| General information | |
|---|---|
| Brand | Dodge |
| Model | Journey |
| Generation | Journey (facelift 2010) |
| Type (Engine) | 2.4 (173 Hp) Automatic |
| Start of production | 2010 year |
| End of production | 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | CUV |
| Seats | 5-7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (EPA) | 12.4 l/100 km 19 US mpg 22.8 UK mpg 8.1 km/l |
| Fuel consumption (economy) – extra urban (EPA) | 9.4 l/100 km 25 US mpg 30.1 UK mpg 10.6 km/l |
| Fuel consumption (economy) – combined (EPA) | 11.2 l/100 km 21 US mpg 25.2 UK mpg 8.9 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 10 kg/Hp, 99.7 Hp/tonne |
| Weight-to-torque ratio | 7.7 kg/Nm, 129.7 Nm/tonne |
| Engine specs | |
| Power | 173 Hp @ 6000 rpm. |
| Power per litre | 73.3 Hp/l |
| Torque | 225 Nm @ 4000 rpm. 165.95 lb.-ft. @ 4000 rpm. |
| Maximum engine speed | 6500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | ED3 |
| Engine displacement | 2360 cm3 144.02 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 88 mm 3.46 in. |
| Piston Stroke | 97 mm 3.82 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, VVT |
| Engine oil capacity | 4.26 l 4.5 US qt | 3.75 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.5 l 7.93 US qt | 6.6 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1735 kg 3825.02 lbs. |
| Max. weight | 2270-2381 kg 5004.49 – 5249.21 lbs. |
| Max load | 535-646 kg 1179.47 – 1424.19 lbs. |
| Trunk (boot) space – minimum | 300 l 10.59 cu. ft. |
| Trunk (boot) space – maximum | 1915 l 67.63 cu. ft. |
| Fuel tank capacity | 77.6 l 20.5 US gal | 17.07 UK gal |
| Permitted trailer load with brakes (12%) | 450 kg 992.08 lbs. |
| Dimensions | |
| Length | 4887 mm 192.4 in. |
| Width | 1834 mm 72.2 in. |
| Width including mirrors | 2127 mm 83.74 in. |
| Height | 1692 mm 66.61 in. |
| Wheelbase | 2890 mm 113.78 in. |
| Front track | 1570 mm 61.81 in. |
| Rear (Back) track | 1582 mm 62.28 in. |
| Front overhang | 989 mm 38.94 in. |
| Rear overhang | 1008 mm 39.69 in. |
| Drag coefficient (Cd) | 0.368 |
| Minimum turning circle (turning diameter) | 11.7 m 38.39 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 330×28 mm |
| Rear brakes | Disc, 328×12 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 225/65 R17; 225/55 R19 |
| Wheel rims size | 6.5J x 17; 7J x 19 |
| What is the body type, Dodge Journey (facelift 2010)? | CUV, 5 Doors, 5-7 Seats |
|---|---|
| What is the fuel economy, Dodge Journey (facelift 2010) 2.4 (173 Hp) Automatic? | 11.2 l/100 km 21 US mpg 25.2 UK mpg 8.9 km/l |
| How much power, Dodge Journey CUV 2010 2.4 (173 Hp) Automatic? | 173 Hp, 225 Nm 165.95 lb.-ft. |
| What is the engine size, Dodge Journey CUV 2010 2.4 (173 Hp) Automatic? | 2.4 l 2360 cm3 144.02 cu. in. |
| How many cylinders, 2010 Dodge 2.4 (173 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Dodge Journey (facelift 2010) CUV 2010 2.4 (173 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2010 Dodge Journey CUV? | 4887 mm 192.4 in. |
| How wide is the vehicle, 2010 Dodge Journey CUV? | 1834 mm 72.2 in. |
| What is the curb weight, 2010 Dodge Journey (facelift 2010) 2.4 (173 Hp) Automatic? | 1735 kg 3825.02 lbs. |
| What is the gross weight, 2010 Dodge Journey (facelift 2010) 2.4 (173 Hp) Automatic? | 2270-2381 kg 5004.49 – 5249.21 lbs. |
| How much trunk (boot) space, 2010 Dodge Journey CUV? | 300 – 1915 l 10.59 – 67.63 cu. ft. |
| How many gears, What type is the gearbox, 2010 Dodge Journey (facelift 2010) 2.4 (173 Hp) Automatic? | 4, automatic transmission |
