| General information | |
|---|---|
| Brand | Fangchengbao |
| Model | Leopard 5 |
| Generation | Leopard 5 |
| Type (Engine) | DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT |
| Start of production | November, 2023 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – combined (WLTC) | 1.79-8.85 l/100 km 131.4 – 26.6 US mpg 157.8 – 31.9 UK mpg 55.9 – 11.3 km/l |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 4.8 sec |
| Acceleration 0 – 62 mph | 4.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 4.6 sec |
| Maximum speed | 180 km/h 111.85 mph |
| Weight-to-power ratio | 4.2 kg/Hp, 237.7 Hp/tonne |
| Weight-to-torque ratio | 3.8 kg/Nm, 263 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 31.8 kWh |
| Battery technology | Lithium iron phosphate (LiFePO4) |
| Battery location | Below the floor |
| All-electric range | 100-125 km 62.14 – 77.67 mi |
| Average Energy consumption | 23.5-24 kWh/100 km
37.82 – 38.62 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 388 Hp |
| Electric motor Torque | 400 Nm
295.02 lb.-ft. |
| Electric motor model/code | TZ200XYA |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 272 Hp |
| Electric motor Torque | 360 Nm
265.52 lb.-ft. |
| Electric motor model/code | TZ220XYAB |
| Electric motor location | Front axle, Longitudinal |
| Electric motor type | Synchronous |
| System power | 687 Hp |
| System torque | 760 Nm 560.55 lb.-ft. |
| Internal combustion engine specs | |
| Power | 194 Hp |
| Power per litre | 129.6 Hp/l |
| Torque | 273 Nm 201.35 lb.-ft. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | BYD476ZQF |
| Engine displacement | 1497 cm3 91.35 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2890-2998 kg 6371.36 – 6609.46 lbs. |
| Max. weight | 3265-3373 kg 7198.09 – 7436.19 lbs. |
| Max load | 375 kg 826.73 lbs. |
| Fuel tank capacity | 83 l 21.93 US gal | 18.26 UK gal |
| Permitted trailer load with brakes (12%) | 2500 kg 5511.56 lbs. |
| Dimensions | |
| Length | 4890 mm 192.52 in. |
| Width | 1970 mm 77.56 in. |
| Height | 1920 mm 75.59 in. |
| Wheelbase | 2800 mm 110.24 in. |
| Front track | 1660 mm 65.35 in. |
| Rear (Back) track | 1660 mm 65.35 in. |
| Ride height (ground clearance) | 220-310 mm 8.66 – 12.2 in. |
| Approach angle | 35-39° |
| Departure angle | 32-35° |
| Ramp-over (brakeover) angle | 20° |
| Climb angle | 45° |
| Wading depth | 700-790 mm 27.56 – 31.1 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | automatic transmission E-CVT |
| Front suspension | Double wishbone |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 265/65 R18; 275/55 R20 |
| Wheel rims size | 18; 20 |
| What is the body type, Fangchengbao Leopard 5? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Fangchengbao Leopard 5 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 1.79-8.85 l/100 km 131.4 – 26.6 US mpg 157.8 – 31.9 UK mpg 55.9 – 11.3 km/l |
| What is the range of pure electric driving, DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 100-125 km 62.14 – 77.67 mi |
| What is electricity consumption, Fangchengbao Leopard 5 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 23.5-24 kWh/100 km 37.82 – 38.62 kWh/100 mi 89 – 87 MPGe 4.3 – 4.2 km/kWh 2.6 – 2.6 mi/kWh |
| How fast is the car, 2023 Leopard 5 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 180 km/h | 111.85 mph 0-100 km/h: 4.8 sec 0-60 mph: 4.6 sec |
| How much power, Fangchengbao Leopard 5 SUV 2023 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 687 Hp, 760 Nm 560.55 lb.-ft. |
| What is the engine size, Fangchengbao Leopard 5 SUV 2023 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 1.5 l 1497 cm3 91.35 cu. in. |
| How many cylinders, 2023 Fangchengbao DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 4, Inline |
| What is the drivetrain, Fangchengbao Leopard 5 SUV 2023 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode. |
| How long is this vehicle, 2023 Fangchengbao Leopard 5 SUV? | 4890 mm 192.52 in. |
| How wide is the vehicle, 2023 Fangchengbao Leopard 5 SUV? | 1970 mm 77.56 in. |
| What is the curb weight, 2023 Fangchengbao Leopard 5 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 2890-2998 kg 6371.36 – 6609.46 lbs. |
| What is the gross weight, 2023 Fangchengbao Leopard 5 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | 3265-3373 kg 7198.09 – 7436.19 lbs. |
| How many gears, What type is the gearbox, 2023 Fangchengbao Leopard 5 DMO 1.5T 31.8 kWh (687 Hp) Plug-in Hybrid 4WD E-CVT? | automatic transmission E-CVT |
