| General information | |
|---|---|
| Brand | Citroen |
| Model | C4 |
| Generation | C4 II Grand Picasso (Phase II, 2016) |
| Type (Engine) | 1.6 BlueHDI (120 Hp) S&S |
| Start of production | 2016 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan, MPV |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 4.5-4.6 l/100 km 52.3 – 51.1 US mpg 62.8 – 61.4 UK mpg 22.2 – 21.7 km/l |
| Fuel consumption (economy) – extra urban | 3.7-3.8 l/100 km 63.6 – 61.9 US mpg 76.3 – 74.3 UK mpg 27 – 26.3 km/l |
| Fuel consumption (economy) – combined | 4 l/100 km 58.8 US mpg 70.6 UK mpg 25 km/l |
| CO2 emissions | 105-106 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 11.7 sec |
| Acceleration 0 – 62 mph | 11.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.1 sec |
| Maximum speed | 189 km/h 117.44 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 11.2 kg/Hp, 89.1 Hp/tonne |
| Weight-to-torque ratio | 4.5 kg/Nm, 222.7 Nm/tonne |
| Engine specs | |
| Power | 120 Hp @ 3500 rpm. |
| Power per litre | 76.9 Hp/l |
| Torque | 300 Nm @ 1750 rpm. 221.27 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | BHZ DV6FC |
| Engine displacement | 1560 cm3 95.2 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Compression ratio | 16:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.75 l 3.96 US qt | 3.3 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1347 kg 2969.63 lbs. |
| Max. weight | 2175 kg 4795.05 lbs. |
| Max load | 828 kg 1825.43 lbs. |
| Trunk (boot) space – minimum | 165 l 5.83 cu. ft. |
| Trunk (boot) space – maximum | 2181 l 77.02 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| AdBlue tank | 17 l 4.49 US gal | 3.74 UK gal |
| Max. roof load | 80 kg 176.37 lbs. |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 674 kg 1485.92 lbs. |
| Permitted towbar download | 70 kg 154.32 lbs. |
| Dimensions | |
| Length | 4602 mm 181.18 in. |
| Width | 1826 mm 71.89 in. |
| Width with mirrors folded | 1971 mm 77.6 in. |
| Width including mirrors | 2117 mm 83.35 in. |
| Height | 1638-1644 mm 64.49 – 64.72 in. |
| Wheelbase | 2840 mm 111.81 in. |
| Front track | 1573-1587 mm 61.93 – 62.48 in. |
| Rear (Back) track | 1576-1590 mm 62.05 – 62.6 in. |
| Front overhang | 889 mm 35 in. |
| Rear overhang | 873 mm 34.37 in. |
| Minimum turning circle (turning diameter) | 11.3 m 37.07 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/60 R16; 205/55 R17 |
| Wheel rims size | 16; 17 |
| What is the body type, Citroen C4 II Grand Picasso (Phase II, 2016)? | Minivan, MPV, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Citroen C4 II Grand Picasso (Phase II, 2016) 1.6 BlueHDI (120 Hp) S&S? | 4 l/100 km 58.8 US mpg 70.6 UK mpg 25 km/l |
| How ECO is the car, Citroen C4 1.6 BlueHDI (120 Hp) S&S? | 105-106 g/km CO2 Euro 6 |
| How fast is the car, 2016 C4 II Grand Picasso (Phase II, 2016) 1.6 BlueHDI (120 Hp) S&S? | 189 km/h | 117.44 mph 0-100 km/h: 11.7 sec 0-60 mph: 11.1 sec |
| How much power, Citroen C4 Minivan, MPV 2016 1.6 BlueHDI (120 Hp) S&S? | 120 Hp, 300 Nm 221.27 lb.-ft. |
| What is the engine size, Citroen C4 Minivan, MPV 2016 1.6 BlueHDI (120 Hp) S&S? | 1.6 l 1560 cm3 95.2 cu. in. |
| How many cylinders, 2016 Citroen 1.6 BlueHDI (120 Hp) S&S? | 4, Inline |
| What is the drivetrain, Citroen C4 II Grand Picasso (Phase II, 2016) Minivan, MPV 2016 1.6 BlueHDI (120 Hp) S&S? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2016 Citroen C4 Minivan, MPV? | 4602 mm 181.18 in. |
| How wide is the vehicle, 2016 Citroen C4 Minivan, MPV? | 1826 mm 71.89 in. |
| What is the curb weight, 2016 Citroen C4 II Grand Picasso (Phase II, 2016) 1.6 BlueHDI (120 Hp) S&S? | 1347 kg 2969.63 lbs. |
| What is the gross weight, 2016 Citroen C4 II Grand Picasso (Phase II, 2016) 1.6 BlueHDI (120 Hp) S&S? | 2175 kg 4795.05 lbs. |
| How much trunk (boot) space, 2016 Citroen C4 Minivan, MPV? | 165 – 2181 l 5.83 – 77.02 cu. ft. |
| How many gears, What type is the gearbox, 2016 Citroen C4 II Grand Picasso (Phase II, 2016) 1.6 BlueHDI (120 Hp) S&S? | 6, manual transmission |
