| General information | |
|---|---|
| Brand | Fiat |
| Model | 500L |
| Generation | 500L |
| Type (Engine) | 0.9 TwinAir (105 Hp) Turbo |
| Start of production | 2012 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 5.7 l/100 km 41.3 US mpg 49.6 UK mpg 17.5 km/l |
| Fuel consumption (economy) – extra urban | 4.3 l/100 km 54.7 US mpg 65.7 UK mpg 23.3 km/l |
| Fuel consumption (economy) – combined | 4.8 l/100 km 49 US mpg 58.9 UK mpg 20.8 km/l |
| CO2 emissions | 112 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 12.3 sec |
| Acceleration 0 – 62 mph | 12.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.7 sec |
| Maximum speed | 180 km/h 111.85 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 12 kg/Hp, 83.3 Hp/tonne |
| Weight-to-torque ratio | 8.7 kg/Nm, 115.1 Nm/tonne |
| Engine specs | |
| Power | 105 Hp @ 5500 rpm. |
| Power per litre | 120 Hp/l |
| Torque | 145 Nm @ 2000 rpm. 106.95 lb.-ft. @ 2000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 199B6000 |
| Engine displacement | 875 cm3 53.4 cu. in. |
| Number of cylinders | 2 |
| Engine configuration | Inline |
| Cylinder Bore | 80.5 mm 3.17 in. |
| Piston Stroke | 86 mm 3.39 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.3 l 3.49 US qt | 2.9 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.3 l 5.6 US qt | 4.66 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1260 kg 2777.82 lbs. |
| Trunk (boot) space – minimum | 412 l 14.55 cu. ft. |
| Trunk (boot) space – maximum | 1375 l 48.56 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Permitted trailer load with brakes (12%) | 1000 kg 2204.62 lbs. |
| Permitted trailer load without brakes | 400 kg 881.85 lbs. |
| Dimensions | |
| Length | 4147 mm 163.27 in. |
| Width | 1784 mm 70.24 in. |
| Height | 1665 mm 65.55 in. |
| Wheelbase | 2612 mm 102.83 in. |
| Front track | 1522 mm 59.92 in. |
| Rear (Back) track | 1519 mm 59.8 in. |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 195/65 R15; 205/55 R16; 225/45 R17 |
| Wheel rims size | 6J x 15; 6.5J x 16; 7J x 17 |
| What is the body type, Fiat 500L? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Fiat 500L 0.9 TwinAir (105 Hp) Turbo? | 4.8 l/100 km 49 US mpg 58.9 UK mpg 20.8 km/l |
| How ECO is the car, Fiat 500L 0.9 TwinAir (105 Hp) Turbo? | 112 g/km CO2 Euro 6 |
| How fast is the car, 2012 500L 0.9 TwinAir (105 Hp) Turbo? | 180 km/h | 111.85 mph 0-100 km/h: 12.3 sec 0-60 mph: 11.7 sec |
| How much power, Fiat 500L Hatchback 2012 0.9 TwinAir (105 Hp) Turbo? | 105 Hp, 145 Nm 106.95 lb.-ft. |
| What is the engine size, Fiat 500L Hatchback 2012 0.9 TwinAir (105 Hp) Turbo? | 0.9 l 875 cm3 53.4 cu. in. |
| How many cylinders, 2012 Fiat 0.9 TwinAir (105 Hp) Turbo? | 2, Inline |
| What is the drivetrain, Fiat 500L Hatchback 2012 0.9 TwinAir (105 Hp) Turbo? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2012 Fiat 500L Hatchback? | 4147 mm 163.27 in. |
| How wide is the vehicle, 2012 Fiat 500L Hatchback? | 1784 mm 70.24 in. |
| What is the curb weight, 2012 Fiat 500L 0.9 TwinAir (105 Hp) Turbo? | 1260 kg 2777.82 lbs. |
| How much trunk (boot) space, 2012 Fiat 500L Hatchback? | 412 – 1375 l 14.55 – 48.56 cu. ft. |
| How many gears, What type is the gearbox, 2012 Fiat 500L 0.9 TwinAir (105 Hp) Turbo? | 6, manual transmission |
