| General information | |
|---|---|
| Brand | Fiat |
| Model | Multipla |
| Generation | Multipla (186, facelift 2004) |
| Type (Engine) | 1.6 16V (103 Hp) |
| Start of production | 2004 year |
| End of production | 2010 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | MPV |
| Seats | 6 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.1 l/100 km 21.2 US mpg 25.4 UK mpg 9 km/l |
| Fuel consumption (economy) – extra urban | 7.2 l/100 km 32.7 US mpg 39.2 UK mpg 13.9 km/l |
| Fuel consumption (economy) – combined | 8.6 l/100 km 27.4 US mpg 32.8 UK mpg 11.6 km/l |
| CO2 emissions | 204 g/km |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 171 km/h 106.25 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 12.6 kg/Hp, 79.2 Hp/tonne |
| Weight-to-torque ratio | 9 kg/Nm, 111.5 Nm/tonne |
| Engine specs | |
| Power | 103 Hp @ 5750 rpm. |
| Power per litre | 64.5 Hp/l |
| Torque | 145 Nm @ 4000 rpm. 106.95 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 182B6000 |
| Engine displacement | 1596 cm3 97.39 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 80.5 mm 3.17 in. |
| Piston Stroke | 78.4 mm 3.09 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 3.8 l 4.02 US qt | 3.34 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7 l 7.4 US qt | 6.16 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1300 kg 2866.01 lbs. |
| Trunk (boot) space – minimum | 430 l 15.19 cu. ft. |
| Trunk (boot) space – maximum | 1900 l 67.1 cu. ft. |
| Fuel tank capacity | 63 l 16.64 US gal | 13.86 UK gal |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 560 kg 1234.59 lbs. |
| Dimensions | |
| Length | 4090 mm 161.02 in. |
| Width | 1870 mm 73.62 in. |
| Height | 1690 mm 66.54 in. |
| Wheelbase | 2666 mm 104.96 in. |
| Front track | 1515 mm 59.65 in. |
| Rear (Back) track | 1520 mm 59.84 in. |
| Front overhang | 837 mm 32.95 in. |
| Rear overhang | 586 mm 23.07 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Leaf spring |
| Front brakes | Ventilated discs, 284 mm |
| Rear brakes | Drum, 228 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 185/65 R15 |
| Wheel rims size | 15 |
| What is the body type, Fiat Multipla (186, facelift 2004)? | MPV, 5 Doors, 6 Seats |
|---|---|
| What is the fuel economy, Fiat Multipla (186, facelift 2004) 1.6 16V (103 Hp)? | 8.6 l/100 km 27.4 US mpg 32.8 UK mpg 11.6 km/l |
| How ECO is the car, Fiat Multipla 1.6 16V (103 Hp)? | 204 g/km CO2 Euro 4 |
| How fast is the car, 2004 Multipla (186, facelift 2004) 1.6 16V (103 Hp)? | 171 km/h | 106.25 mph |
| How much power, Fiat Multipla MPV 2004 1.6 16V (103 Hp)? | 103 Hp, 145 Nm 106.95 lb.-ft. |
| What is the engine size, Fiat Multipla MPV 2004 1.6 16V (103 Hp)? | 1.6 l 1596 cm3 97.39 cu. in. |
| How many cylinders, 2004 Fiat 1.6 16V (103 Hp)? | 4, Inline |
| What is the drivetrain, Fiat Multipla (186, facelift 2004) MPV 2004 1.6 16V (103 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2004 Fiat Multipla MPV? | 4090 mm 161.02 in. |
| How wide is the vehicle, 2004 Fiat Multipla MPV? | 1870 mm 73.62 in. |
| What is the curb weight, 2004 Fiat Multipla (186, facelift 2004) 1.6 16V (103 Hp)? | 1300 kg 2866.01 lbs. |
| How much trunk (boot) space, 2004 Fiat Multipla MPV? | 430 – 1900 l 15.19 – 67.1 cu. ft. |
| How many gears, What type is the gearbox, 2004 Fiat Multipla (186, facelift 2004) 1.6 16V (103 Hp)? | 5, manual transmission |
