| General information | |
|---|---|
| Brand | DS |
| Model | 4 |
| Generation | 4 II |
| Type (Engine) | 1.6 PureTech (225 Hp) E-TENSE Automatic |
| Start of production | May, 2021 year |
| End of production | June, 2025 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption at Low speed (WLTP) | 7.4-7.7 l/100 km 31.8 – 30.5 US mpg 38.2 – 36.7 UK mpg 13.5 – 13 km/l |
| Fuel consumption at Medium speed (WLTP) | 6.1-6.4 l/100 km 38.6 – 36.8 US mpg 46.3 – 44.1 UK mpg 16.4 – 15.6 km/l |
| Fuel consumption at high speed (WLTP) | 5.6-5.8 l/100 km 42 – 40.6 US mpg 50.4 – 48.7 UK mpg 17.9 – 17.2 km/l |
| Fuel consumption at very high speed (WLTP) | 6.9-7.4 l/100 km 34.1 – 31.8 US mpg 40.9 – 38.2 UK mpg 14.5 – 13.5 km/l |
| Combined fuel consumption (WLTP) | 1.3-1.4 l/100 km 180.9 – 168 US mpg 217.3 – 201.8 UK mpg 76.9 – 71.4 km/l |
| CO2 emissions (WLTP) | 29-32 g/km |
| Fuel consumption (economy) – combined (NEDC, WLTP equivalent) | 1.4 l/100 km 168 US mpg 201.8 UK mpg 71.4 km/l |
| CO2 emissions (NEDC, WLTP equivalent) | 32 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 7.7 sec |
| Acceleration 0 – 62 mph | 7.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.3 sec |
| Maximum speed | 233 km/h 144.78 mph |
| Emission standard | Euro 6.3 |
| Weight-to-power ratio | 7.3 kg/Hp, 136.1 Hp/tonne |
| Weight-to-torque ratio | 4.6 kg/Nm, 217.8 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 12.4 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the trunk |
| All-electric range (WLTP) | 52-55 km 32.31 – 34.18 mi |
| Average Energy consumption (WLTP) | 14.6-15.2 kWh/100 km
23.5 – 24.46 kWh/100 mi |
| Max speed (electric) | 135 km/h
83.89 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 110 Hp @ 2500 rpm. |
| Electric motor Torque | 320 Nm
236.02 lb.-ft. |
| Electric motor location | Between the combustion engine and the transmission |
| System power | 225 Hp @ 6000 rpm. |
| System torque | 360 Nm 265.52 lb.-ft. |
| Internal combustion engine specs | |
| Power | 180 Hp @ 6000 rpm. |
| Power per litre | 112.6 Hp/l |
| Torque | 250 Nm @ 1750 rpm. 184.39 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | DGZ EP6FADTXHPD |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 77 mm 3.03 in. |
| Piston Stroke | 86 mm 3.39 in. |
| Compression ratio | 10.2:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.25 l 4.49 US qt | 3.74 UK qt |
| Engine oil specification | Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1653 kg 3644.24 lbs. |
| Max. weight | 2200 kg 4850.17 lbs. |
| Max load | 547 kg 1205.93 lbs. |
| Trunk (boot) space – minimum | 390 l 13.77 cu. ft. |
| Trunk (boot) space – maximum | 1190 l 42.02 cu. ft. |
| Fuel tank capacity | 40 l 10.57 US gal | 8.8 UK gal |
| Permitted trailer load with brakes (12%) | 1400 kg 3086.47 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 70 kg 154.32 lbs. |
| Dimensions | |
| Length | 4400 mm 173.23 in. |
| Width | 1866 mm 73.46 in. |
| Width including mirrors | 2061 mm 81.14 in. |
| Height | 1490 mm 58.66 in. |
| Wheelbase | 2675 mm 105.31 in. |
| Front track | 1600 mm 62.99 in. |
| Rear (Back) track | 1605 mm 63.19 in. |
| Front overhang | 925 mm 36.42 in. |
| Rear overhang | 800 mm 31.5 in. |
| Ride height (ground clearance) | 189 mm 7.44 in. |
| Minimum turning circle (turning diameter) | 10.82 m 35.5 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Coil spring, Torsion |
| Front brakes | Ventilated discs, 330×28 mm |
| Rear brakes | Disc, 290×12 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R17 99V; 205/55 R19 97V; 245/40 R20 99V |
| Wheel rims size | 17; 19; 20 |
| What is the body type, DS 4 II? | Crossover, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, DS 4 II 1.6 PureTech (225 Hp) E-TENSE Automatic? | 1.3-1.4 l/100 km 180.9 – 168 US mpg 217.3 – 201.8 UK mpg 76.9 – 71.4 km/l |
| How ECO is the car, DS 4 1.6 PureTech (225 Hp) E-TENSE Automatic? | 29-32 g/km CO2 Euro 6.3 |
| What is the range of pure electric driving, 1.6 PureTech (225 Hp) E-TENSE Automatic? | 52-55 km 32.31 – 34.18 mi |
| What is electricity consumption, DS 4 II 1.6 PureTech (225 Hp) E-TENSE Automatic? | 14.6-15.2 kWh/100 km 23.5 – 24.46 kWh/100 mi 143 – 138 MPGe 6.8 – 6.6 km/kWh 4.3 – 4.1 mi/kWh |
| How fast is the car, 2021 4 II 1.6 PureTech (225 Hp) E-TENSE Automatic? | 233 km/h | 144.78 mph 0-100 km/h: 7.7 sec 0-60 mph: 7.3 sec |
| How much power, DS 4 Crossover 2021 1.6 PureTech (225 Hp) E-TENSE Automatic? | 225 Hp, 360 Nm 265.52 lb.-ft. |
| What is the engine size, DS 4 Crossover 2021 1.6 PureTech (225 Hp) E-TENSE Automatic? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2021 DS 1.6 PureTech (225 Hp) E-TENSE Automatic? | 4, Inline |
| What is the drivetrain, DS 4 II Crossover 2021 1.6 PureTech (225 Hp) E-TENSE Automatic? | Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2021 DS 4 Crossover? | 4400 mm 173.23 in. |
| How wide is the vehicle, 2021 DS 4 Crossover? | 1866 mm 73.46 in. |
| What is the curb weight, 2021 DS 4 II 1.6 PureTech (225 Hp) E-TENSE Automatic? | 1653 kg 3644.24 lbs. |
| What is the gross weight, 2021 DS 4 II 1.6 PureTech (225 Hp) E-TENSE Automatic? | 2200 kg 4850.17 lbs. |
| How much trunk (boot) space, 2021 DS 4 Crossover? | 390 – 1190 l 13.77 – 42.02 cu. ft. |
| How many gears, What type is the gearbox, 2021 DS 4 II 1.6 PureTech (225 Hp) E-TENSE Automatic? | 8, automatic transmission |
