| General information | |
|---|---|
| Brand | Fiat |
| Model | 500 |
| Generation | 500e (312) |
| Type (Engine) | 24 kWh (113 Hp) Electric |
| Start of production | 2013 year |
| End of production | 2019 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Hatchback |
| Seats | 4 |
| Doors | 3 |
| Performance specs | |
| Fuel Type | Electricity |
| Maximum speed | 142 km/h 88.23 mph |
| Weight-to-power ratio | 12 kg/Hp, 83.6 Hp/tonne |
| Weight-to-torque ratio | 6.8 kg/Nm, 147.2 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 24 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor, between front and rear seats |
| All-electric range | 135.2 km 84.01 mi |
| Average Energy consumption | 18.7 kWh/100 km
30.09 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 113 Hp |
| Electric motor Torque | 199 Nm
146.77 lb.-ft. |
| Electric motor location | Front, Transverse |
| System power | 113 Hp |
| System torque | 199 Nm 146.77 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1352 kg 2980.65 lbs. |
| Trunk (boot) space – minimum | 198 l 6.99 cu. ft. |
| Dimensions | |
| Length | 3617 mm 142.4 in. |
| Width | 1628 mm 64.09 in. |
| Height | 1527 mm 60.12 in. |
| Wheelbase | 2301 mm 90.59 in. |
| Front track | 1407 mm 55.39 in. |
| Rear (Back) track | 1397 mm 55 in. |
| Ride height (ground clearance) | 114 mm 4.49 in. |
| Drag coefficient (Cd) | 0.311 |
| Minimum turning circle (turning diameter) | 9.5 m 31.17 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Spring Strut, Rigid axle suspension, Coil spring |
| Front brakes | Ventilated discs, 279.4×22.1 mm |
| Rear brakes | Disc, 238.76×10.16 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 185/55 R15 Rear wheel tires: 185/55 R15 |
| Wheel rims size | Front wheel rims: 5.5J x 15 Rear wheel rims: 6.5J x 15 |
| What is the body type, Fiat 500e (312)? | Hatchback, 3 Doors, 4 Seats |
|---|---|
| What is the range of pure electric driving, 24 kWh (113 Hp) Electric? | 135.2 km 84.01 mi |
| What is electricity consumption, Fiat 500e (312) 24 kWh (113 Hp) Electric? | 18.7 kWh/100 km 30.09 kWh/100 mi 112 MPGe 5.3 km/kWh 3.3 mi/kWh |
| How fast is the car, 2013 500e (312) 24 kWh (113 Hp) Electric? | 142 km/h | 88.23 mph |
| How much power, Fiat 500 Hatchback 2013 24 kWh (113 Hp) Electric? | 113 Hp, 199 Nm 146.77 lb.-ft. |
| What is the drivetrain, Fiat 500e (312) Hatchback 2013 24 kWh (113 Hp) Electric? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2013 Fiat 500 Hatchback? | 3617 mm 142.4 in. |
| How wide is the vehicle, 2013 Fiat 500 Hatchback? | 1628 mm 64.09 in. |
| What is the curb weight, 2013 Fiat 500e (312) 24 kWh (113 Hp) Electric? | 1352 kg 2980.65 lbs. |
| How much trunk (boot) space, 2013 Fiat 500 Hatchback? | 198 l 6.99 cu. ft. |
| How many gears, What type is the gearbox, 2013 Fiat 500e (312) 24 kWh (113 Hp) Electric? | 1, automatic transmission |
