| General information | |
|---|---|
| Brand | Citroen |
| Model | C4 |
| Generation | C4 II Picasso (Phase II, 2016) |
| Type (Engine) | 1.2 PureTech (131 Hp) S&S Automatic |
| Start of production | 2016 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan, MPV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 6.4 l/100 km 36.8 US mpg 44.1 UK mpg 15.6 km/l |
| Fuel consumption (economy) – extra urban | 4.4 l/100 km 53.5 US mpg 64.2 UK mpg 22.7 km/l |
| Fuel consumption (economy) – combined | 5.1 l/100 km 46.1 US mpg 55.4 UK mpg 19.6 km/l |
| CO2 emissions | 115 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 10.2 sec |
| Acceleration 0 – 62 mph | 10.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.7 sec |
| Maximum speed | 205 km/h 127.38 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 9.9 kg/Hp, 100.9 Hp/tonne |
| Weight-to-torque ratio | 5.6 kg/Nm, 177.2 Nm/tonne |
| Engine specs | |
| Power | 131 Hp @ 5500 rpm. |
| Power per litre | 109.3 Hp/l |
| Torque | 230 Nm @ 1750 rpm. 169.64 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | HNY EB2DTS |
| Engine displacement | 1199 cm3 73.17 cu. in. |
| Number of cylinders | 3 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 90.5 mm 3.56 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.5 l 3.7 US qt | 3.08 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1298 kg 2861.6 lbs. |
| Max. weight | 1918 kg 4228.47 lbs. |
| Max load | 620 kg 1366.87 lbs. |
| Trunk (boot) space – minimum | 630 l 22.25 cu. ft. |
| Trunk (boot) space – maximum | 1851 l 65.37 cu. ft. |
| Fuel tank capacity | 57 l 15.06 US gal | 12.54 UK gal |
| Max. roof load | 80 kg 176.37 lbs. |
| Permitted trailer load with brakes (12%) | 1270 kg 2799.87 lbs. |
| Permitted trailer load without brakes | 640 kg 1410.96 lbs. |
| Permitted towbar download | 70 kg 154.32 lbs. |
| Dimensions | |
| Length | 4438 mm 174.72 in. |
| Width | 1826 mm 71.89 in. |
| Width with mirrors folded | 1971 mm 77.6 in. |
| Width including mirrors | 2117 mm 83.35 in. |
| Height | 1610-1625 mm 63.39 – 63.98 in. |
| Wheelbase | 2785 mm 109.65 in. |
| Front track | 1573-1587 mm 61.93 – 62.48 in. |
| Rear (Back) track | 1576-1590 mm 62.05 – 62.6 in. |
| Front overhang | 889 mm 35 in. |
| Rear overhang | 764 mm 30.08 in. |
| Minimum turning circle (turning diameter) | 11.1 m 36.42 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/60 R16; 205/55 R17 |
| Wheel rims size | 16; 17 |
| What is the body type, Citroen C4 II Picasso (Phase II, 2016)? | Minivan, MPV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Citroen C4 II Picasso (Phase II, 2016) 1.2 PureTech (131 Hp) S&S Automatic? | 5.1 l/100 km 46.1 US mpg 55.4 UK mpg 19.6 km/l |
| How ECO is the car, Citroen C4 1.2 PureTech (131 Hp) S&S Automatic? | 115 g/km CO2 Euro 6 |
| How fast is the car, 2016 C4 II Picasso (Phase II, 2016) 1.2 PureTech (131 Hp) S&S Automatic? | 205 km/h | 127.38 mph 0-100 km/h: 10.2 sec 0-60 mph: 9.7 sec |
| How much power, Citroen C4 Minivan, MPV 2016 1.2 PureTech (131 Hp) S&S Automatic? | 131 Hp, 230 Nm 169.64 lb.-ft. |
| What is the engine size, Citroen C4 Minivan, MPV 2016 1.2 PureTech (131 Hp) S&S Automatic? | 1.2 l 1199 cm3 73.17 cu. in. |
| How many cylinders, 2016 Citroen 1.2 PureTech (131 Hp) S&S Automatic? | 3, Inline |
| What is the drivetrain, Citroen C4 II Picasso (Phase II, 2016) Minivan, MPV 2016 1.2 PureTech (131 Hp) S&S Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2016 Citroen C4 Minivan, MPV? | 4438 mm 174.72 in. |
| How wide is the vehicle, 2016 Citroen C4 Minivan, MPV? | 1826 mm 71.89 in. |
| What is the curb weight, 2016 Citroen C4 II Picasso (Phase II, 2016) 1.2 PureTech (131 Hp) S&S Automatic? | 1298 kg 2861.6 lbs. |
| What is the gross weight, 2016 Citroen C4 II Picasso (Phase II, 2016) 1.2 PureTech (131 Hp) S&S Automatic? | 1918 kg 4228.47 lbs. |
| How much trunk (boot) space, 2016 Citroen C4 Minivan, MPV? | 630 – 1851 l 22.25 – 65.37 cu. ft. |
| How many gears, What type is the gearbox, 2016 Citroen C4 II Picasso (Phase II, 2016) 1.2 PureTech (131 Hp) S&S Automatic? | 6, automatic transmission |
