| General information | |
|---|---|
| Brand | Citroen |
| Model | C4 |
| Generation | C4 II Picasso (Phase I, 2013) |
| Type (Engine) | 1.6 VTi (120 Hp) |
| Start of production | 2013 year |
| End of production | 2014 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan, MPV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 8.5 l/100 km 27.7 US mpg 33.2 UK mpg 11.8 km/l |
| Fuel consumption (economy) – extra urban | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| Fuel consumption (economy) – combined | 6.3 l/100 km 37.3 US mpg 44.8 UK mpg 15.9 km/l |
| CO2 emissions | 145 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 12.3 sec |
| Acceleration 0 – 62 mph | 12.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.7 sec |
| Maximum speed | 187 km/h 116.2 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 10.4 kg/Hp, 95.8 Hp/tonne |
| Weight-to-torque ratio | 7.8 kg/Nm, 127.8 Nm/tonne |
| Engine specs | |
| Power | 120 Hp @ 6000 rpm. |
| Power per litre | 75.1 Hp/l |
| Torque | 160 Nm @ 4250 rpm. 118.01 lb.-ft. @ 4250 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 5FS EP6C |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 77 mm 3.03 in. |
| Piston Stroke | 85.8 mm 3.38 in. |
| Compression ratio | 11:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4.25 l 4.49 US qt | 3.74 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6 l 6.34 US qt | 5.28 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1252 kg 2760.19 lbs. |
| Max. weight | 1900 kg 4188.78 lbs. |
| Max load | 648 kg 1428.6 lbs. |
| Trunk (boot) space – minimum | 537 l 18.96 cu. ft. |
| Trunk (boot) space – maximum | 1710 l 60.39 cu. ft. |
| Fuel tank capacity | 57 l 15.06 US gal | 12.54 UK gal |
| Permitted trailer load with brakes (12%) | 1000 kg 2204.62 lbs. |
| Permitted trailer load without brakes | 660 kg 1455.05 lbs. |
| Permitted towbar download | 70 kg 154.32 lbs. |
| Dimensions | |
| Length | 4428 mm 174.33 in. |
| Width | 1826 mm 71.89 in. |
| Width with mirrors folded | 1971 mm 77.6 in. |
| Width including mirrors | 2117 mm 83.35 in. |
| Height | 1610-1625 mm 63.39 – 63.98 in. |
| Wheelbase | 2785 mm 109.65 in. |
| Front track | 1573-1587 mm 61.93 – 62.48 in. |
| Rear (Back) track | 1576-1590 mm 62.05 – 62.6 in. |
| Front overhang | 879 mm 34.61 in. |
| Rear overhang | 764 mm 30.08 in. |
| Minimum turning circle (turning diameter) | 11.1 m 36.42 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/60 R16 |
| Wheel rims size | 16 |
| What is the body type, Citroen C4 II Picasso (Phase I, 2013)? | Minivan, MPV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Citroen C4 II Picasso (Phase I, 2013) 1.6 VTi (120 Hp)? | 6.3 l/100 km 37.3 US mpg 44.8 UK mpg 15.9 km/l |
| How ECO is the car, Citroen C4 1.6 VTi (120 Hp)? | 145 g/km CO2 Euro 5 |
| How fast is the car, 2013 C4 II Picasso (Phase I, 2013) 1.6 VTi (120 Hp)? | 187 km/h | 116.2 mph 0-100 km/h: 12.3 sec 0-60 mph: 11.7 sec |
| How much power, Citroen C4 Minivan, MPV 2013 1.6 VTi (120 Hp)? | 120 Hp, 160 Nm 118.01 lb.-ft. |
| What is the engine size, Citroen C4 Minivan, MPV 2013 1.6 VTi (120 Hp)? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2013 Citroen 1.6 VTi (120 Hp)? | 4, Inline |
| What is the drivetrain, Citroen C4 II Picasso (Phase I, 2013) Minivan, MPV 2013 1.6 VTi (120 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2013 Citroen C4 Minivan, MPV? | 4428 mm 174.33 in. |
| How wide is the vehicle, 2013 Citroen C4 Minivan, MPV? | 1826 mm 71.89 in. |
| What is the curb weight, 2013 Citroen C4 II Picasso (Phase I, 2013) 1.6 VTi (120 Hp)? | 1252 kg 2760.19 lbs. |
| What is the gross weight, 2013 Citroen C4 II Picasso (Phase I, 2013) 1.6 VTi (120 Hp)? | 1900 kg 4188.78 lbs. |
| How much trunk (boot) space, 2013 Citroen C4 Minivan, MPV? | 537 – 1710 l 18.96 – 60.39 cu. ft. |
| How many gears, What type is the gearbox, 2013 Citroen C4 II Picasso (Phase I, 2013) 1.6 VTi (120 Hp)? | 5, manual transmission |
