| General information | |
|---|---|
| Brand | Citroen |
| Model | C3 |
| Generation | C3 I Picasso (Phase II, 2013) |
| Type (Engine) | 1.6 e-HDi (92 Hp) EGS |
| Start of production | 2013 year |
| End of production | 2015 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate), MPV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 4.7 l/100 km 50 US mpg 60.1 UK mpg 21.3 km/l |
| Fuel consumption (economy) – extra urban | 3.8 l/100 km 61.9 US mpg 74.3 UK mpg 26.3 km/l |
| Fuel consumption (economy) – combined | 4.2 l/100 km 56 US mpg 67.3 UK mpg 23.8 km/l |
| CO2 emissions | 109 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 14.5 sec |
| Acceleration 0 – 62 mph | 14.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 13.8 sec |
| Maximum speed | 177 km/h 109.98 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 13.4 kg/Hp, 74.5 Hp/tonne |
| Weight-to-torque ratio | 5.4 kg/Nm, 186.2 Nm/tonne |
| Engine specs | |
| Power | 92 Hp @ 4000 rpm. |
| Power per litre | 59 Hp/l |
| Torque | 230 Nm @ 1750 rpm. 169.64 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 9HP DV6DTED |
| Engine displacement | 1560 cm3 95.2 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Compression ratio | 18:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.75 l 3.96 US qt | 3.3 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.8 l 7.19 US qt | 5.98 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1235 kg 2722.71 lbs. |
| Max. weight | 1811 kg 3992.57 lbs. |
| Max load | 576 kg 1269.86 lbs. |
| Trunk (boot) space – minimum | 385 l 13.6 cu. ft. |
| Trunk (boot) space – maximum | 1506 l 53.18 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Max. roof load | 60 kg 132.28 lbs. |
| Permitted trailer load with brakes (8%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 675 kg 1488.12 lbs. |
| Permitted towbar download | 54 kg 119.05 lbs. |
| Dimensions | |
| Length | 4078 mm 160.55 in. |
| Width | 1766 mm 69.53 in. |
| Width including mirrors | 2050 mm 80.71 in. |
| Height | 1631-1670 mm 64.21 – 65.75 in. |
| Wheelbase | 2540 mm 100 in. |
| Front track | 1472 mm 57.95 in. |
| Rear (Back) track | 1470 mm 57.87 in. |
| Front overhang | 834 mm 32.83 in. |
| Rear overhang | 704 mm 27.72 in. |
| Drag coefficient (Cd) | 0.308 |
| Minimum turning circle (turning diameter) | 10.6 m 34.78 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission EGS |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 195/55 R16 |
| Wheel rims size | 16 |
| What is the body type, Citroen C3 I Picasso (Phase II, 2013)? | Station wagon (estate), MPV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Citroen C3 I Picasso (Phase II, 2013) 1.6 e-HDi (92 Hp) EGS? | 4.2 l/100 km 56 US mpg 67.3 UK mpg 23.8 km/l |
| How ECO is the car, Citroen C3 1.6 e-HDi (92 Hp) EGS? | 109 g/km CO2 Euro 5 |
| How fast is the car, 2013 C3 I Picasso (Phase II, 2013) 1.6 e-HDi (92 Hp) EGS? | 177 km/h | 109.98 mph 0-100 km/h: 14.5 sec 0-60 mph: 13.8 sec |
| How much power, Citroen C3 Station wagon (estate), MPV 2013 1.6 e-HDi (92 Hp) EGS? | 92 Hp, 230 Nm 169.64 lb.-ft. |
| What is the engine size, Citroen C3 Station wagon (estate), MPV 2013 1.6 e-HDi (92 Hp) EGS? | 1.6 l 1560 cm3 95.2 cu. in. |
| How many cylinders, 2013 Citroen 1.6 e-HDi (92 Hp) EGS? | 4, Inline |
| What is the drivetrain, Citroen C3 I Picasso (Phase II, 2013) Station wagon (estate), MPV 2013 1.6 e-HDi (92 Hp) EGS? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2013 Citroen C3 Station wagon (estate), MPV? | 4078 mm 160.55 in. |
| How wide is the vehicle, 2013 Citroen C3 Station wagon (estate), MPV? | 1766 mm 69.53 in. |
| What is the curb weight, 2013 Citroen C3 I Picasso (Phase II, 2013) 1.6 e-HDi (92 Hp) EGS? | 1235 kg 2722.71 lbs. |
| What is the gross weight, 2013 Citroen C3 I Picasso (Phase II, 2013) 1.6 e-HDi (92 Hp) EGS? | 1811 kg 3992.57 lbs. |
| How much trunk (boot) space, 2013 Citroen C3 Station wagon (estate), MPV? | 385 – 1506 l 13.6 – 53.18 cu. ft. |
| How many gears, What type is the gearbox, 2013 Citroen C3 I Picasso (Phase II, 2013) 1.6 e-HDi (92 Hp) EGS? | 6, automatic transmission EGS |
