The Citroen C5 X 1.2 PureTech Automatic, produced from September 2021 to February 2025, represents a unique offering within the C5 X range. Positioned as an entry-level powertrain option, it combined a relatively small-displacement turbocharged engine with an eight-speed automatic transmission. This variant aimed to provide a balance of fuel efficiency and comfortable driving, appealing to buyers seeking a practical and stylish crossover vehicle. The C5 X itself is a distinctive model, blending elements of a traditional station wagon, a sedan, and an SUV, and was intended to revitalize Citroen’s presence in the D-segment.
Technical Specifications
| Brand | Citroen |
| Model | C5 X |
| Generation | C5 X |
| Type (Engine) | 1.2 PureTech (131 Hp) Automatic |
| Start of production | September, 2021 |
| End of production | February, 2025 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate), Crossover |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption at Low speed (WLTP) | 7.8 l/100 km (30.2 US mpg, 36.2 UK mpg, 12.8 km/l) |
| Fuel consumption at Medium speed (WLTP) | 6 l/100 km (39.2 US mpg, 47.1 UK mpg, 16.7 km/l) |
| Fuel consumption at high speed (WLTP) | 5.1 l/100 km (46.1 US mpg, 55.4 UK mpg, 19.6 km/l) |
| Fuel consumption at very high speed (WLTP) | 6.1 l/100 km (38.6 US mpg, 46.3 UK mpg, 16.4 km/l) |
| Combined fuel consumption (WLTP) | 6 l/100 km (39.2 US mpg, 47.1 UK mpg, 16.7 km/l) |
| CO2 emissions (WLTP) | 136 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 11.3 sec |
| Acceleration 0 – 62 mph | 11.3 sec |
| Acceleration 0 – 60 mph | 10.7 sec |
| Maximum speed | 210 km/h (130.49 mph) |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 11.4 kg/Hp, 87.7 Hp/tonne |
| Weight-to-torque ratio | 6.5 kg/Nm, 154.1 Nm/tonne |
| Power | 131 Hp @ 5500 rpm |
| Power per litre | 109.3 Hp/l |
| Torque | 230 Nm @ 1750 rpm (169.64 lb.-ft. @ 1750 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | EB2DTS |
| Engine displacement | 1199 cm3 (73.17 cu. in.) |
| Number of cylinders | 3 |
| Engine configuration | Inline |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.5 l (3.7 US qt | 3.08 UK qt) |
| Kerb Weight | 1493 kg (3291.5 lbs.) |
| Max. weight | 1905 kg (4199.81 lbs.) |
| Max load | 412 kg (908.3 lbs.) |
| Trunk (boot) space – minimum | 545 l (19.25 cu. ft.) |
| Trunk (boot) space – maximum | 720 l (25.43 cu. ft.) |
| Fuel tank capacity | 53 l (14 US gal | 11.66 UK gal) |
| Max. roof load | 70 kg (154.32 lbs.) |
| Permitted trailer load with brakes (12%) | 1050 kg (2314.85 lbs.) |
| Permitted trailer load without brakes | 745 kg (1642.44 lbs.) |
| Length | 4805 mm (189.17 in.) |
| Width | 1859 mm (73.19 in.) |
| Width including mirrors | 2062 mm (81.18 in.) |
| Height | 1485 mm (58.46 in.) |
| Wheelbase | 2785 mm (109.65 in.) |
| Front overhang | 985 mm (38.78 in.) |
| Rear overhang | 1035 mm (40.75 in.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Wheel rims size | 19 |
Powertrain & Engine Architecture
The C5 X 1.2 PureTech utilizes the EB2DTS engine, a 1.2-liter turbocharged three-cylinder petrol engine belonging to Citroen’s PureTech family. This engine employs direct fuel injection and a single-scroll turbocharger with an intercooler to enhance efficiency and power output. The engine’s architecture prioritizes compactness and reduced friction to minimize fuel consumption. The eight-speed automatic transmission, sourced from Aisin, was chosen for its smooth shifting characteristics and contribution to overall fuel economy. This transmission features a wide gear ratio spread, optimizing engine operation for both cruising and acceleration. The engine is transversely mounted at the front of the vehicle, driving the front wheels.
Driving Characteristics
The 131 horsepower and 230 Nm (169.64 lb-ft) of torque delivered by the 1.2 PureTech engine, coupled with the eight-speed automatic, resulted in a comfortable, rather than sporty, driving experience. Acceleration from 0-60 mph took approximately 10.7 seconds, and 0-100 km/h in 11.3 seconds. While adequate for everyday driving, it was noticeably slower than the higher-powered variants of the C5 X, such as those equipped with the 1.6 PureTech engine. The automatic transmission generally shifted smoothly, but could occasionally exhibit some hesitation during quick acceleration. The gear ratios were tuned for fuel efficiency, meaning the engine sometimes felt strained when climbing hills or overtaking at higher speeds. The focus was on providing a relaxed and refined ride, prioritizing comfort over outright performance.
Equipment & Trim Levels
The 1.2 PureTech Automatic trim typically served as the entry point to the C5 X range. Standard equipment generally included features such as a touchscreen infotainment system with Apple CarPlay and Android Auto compatibility, automatic climate control, rear parking sensors, and a suite of safety features including automatic emergency braking and lane departure warning. Interior upholstery was typically cloth, with options for leather upgrades available at an additional cost. Higher trim levels added features like a panoramic sunroof, adaptive cruise control, and premium audio systems. The dashboard layout was modern and minimalist, emphasizing a clean and uncluttered aesthetic.
Chassis & Braking
The C5 X features a front-wheel-drive chassis with a MacPherson strut front suspension and a multi-link rear suspension. The suspension was tuned to prioritize ride comfort, utilizing Citroen’s Advanced Comfort program which includes Progressive Hydraulic Cushions. This system effectively filters out bumps and imperfections in the road surface. The braking system consisted of ventilated discs at the front and solid discs at the rear. Anti-lock Braking System (ABS) and Electronic Stability Control (ESC) were standard safety features. The steering utilized an electric power steering system, providing light and precise control.
Market Reception & Comparison
The C5 X 1.2 PureTech Automatic received mixed reviews. Critics generally praised the vehicle’s unique styling, comfortable ride, and fuel efficiency. However, the engine was often criticized for feeling underpowered, particularly when fully loaded or driving on inclines. Compared to the 1.6 PureTech variants, the 1.2 offered significantly less performance, but at a lower price point. Fuel economy was a strong point, with combined WLTP figures around 6 l/100 km (39.2 US mpg), making it an attractive option for drivers prioritizing efficiency. Reliability reports have been generally positive, with the PureTech engine proving to be reasonably durable, although some owners have reported issues with the turbocharger and fuel injection system.
Legacy
The Citroen C5 X 1.2 PureTech Automatic, while not a performance standout, offered a compelling package for buyers seeking a comfortable, stylish, and fuel-efficient crossover. Its unique design and focus on ride quality helped it stand out in a crowded market segment. On the used car market, these models represent a relatively affordable entry point into C5 X ownership. The longevity of the EB2DTS engine, when properly maintained, suggests that these vehicles should provide reliable service for years to come. However, potential buyers should be aware of the potential for turbocharger and fuel injection issues, and ensure that the vehicle has been regularly serviced.
