| General information | |
|---|---|
| Brand | Citroen |
| Model | Xsara |
| Generation | Xsara (N1, Phase III) |
| Type (Engine) | 1.4 HDi (68 Hp) |
| Start of production | 2003 year |
| End of production | 2004 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 5.7 l/100 km 41.3 US mpg 49.6 UK mpg 17.5 km/l |
| Fuel consumption (economy) – extra urban | 3.8 l/100 km 61.9 US mpg 74.3 UK mpg 26.3 km/l |
| Fuel consumption (economy) – combined | 4.5 l/100 km 52.3 US mpg 62.8 UK mpg 22.2 km/l |
| CO2 emissions | 120 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 16.7 sec |
| Acceleration 0 – 62 mph | 16.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 15.9 sec |
| Maximum speed | 164 km/h 101.9 mph |
| Emission standard | Euro 3 |
| Weight-to-power ratio | 16.6 kg/Hp, 60.3 Hp/tonne |
| Weight-to-torque ratio | 7 kg/Nm, 142 Nm/tonne |
| Engine specs | |
| Power | 68 Hp @ 4000 rpm. |
| Power per litre | 48.6 Hp/l |
| Torque | 160 Nm @ 2000 rpm. 118.01 lb.-ft. @ 2000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 8HX DV4TD |
| Engine displacement | 1398 cm3 85.31 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 73.7 mm 2.9 in. |
| Piston Stroke | 82 mm 3.23 in. |
| Compression ratio | 17.9:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 4.2 l 4.44 US qt | 3.7 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.7 l 6.02 US qt | 5.02 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1127 kg 2484.61 lbs. |
| Max. weight | 1675 kg 3692.74 lbs. |
| Max load | 548 kg 1208.13 lbs. |
| Trunk (boot) space – minimum | 408 l 14.41 cu. ft. |
| Trunk (boot) space – maximum | 1190 l 42.02 cu. ft. |
| Fuel tank capacity | 54 l 14.27 US gal | 11.88 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 1100 kg 2425.08 lbs. |
| Permitted trailer load without brakes | 590 kg 1300.73 lbs. |
| Permitted towbar download | 70 kg 154.32 lbs. |
| Dimensions | |
| Length | 4188 mm 164.88 in. |
| Width | 1705 mm 67.13 in. |
| Width including mirrors | 2014 mm 79.29 in. |
| Height | 1405 mm 55.31 in. |
| Wheelbase | 2540 mm 100 in. |
| Front track | 1433 mm 56.42 in. |
| Rear (Back) track | 1442 mm 56.77 in. |
| Front overhang | 880 mm 34.65 in. |
| Rear overhang | 768 mm 30.24 in. |
| Minimum turning circle (turning diameter) | 11.5 m 37.73 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/55 R15 |
| Wheel rims size | 6J x 15 |
| What is the body type, Citroen Xsara (N1, Phase III)? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Citroen Xsara (N1, Phase III) 1.4 HDi (68 Hp)? | 4.5 l/100 km 52.3 US mpg 62.8 UK mpg 22.2 km/l |
| How ECO is the car, Citroen Xsara 1.4 HDi (68 Hp)? | 120 g/km CO2 Euro 3 |
| How fast is the car, 2003 Xsara (N1, Phase III) 1.4 HDi (68 Hp)? | 164 km/h | 101.9 mph 0-100 km/h: 16.7 sec 0-60 mph: 15.9 sec |
| How much power, Citroen Xsara Hatchback 2003 1.4 HDi (68 Hp)? | 68 Hp, 160 Nm 118.01 lb.-ft. |
| What is the engine size, Citroen Xsara Hatchback 2003 1.4 HDi (68 Hp)? | 1.4 l 1398 cm3 85.31 cu. in. |
| How many cylinders, 2003 Citroen 1.4 HDi (68 Hp)? | 4, Inline |
| What is the drivetrain, Citroen Xsara (N1, Phase III) Hatchback 2003 1.4 HDi (68 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2003 Citroen Xsara Hatchback? | 4188 mm 164.88 in. |
| How wide is the vehicle, 2003 Citroen Xsara Hatchback? | 1705 mm 67.13 in. |
| What is the curb weight, 2003 Citroen Xsara (N1, Phase III) 1.4 HDi (68 Hp)? | 1127 kg 2484.61 lbs. |
| What is the gross weight, 2003 Citroen Xsara (N1, Phase III) 1.4 HDi (68 Hp)? | 1675 kg 3692.74 lbs. |
| How much trunk (boot) space, 2003 Citroen Xsara Hatchback? | 408 – 1190 l 14.41 – 42.02 cu. ft. |
| How many gears, What type is the gearbox, 2003 Citroen Xsara (N1, Phase III) 1.4 HDi (68 Hp)? | 5, manual transmission |
