| General information | |
|---|---|
| Brand | Citroen |
| Model | C4 |
| Generation | C4 II Hatchback (Phase II, 2015) |
| Type (Engine) | 1.6 BlueHDi (120 Hp) S&S |
| Start of production | 2015 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 4.2-4.4 l/100 km 56 – 53.5 US mpg 67.3 – 64.2 UK mpg 23.8 – 22.7 km/l |
| Fuel consumption (economy) – extra urban | 3.3-3.5 l/100 km 71.3 – 67.2 US mpg 85.6 – 80.7 UK mpg 30.3 – 28.6 km/l |
| Fuel consumption (economy) – combined | 3.6-3.8 l/100 km 65.3 – 61.9 US mpg 78.5 – 74.3 UK mpg 27.8 – 26.3 km/l |
| CO2 emissions | 95-100 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 10.6-11.0 sec |
| Acceleration 0 – 62 mph | 10.6-11.0 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 10.1 sec |
| Maximum speed | 197 km/h 122.41 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 10.7 kg/Hp, 93.8 Hp/tonne |
| Weight-to-torque ratio | 4.3 kg/Nm, 234.4 Nm/tonne |
| Engine specs | |
| Power | 120 Hp @ 3500 rpm. |
| Power per litre | 76.9 Hp/l |
| Torque | 300 Nm @ 1750 rpm. 221.27 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | BHZ DV6FC |
| Engine displacement | 1560 cm3 95.2 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Compression ratio | 16:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.75 l 3.96 US qt | 3.3 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1280 kg 2821.92 lbs. |
| Max. weight | 1860 kg 4100.6 lbs. |
| Max load | 580 kg 1278.68 lbs. |
| Trunk (boot) space – minimum | 408 l 14.41 cu. ft. |
| Trunk (boot) space – maximum | 1183 l 41.78 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| AdBlue tank | 17 l 4.49 US gal | 3.74 UK gal |
| Max. roof load | 55 kg 121.25 lbs. |
| Permitted trailer load with brakes (12%) | 1550 kg 3417.17 lbs. |
| Permitted trailer load without brakes | 675 kg 1488.12 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4329 mm 170.43 in. |
| Width | 1789 mm 70.43 in. |
| Width including mirrors | 2050 mm 80.71 in. |
| Height | 1498-1502 mm 58.98 – 59.13 in. |
| Wheelbase | 2608 mm 102.68 in. |
| Front track | 1522-1536 mm 59.92 – 60.47 in. |
| Rear (Back) track | 1515-1529 mm 59.65 – 60.2 in. |
| Front overhang | 935 mm 36.81 in. |
| Rear overhang | 786 mm 30.94 in. |
| Drag coefficient (Cd) | 0.30 |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 225/45 R17; 225/40 R18 |
| Wheel rims size | 17; 18 |
| What is the body type, Citroen C4 II Hatchback (Phase II, 2015)? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Citroen C4 II Hatchback (Phase II, 2015) 1.6 BlueHDi (120 Hp) S&S? | 3.6-3.8 l/100 km 65.3 – 61.9 US mpg 78.5 – 74.3 UK mpg 27.8 – 26.3 km/l |
| How ECO is the car, Citroen C4 1.6 BlueHDi (120 Hp) S&S? | 95-100 g/km CO2 Euro 6 |
| How fast is the car, 2015 C4 II Hatchback (Phase II, 2015) 1.6 BlueHDi (120 Hp) S&S? | 197 km/h | 122.41 mph 0-100 km/h: 10.6-11.0 sec 0-60 mph: 10.1 sec |
| How much power, Citroen C4 Hatchback 2015 1.6 BlueHDi (120 Hp) S&S? | 120 Hp, 300 Nm 221.27 lb.-ft. |
| What is the engine size, Citroen C4 Hatchback 2015 1.6 BlueHDi (120 Hp) S&S? | 1.6 l 1560 cm3 95.2 cu. in. |
| How many cylinders, 2015 Citroen 1.6 BlueHDi (120 Hp) S&S? | 4, Inline |
| What is the drivetrain, Citroen C4 II Hatchback (Phase II, 2015) Hatchback 2015 1.6 BlueHDi (120 Hp) S&S? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2015 Citroen C4 Hatchback? | 4329 mm 170.43 in. |
| How wide is the vehicle, 2015 Citroen C4 Hatchback? | 1789 mm 70.43 in. |
| What is the curb weight, 2015 Citroen C4 II Hatchback (Phase II, 2015) 1.6 BlueHDi (120 Hp) S&S? | 1280 kg 2821.92 lbs. |
| What is the gross weight, 2015 Citroen C4 II Hatchback (Phase II, 2015) 1.6 BlueHDi (120 Hp) S&S? | 1860 kg 4100.6 lbs. |
| How much trunk (boot) space, 2015 Citroen C4 Hatchback? | 408 – 1183 l 14.41 – 41.78 cu. ft. |
| How many gears, What type is the gearbox, 2015 Citroen C4 II Hatchback (Phase II, 2015) 1.6 BlueHDi (120 Hp) S&S? | 6, manual transmission |
