| General information | |
|---|---|
| Brand | DS |
| Model | 9 |
| Generation | 9 |
| Type (Engine) | 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8 |
| Start of production | November, 2020 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 1.8 l/100 km 130.7 US mpg 156.9 UK mpg 55.6 km/l |
| CO2 emissions (WLTP) | 41 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 5.6 sec |
| Acceleration 0 – 62 mph | 5.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 5.3 sec |
| Maximum speed | 250 km/h, Electronically limited 155.34 mph |
| Emission standard | Euro 6d-ISC-FCM |
| Weight-to-power ratio | 5.3 kg/Hp, 188.6 Hp/tonne |
| Weight-to-torque ratio | 3.7 kg/Nm, 272.4 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 11.9 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the rear seats |
| All-electric range (WLTP) | 51 km 31.69 mi |
| Average Energy consumption (WLTP) | 15.5 kWh/100 km
24.94 kWh/100 mi |
| Max speed (electric) | 190 km/h
118.06 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 110 Hp |
| Electric motor Torque | 320 Nm
236.02 lb.-ft. |
| Electric motor location | Between the combustion engine and the transmission |
| Electric motor 2 | |
| Electric motor power | 113 Hp |
| Electric motor Torque | 166 Nm
122.44 lb.-ft. |
| Electric motor location | Rear axle, Transverse |
| System power | 360 Hp |
| System torque | 520 Nm 383.53 lb.-ft. |
| Internal combustion engine specs | |
| Power | 200 Hp @ 6000 rpm. |
| Power per litre | 125.2 Hp/l |
| Torque | 300 Nm @ 3000 rpm. 221.27 lb.-ft. @ 3000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | DGS EP6FADTXHPR |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 77 mm 3.03 in. |
| Piston Stroke | 86 mm 3.39 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.25 l 4.49 US qt | 3.74 UK qt |
| Engine oil specification | Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1909 kg 4208.62 lbs. |
| Max. weight | 2395 kg 5280.07 lbs. |
| Max load | 486 kg 1071.45 lbs. |
| Trunk (boot) space – minimum | 510 l 18.01 cu. ft. |
| Fuel tank capacity | 42 l 11.1 US gal | 9.24 UK gal |
| Dimensions | |
| Length | 4934 mm 194.25 in. |
| Width | 1855 mm 73.03 in. |
| Width with mirrors folded | 1932 mm 76.06 in. |
| Width including mirrors | 2079 mm 81.85 in. |
| Height | 1460 mm 57.48 in. |
| Wheelbase | 2895 mm 113.98 in. |
| Front track | 1584 mm 62.36 in. |
| Rear (Back) track | 1566 mm 61.65 in. |
| Front overhang | 973 mm 38.31 in. |
| Rear overhang | 1066 mm 41.97 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission EAT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 380×32 mm |
| Rear brakes | Disc, 290×12 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/45 R19; 235/40 R20 |
| Wheel rims size | 19; 20 |
| What is the body type, DS 9? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, DS 9 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 1.8 l/100 km 130.7 US mpg 156.9 UK mpg 55.6 km/l |
| How ECO is the car, DS 9 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 41 g/km CO2 Euro 6d-ISC-FCM |
| What is the range of pure electric driving, 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 51 km 31.69 mi |
| What is electricity consumption, DS 9 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 15.5 kWh/100 km 24.94 kWh/100 mi 135 MPGe 6.5 km/kWh 4 mi/kWh |
| How fast is the car, 2020 9 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 250 km/h | 155.34 mph 0-100 km/h: 5.6 sec 0-60 mph: 5.3 sec |
| How much power, DS 9 Sedan 2020 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 360 Hp, 520 Nm 383.53 lb.-ft. |
| What is the engine size, DS 9 Sedan 2020 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2020 DS 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 4, Inline |
| What is the drivetrain, DS 9 Sedan 2020 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode. |
| How long is this vehicle, 2020 DS 9 Sedan? | 4934 mm 194.25 in. |
| How wide is the vehicle, 2020 DS 9 Sedan? | 1855 mm 73.03 in. |
| What is the curb weight, 2020 DS 9 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 1909 kg 4208.62 lbs. |
| What is the gross weight, 2020 DS 9 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 2395 kg 5280.07 lbs. |
| How much trunk (boot) space, 2020 DS 9 Sedan? | 510 l 18.01 cu. ft. |
| How many gears, What type is the gearbox, 2020 DS 9 1.6 PureTech (360 Hp) E-TENSE 4×4 EAT8? | 8, automatic transmission EAT |
