| General information | |
|---|---|
| Brand | Dodge |
| Model | Caliber |
| Generation | Caliber |
| Type (Engine) | 2.4 16V (174 Hp) |
| Start of production | 2006 year |
| End of production | 2007 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 10.2 l/100 km 23.1 US mpg 27.7 UK mpg 9.8 km/l |
| Fuel consumption (economy) – extra urban | 9.1 l/100 km 25.8 US mpg 31 UK mpg 11 km/l |
| Fuel Type | Petrol (Gasoline) |
| Engine specs | |
| Power | 174 Hp @ 6000 rpm. |
| Power per litre | 73.7 Hp/l |
| Torque | 223 Nm @ 4400 rpm. 164.48 lb.-ft. @ 4400 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | ED3 |
| Engine displacement | 2360 cm3 144.02 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 88 mm 3.46 in. |
| Piston Stroke | 97 mm 3.82 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.26 l 4.5 US qt | 3.75 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.8 l 7.19 US qt | 5.98 UK qt |
|
|
|
| Space, Volume and weights | |
| Trunk (boot) space – minimum | 524 l 18.5 cu. ft. |
| Trunk (boot) space – maximum | 1360 l 48.03 cu. ft. |
| Fuel tank capacity | 52 l 13.74 US gal | 11.44 UK gal |
| Dimensions | |
| Length | 4414 mm 173.78 in. |
| Width | 1747 mm 68.78 in. |
| Height | 1533 mm 60.35 in. |
| Wheelbase | 2635 mm 103.74 in. |
| Front track | 1520 mm 59.84 in. |
| Rear (Back) track | 1520 mm 59.84 in. |
| Minimum turning circle (turning diameter) | 10.8 m 35.43 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 225/45 R19 |
| What is the body type, Dodge Caliber? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| How much power, Dodge Caliber Hatchback 2006 2.4 16V (174 Hp)? | 174 Hp, 223 Nm 164.48 lb.-ft. |
| What is the engine size, Dodge Caliber Hatchback 2006 2.4 16V (174 Hp)? | 2.4 l 2360 cm3 144.02 cu. in. |
| How many cylinders, 2006 Dodge 2.4 16V (174 Hp)? | 4, Inline |
| What is the drivetrain, Dodge Caliber Hatchback 2006 2.4 16V (174 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2006 Dodge Caliber Hatchback? | 4414 mm 173.78 in. |
| How wide is the vehicle, 2006 Dodge Caliber Hatchback? | 1747 mm 68.78 in. |
| How much trunk (boot) space, 2006 Dodge Caliber Hatchback? | 524 – 1360 l 18.5 – 48.03 cu. ft. |
| How many gears, What type is the gearbox, 2006 Dodge Caliber 2.4 16V (174 Hp)? | 5, manual transmission |
