| General information | |
|---|---|
| Brand | Fiat |
| Model | Panda |
| Generation | Panda II (169) |
| Type (Engine) | 1.2 8V (69 Hp) DYNAMIC |
| Start of production | 2003 year |
| End of production | 2012 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 6.4 l/100 km 36.8 US mpg 44.1 UK mpg 15.6 km/l |
| Fuel consumption (economy) – extra urban | 4 l/100 km 58.8 US mpg 70.6 UK mpg 25 km/l |
| Fuel consumption (economy) – combined | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 13.4 sec |
| Acceleration 0 – 62 mph | 13.4 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 12.7 sec |
| Maximum speed | 162 km/h 100.66 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 12.5 kg/Hp, 80.2 Hp/tonne |
| Weight-to-torque ratio | 8.4 kg/Nm, 118.6 Nm/tonne |
| Engine specs | |
| Power | 69 Hp @ 5500 rpm. |
| Power per litre | 55.6 Hp/l |
| Torque | 102 Nm @ 3000 rpm. 75.23 lb.-ft. @ 3000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 169A4000 |
| Engine displacement | 1242 cm3 75.79 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 2.8 l 2.96 US qt | 2.46 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 4.6 l 4.86 US qt | 4.05 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 860 kg 1895.98 lbs. |
| Max. weight | 1275 kg 2810.89 lbs. |
| Max load | 415 kg 914.92 lbs. |
| Trunk (boot) space – minimum | 206 l 7.27 cu. ft. |
| Trunk (boot) space – maximum | 775 l 27.37 cu. ft. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Dimensions | |
| Length | 3538 mm 139.29 in. |
| Width | 1578 mm 62.13 in. |
| Height | 1550 mm 61.02 in. |
| Wheelbase | 2299 mm 90.51 in. |
| Front track | 1366 mm 53.78 in. |
| Rear (Back) track | 1357 mm 53.43 in. |
| Minimum turning circle (turning diameter) | 9.1 m 29.86 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Semi-dependent beam with stabilizer lateral stability |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 155/80R13 |
| Wheel rims size | 13 |
| What is the body type, Fiat Panda II (169)? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Fiat Panda II (169) 1.2 8V (69 Hp) DYNAMIC? | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| How ECO is the car, Fiat Panda 1.2 8V (69 Hp) DYNAMIC? | Euro 5 |
| How fast is the car, 2003 Panda II (169) 1.2 8V (69 Hp) DYNAMIC? | 162 km/h | 100.66 mph 0-100 km/h: 13.4 sec 0-60 mph: 12.7 sec |
| How much power, Fiat Panda Hatchback 2003 1.2 8V (69 Hp) DYNAMIC? | 69 Hp, 102 Nm 75.23 lb.-ft. |
| What is the engine size, Fiat Panda Hatchback 2003 1.2 8V (69 Hp) DYNAMIC? | 1.2 l 1242 cm3 75.79 cu. in. |
| How many cylinders, 2003 Fiat 1.2 8V (69 Hp) DYNAMIC? | 4, Inline |
| What is the drivetrain, Fiat Panda II (169) Hatchback 2003 1.2 8V (69 Hp) DYNAMIC? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2003 Fiat Panda Hatchback? | 3538 mm 139.29 in. |
| How wide is the vehicle, 2003 Fiat Panda Hatchback? | 1578 mm 62.13 in. |
| What is the curb weight, 2003 Fiat Panda II (169) 1.2 8V (69 Hp) DYNAMIC? | 860 kg 1895.98 lbs. |
| What is the gross weight, 2003 Fiat Panda II (169) 1.2 8V (69 Hp) DYNAMIC? | 1275 kg 2810.89 lbs. |
| How much trunk (boot) space, 2003 Fiat Panda Hatchback? | 206 – 775 l 7.27 – 27.37 cu. ft. |
| How many gears, What type is the gearbox, 2003 Fiat Panda II (169) 1.2 8V (69 Hp) DYNAMIC? | 5, manual transmission |
