The Citroën Xsara 1.8i Automatic, produced between 1998 and 2000, represents a mid-range offering within the first generation (N1) of the Xsara compact hatchback. Positioned as a more comfortable and accessible alternative to the sportier trims, this variant aimed to provide a balance of practicality, reasonable performance, and ease of use for the average family driver. It was a key part of Citroën’s strategy to offer a diverse lineup within the competitive European C-segment, appealing to buyers who prioritized convenience over outright driving thrills. The N1 Xsara, and this 1.8i Automatic specifically, played a significant role in establishing the Xsara as a popular choice in its class.
Technical Specifications
| Brand | Citroen |
| Model | Xsara |
| Generation | Xsara (N1, Phase I) |
| Type (Engine) | 1.8 i (101 Hp) Automatic |
| Start of production | 1998 |
| End of production | 2000 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption (urban) | 12.9 l/100 km (18.2 US mpg, 21.9 UK mpg, 7.8 km/l) |
| Fuel consumption (extra urban) | 6.9 l/100 km (34.1 US mpg, 40.9 UK mpg, 14.5 km/l) |
| Fuel consumption (combined) | 9.1 l/100 km (25.8 US mpg, 31 UK mpg, 11 km/l) |
| CO2 emissions | 220 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 15.4 sec |
| Acceleration 0 – 62 mph | 15.4 sec |
| Acceleration 0 – 60 mph | 14.6 sec |
| Maximum speed | 177 km/h (109.98 mph) |
| Emission standard | Euro 2 |
| Weight-to-power ratio | 10.7 kg/Hp, 93.2 Hp/tonne |
| Weight-to-torque ratio | 7.1 kg/Nm, 141.1 Nm/tonne |
| Power | 101 Hp @ 6000 rpm |
| Power per litre | 57.4 Hp/l |
| Torque | 153 Nm @ 3000 rpm (112.85 lb.-ft. @ 3000 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | LFZ XU7JP |
| Engine displacement | 1761 cm3 (107.46 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 83 mm (3.27 in.) |
| Piston Stroke | 81.4 mm (3.2 in.) |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHC |
| Engine oil capacity | 4.75 l (5.02 US qt | 4.18 UK qt) |
| Coolant | 7 l (7.4 US qt | 6.16 UK qt) |
| Kerb Weight | 1084 kg (2389.81 lbs.) |
| Max. weight | 1600 kg (3527.4 lbs.) |
| Max load | 516 kg (1137.59 lbs.) |
| Trunk (boot) space – minimum | 408 l (14.41 cu. ft.) |
| Trunk (boot) space – maximum | 1190 l (42.02 cu. ft.) |
| Fuel tank capacity | 54 l (14.27 US gal | 11.88 UK gal) |
| Max. roof load | 75 kg (165.35 lbs.) |
| Permitted trailer load with brakes (12%) | 1100 kg (2425.08 lbs.) |
| Permitted trailer load without brakes | 575 kg (1267.66 lbs.) |
| Length | 4167 mm (164.06 in.) |
| Width | 1698 mm (66.85 in.) |
| Width including mirrors | 1994 mm (78.5 in.) |
| Height | 1405 mm (55.31 in.) |
| Wheelbase | 2540 mm (100 in.) |
| Front track | 1423 mm (56.02 in.) |
| Rear (Back) track | 1430 mm (56.3 in.) |
| Front overhang | 868 mm (34.17 in.) |
| Rear overhang | 759 mm (29.88 in.) |
| Minimum turning circle | 11.5 m (37.73 ft.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 185/65 R14 |
Powertrain & Engine Architecture
The heart of the Xsara 1.8i Automatic is the LFZ engine, a member of the PSA Group’s XU7JP family. This 1761cc inline-four cylinder engine utilizes a naturally aspirated configuration with two valves per cylinder operated by an overhead camshaft (OHC). Fuel delivery is managed by a multi-port fuel injection system, providing a balance between efficiency and performance for its time. The XU7JP engine was known for its relative simplicity and durability, making it a reliable powerplant. The automatic transmission paired with this engine is a four-speed unit, designed to offer smooth gear changes and ease of driving, particularly in urban environments. While not known for its sportiness, this transmission was well-suited to the engine’s torque characteristics.
Driving Characteristics
The 1.8i Automatic Xsara delivers a comfortable, if not particularly exhilarating, driving experience. With 101 horsepower and 113 lb-ft of torque, acceleration is adequate for everyday driving, but it’s noticeably slower than the higher-output versions of the Xsara, such as those equipped with the 2.0L 16V engine. The four-speed automatic transmission contributes to this, with relatively wide gear ratios prioritizing fuel economy over rapid acceleration. The automatic transmission does rob some power, making the 0-60 mph time around 14.6 seconds. The focus is on smooth cruising and ease of use, making it a good choice for drivers who prioritize comfort and convenience.
Equipment & Trim Levels
The 1.8i Automatic trim typically included features such as power steering, central locking, electric front windows, and an AM/FM radio. Air conditioning was often an optional extra. Interior upholstery was generally cloth, with a functional and durable design. Higher-spec versions could be equipped with features like alloy wheels, a sunroof, and upgraded audio systems. The overall interior ambiance was practical and focused on providing a comfortable space for passengers.
Chassis & Braking
The Xsara N1 utilizes an independent McPherson strut suspension setup at the front, providing a reasonable level of ride comfort and handling. The rear suspension employs a torsion beam, a cost-effective solution that offers adequate stability. Braking is handled by ventilated discs at the front and drum brakes at the rear. Anti-lock Braking System (ABS) was standard, enhancing safety by preventing wheel lockup during hard braking. The suspension tuning was geared towards comfort, resulting in a slightly softer ride compared to sportier Xsara variants.
Market Reception & Comparison
The 1.8i Automatic Xsara was generally well-received as a practical and affordable family car. Critics noted its comfortable ride and ease of driving, but also pointed out its relatively modest performance compared to other engines in the lineup. Compared to the 2.0L 16V models, the 1.8i Automatic offered lower running costs and a more relaxed driving experience, but at the expense of outright speed. The 1.9 TDI diesel offered significantly better fuel economy, but with a higher purchase price and a different driving character. The 1.8i Automatic appealed to buyers who valued convenience and affordability over performance.
Legacy
The XU7JP engine, found in the 1.8i Automatic Xsara, is known for its durability and relatively simple maintenance requirements. While not a high-performance engine, it has proven to be a reliable powerplant over the long term. Today, these cars are relatively affordable on the used market, making them a potentially good value for budget-conscious buyers. However, potential buyers should be aware of the age-related issues common to cars of this era, such as corrosion and wear and tear on suspension components. The 1.8i Automatic Xsara represents a solid, if unspectacular, example of a late-1990s family hatchback.
