager Minivan? | 2022 mm 79.61 in. |
| What is the curb weight, 2024 Chrysler Voyager VI 3.6 Pentastar V6 (291 Hp) TorqueFlite? | 1964 kg 4329.88 lbs. |
| What is the gross weight, 2024 Chrysler Voyager VI 3.6 Pentastar V6 (291 Hp) TorqueFlite? | 2747 kg 6056.1 lbs. |
| How much trunk (boot) space, 2024 Chrysler Voyager Minivan? | 915 – 3979 l 32.31 – 140.52 cu. ft. |
| How many gears, What type is the gearbox, 2024 Chrysler Voyager VI 3.6 Pentastar V6 (291 Hp) TorqueFlite? | 9, automatic transmission TorqueFlite |
