| General information | |
|---|---|
| Brand | Citroen |
| Model | C3 |
| Generation | C3 II (Phase I, 2009) |
| Type (Engine) | 1.4 e-HDi (68 Hp) EGS |
| Start of production | 2011 year |
| End of production | 2013 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 3.6 l/100 km 65.3 US mpg 78.5 UK mpg 27.8 km/l |
| Fuel consumption (economy) – extra urban | 3.2 l/100 km 73.5 US mpg 88.3 UK mpg 31.3 km/l |
| Fuel consumption (economy) – combined | 3.4 l/100 km 69.2 US mpg 83.1 UK mpg 29.4 km/l |
| CO2 emissions | 87 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 16.2 sec |
| Acceleration 0 – 62 mph | 16.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 15.4 sec |
| Maximum speed | 165 km/h 102.53 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 16.8 kg/Hp, 59.4 Hp/tonne |
| Weight-to-torque ratio | 7.2 kg/Nm, 139.7 Nm/tonne |
| Engine specs | |
| Power | 68 Hp @ 4000 rpm. |
| Power per litre | 48.6 Hp/l |
| Torque | 160 Nm @ 1750 rpm. 118.01 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 8HZ DV4TD |
| Engine displacement | 1398 cm3 85.31 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 73.7 mm 2.9 in. |
| Piston Stroke | 82 mm 3.23 in. |
| Compression ratio | 17.9:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.8 l 4.02 US qt | 3.34 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.7 l 6.02 US qt | 5.02 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1145 kg 2524.29 lbs. |
| Max. weight | 1610 kg 3549.44 lbs. |
| Max load | 465 kg 1025.15 lbs. |
| Trunk (boot) space – minimum | 300 l 10.59 cu. ft. |
| Fuel tank capacity | 48 l 12.68 US gal | 10.56 UK gal |
| Permitted trailer load with brakes (12%) | 950 kg 2094.39 lbs. |
| Permitted trailer load without brakes | 570 kg 1256.63 lbs. |
| Dimensions | |
| Length | 3941 mm 155.16 in. |
| Width | 1728 mm 68.03 in. |
| Height | 1524 mm 60 in. |
| Wheelbase | 2466 mm 97.09 in. |
| Front track | 1469 mm 57.83 in. |
| Rear (Back) track | 1440 mm 56.69 in. |
| Front overhang | 815 mm 32.09 in. |
| Rear overhang | 660 mm 25.98 in. |
| Drag coefficient (Cd) | 0.31 |
| Minimum turning circle (turning diameter) | 10.2 m 33.46 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, automatic transmission EGS |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 185/65 R15 |
| Wheel rims size | 15 |
| What is the body type, Citroen C3 II (Phase I, 2009)? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Citroen C3 II (Phase I, 2009) 1.4 e-HDi (68 Hp) EGS? | 3.4 l/100 km 69.2 US mpg 83.1 UK mpg 29.4 km/l |
| How ECO is the car, Citroen C3 1.4 e-HDi (68 Hp) EGS? | 87 g/km CO2 Euro 5 |
| How fast is the car, 2011 C3 II (Phase I, 2009) 1.4 e-HDi (68 Hp) EGS? | 165 km/h | 102.53 mph 0-100 km/h: 16.2 sec 0-60 mph: 15.4 sec |
| How much power, Citroen C3 Hatchback 2011 1.4 e-HDi (68 Hp) EGS? | 68 Hp, 160 Nm 118.01 lb.-ft. |
| What is the engine size, Citroen C3 Hatchback 2011 1.4 e-HDi (68 Hp) EGS? | 1.4 l 1398 cm3 85.31 cu. in. |
| How many cylinders, 2011 Citroen 1.4 e-HDi (68 Hp) EGS? | 4, Inline |
| What is the drivetrain, Citroen C3 II (Phase I, 2009) Hatchback 2011 1.4 e-HDi (68 Hp) EGS? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2011 Citroen C3 Hatchback? | 3941 mm 155.16 in. |
| How wide is the vehicle, 2011 Citroen C3 Hatchback? | 1728 mm 68.03 in. |
| What is the curb weight, 2011 Citroen C3 II (Phase I, 2009) 1.4 e-HDi (68 Hp) EGS? | 1145 kg 2524.29 lbs. |
| What is the gross weight, 2011 Citroen C3 II (Phase I, 2009) 1.4 e-HDi (68 Hp) EGS? | 1610 kg 3549.44 lbs. |
| How much trunk (boot) space, 2011 Citroen C3 Hatchback? | 300 l 10.59 cu. ft. |
| How many gears, What type is the gearbox, 2011 Citroen C3 II (Phase I, 2009) 1.4 e-HDi (68 Hp) EGS? | 5, automatic transmission EGS |
