| General information | |
|---|---|
| Brand | DS |
| Model | 4 |
| Generation | 4 |
| Type (Engine) | 1.6 BlueHDi (120 Hp) Stop&Start Automatic |
| Start of production | 2015 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 4.4-4.8 l/100 km 53.5 – 49 US mpg 64.2 – 58.9 UK mpg 22.7 – 20.8 km/l |
| Fuel consumption (economy) – extra urban | 3.5-3.8 l/100 km 67.2 – 61.9 US mpg 80.7 – 74.3 UK mpg 28.6 – 26.3 km/l |
| Fuel consumption (economy) – combined | 3.8-4.1 l/100 km 61.9 – 57.4 US mpg 74.3 – 68.9 UK mpg 26.3 – 24.4 km/l |
| CO2 emissions | 99-108 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 12.5 sec |
| Acceleration 0 – 62 mph | 12.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.9 sec |
| Maximum speed | 189-193 km/h 117.44 – 119.92 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 10.9 kg/Hp, 91.6 Hp/tonne |
| Weight-to-torque ratio | 4.4 kg/Nm, 229 Nm/tonne |
| Engine specs | |
| Power | 120 Hp @ 3500 rpm. |
| Power per litre | 76.9 Hp/l |
| Torque | 300 Nm @ 1750 rpm. 221.27 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | BHZ DV6FC |
| Engine displacement | 1560 cm3 95.2 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.75 l 3.96 US qt | 3.3 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1310-1422 kg 2888.06 – 3134.97 lbs. |
| Max. weight | 1890 kg 4166.74 lbs. |
| Max load | 468-580 kg 1031.76 – 1278.68 lbs. |
| Trunk (boot) space – minimum | 359 l 12.68 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Permitted trailer load with brakes (12%) | 1450 kg 3196.7 lbs. |
| Permitted trailer load without brakes | 640 kg 1410.96 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4284 mm 168.66 in. |
| Width | 1810 mm 71.26 in. |
| Width including mirrors | 2052 mm 80.79 in. |
| Height | 1497-1502 mm 58.94 – 59.13 in. |
| Wheelbase | 2612 mm 102.83 in. |
| Front track | 1532 mm 60.31 in. |
| Rear (Back) track | 1527 mm 60.12 in. |
| Front overhang | 933 mm 36.73 in. |
| Rear overhang | 739 mm 29.09 in. |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/60 R16; 215/55 R17; 225/45 R18 |
| Wheel rims size | 16; 17; 18 |
| What is the body type, DS 4? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, DS 4 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 3.8-4.1 l/100 km 61.9 – 57.4 US mpg 74.3 – 68.9 UK mpg 26.3 – 24.4 km/l |
| How ECO is the car, DS 4 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 99-108 g/km CO2 Euro 6 |
| How fast is the car, 2015 4 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 189-193 km/h | 117.44 – 119.92 mph 0-100 km/h: 12.5 sec 0-60 mph: 11.9 sec |
| How much power, DS 4 Hatchback 2015 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 120 Hp, 300 Nm 221.27 lb.-ft. |
| What is the engine size, DS 4 Hatchback 2015 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 1.6 l 1560 cm3 95.2 cu. in. |
| How many cylinders, 2015 DS 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 4, Inline |
| What is the drivetrain, DS 4 Hatchback 2015 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2015 DS 4 Hatchback? | 4284 mm 168.66 in. |
| How wide is the vehicle, 2015 DS 4 Hatchback? | 1810 mm 71.26 in. |
| What is the curb weight, 2015 DS 4 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 1310-1422 kg 2888.06 – 3134.97 lbs. |
| What is the gross weight, 2015 DS 4 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 1890 kg 4166.74 lbs. |
| How much trunk (boot) space, 2015 DS 4 Hatchback? | 359 l 12.68 cu. ft. |
| How many gears, What type is the gearbox, 2015 DS 4 1.6 BlueHDi (120 Hp) Stop&Start Automatic? | 6, automatic transmission |
