| General information | |
|---|---|
| Brand | Citroen |
| Model | DS |
| Generation | DS II Cabriolet Chapron |
| Type (Engine) | 21 (100 Hp) |
| Start of production | 1965 year |
| End of production | 1967 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 2 |
| Doors | 2 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 13.2 kg/Hp, 76 Hp/tonne |
| Weight-to-torque ratio | 8 kg/Nm, 124.7 Nm/tonne |
| Engine specs | |
| Power | 100 Hp @ 5500 rpm. |
| Power per litre | 46 Hp/l |
| Torque | 164 Nm @ 3000 rpm. 120.96 lb.-ft. @ 3000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | B22644 |
| Engine displacement | 2175 cm3 132.73 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 90 mm 3.54 in. |
| Piston Stroke | 85.5 mm 3.37 in. |
| Compression ratio | 8.75:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4 l 4.23 US qt | 3.52 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11 l 11.62 US qt | 9.68 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1315 kg 2899.08 lbs. |
| Max. weight | 1760 kg 3880.14 lbs. |
| Max load | 445 kg 981.06 lbs. |
| Fuel tank capacity | 65 l 17.17 US gal | 14.3 UK gal |
| Dimensions | |
| Length | 4860 mm 191.34 in. |
| Width | 1790 mm 70.47 in. |
| Height | 1420 mm 55.91 in. |
| Wheelbase | 3125 mm 123.03 in. |
| Front track | 1500 mm 59.06 in. |
| Rear (Back) track | 1300 mm 51.18 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, manual transmission |
| Front suspension | Hydro-pneumatic element |
| Rear suspension | Hydro-pneumatic element |
| Front brakes | Disc |
| Rear brakes | Drum |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| What is the body type, Citroen DS II Cabriolet Chapron? | Cabriolet, 2 Doors, 2 Seats |
|---|---|
| How much power, Citroen DS Cabriolet 1965 21 (100 Hp)? | 100 Hp, 164 Nm 120.96 lb.-ft. |
| What is the engine size, Citroen DS Cabriolet 1965 21 (100 Hp)? | 2.2 l 2175 cm3 132.73 cu. in. |
| How many cylinders, 1965 Citroen 21 (100 Hp)? | 4, Inline |
| What is the drivetrain, Citroen DS II Cabriolet Chapron Cabriolet 1965 21 (100 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 1965 Citroen DS Cabriolet? | 4860 mm 191.34 in. |
| How wide is the vehicle, 1965 Citroen DS Cabriolet? | 1790 mm 70.47 in. |
| What is the curb weight, 1965 Citroen DS II Cabriolet Chapron 21 (100 Hp)? | 1315 kg 2899.08 lbs. |
| What is the gross weight, 1965 Citroen DS II Cabriolet Chapron 21 (100 Hp)? | 1760 kg 3880.14 lbs. |
| How many gears, What type is the gearbox, 1965 Citroen DS II Cabriolet Chapron 21 (100 Hp)? | 4, manual transmission |
