Technical Specifications
| Brand | Fiat |
| Model | Punto |
| Generation | Punto II (188, facelift 2003) 3dr |
| Type (Engine) | 1.2 (60 Hp) |
| Start of production | 2003 |
| End of production | 2007 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 3 |
| Fuel consumption (urban) | 7.3 l/100 km (32.2 US mpg, 38.7 UK mpg, 13.7 km/l) |
| Fuel consumption (extra urban) | 4.8 l/100 km (49 US mpg, 58.9 UK mpg, 20.8 km/l) |
| Fuel consumption (combined) | 5.7 l/100 km (41.3 US mpg, 49.6 UK mpg, 17.5 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 14.3 sec |
| Acceleration 0 – 62 mph | 14.3 sec |
| Acceleration 0 – 60 mph | 13.6 sec |
| Maximum speed | 155 km/h (96.31 mph) |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 14.5 kg/Hp, 69 Hp/tonne |
| Weight-to-torque ratio | 8.5 kg/Nm, 117.2 Nm/tonne |
| Power | 60 Hp @ 5000 rpm |
| Power per litre | 48.3 Hp/l |
| Torque | 102 Nm @ 2500 rpm (75.23 lb.-ft. @ 2500 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | 188A4000 |
| Engine displacement | 1242 cm3 (75.79 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 70.8 mm (2.79 in.) |
| Piston Stroke | 78.9 mm (3.11 in.) |
| Compression ratio | 9.8:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 2.8 l (2.96 US qt | 2.46 UK qt) |
| Coolant | 4.2 l (4.44 US qt | 3.7 UK qt) |
| Kerb Weight | 870 kg (1918.02 lbs.) |
| Max. weight | 1380 kg (3042.38 lbs.) |
| Max load | 510 kg (1124.36 lbs.) |
| Trunk (boot) space – minimum | 264 l (9.32 cu. ft.) |
| Trunk (boot) space – maximum | 1080 l (38.14 cu. ft.) |
| Fuel tank capacity | 47 l (12.42 US gal | 10.34 UK gal) |
| Length | 3840 mm (151.18 in.) |
| Width | 1660 mm (65.35 in.) |
| Height | 1480 mm (58.27 in.) |
| Wheelbase | 2460 mm (96.85 in.) |
| Front track | 1398 mm (55.04 in.) |
| Rear (Back) track | 1392 mm (54.8 in.) |
| Drag coefficient (Cd) | 0.32 |
| Minimum turning circle | 10.5 m (34.45 ft.) |
| Drivetrain Architecture | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Torsion |
| Front brakes | Disc |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 165/70 R14 |
The 3-door Fiat Punto II 1.2, produced from 2003-2007, was a popular choice for first-time car buyers, city dwellers, and those seeking an economical and practical vehicle. It sat at the entry-level of the Punto II range, offering a more affordable alternative to the higher-specification 1.4-liter and sporting Abarth models. The facelifted Punto II (the ‘188’ series) brought subtle styling updates and improvements to interior quality compared to the pre-2003 models. This particular variant was primarily sold in Europe, where the demand for small, fuel-efficient hatchbacks was – and remains – high. It was designed to compete with vehicles like the Renault Clio, Peugeot 206, and Volkswagen Polo.
Powertrain & Engine Architecture
The heart of this Punto variant is the Fiat 188A4000 1.2-liter inline-four cylinder engine. This engine, a staple of Fiat’s small car lineup for many years, is a naturally aspirated, single overhead camshaft (SOHC) design with two valves per cylinder. It utilizes a multi-point fuel injection system, delivering fuel directly to the intake ports. The engine’s relatively simple design prioritized reliability and ease of maintenance over outright performance. The 1.2-liter engine produces 60 horsepower at 5000 rpm and 102 Nm (75.23 lb-ft) of torque at 2500 rpm. The engine is transversely mounted, driving the front wheels. Paired with the engine is a five-speed manual transmission, chosen for its affordability and efficiency. While an automated manual transmission (Dualogic) was available on some Punto II models, it was not offered with the 1.2-liter 60 hp engine.
Driving Characteristics
The 1.2-liter Punto II 3-door is not known for its blistering acceleration. With a 0-60 mph time of around 13.6 seconds and a top speed of 155 km/h (96.31 mph), it’s geared towards practicality rather than performance. The five-speed gearbox is well-matched to the engine, but requires frequent shifting to maintain momentum, especially when overtaking or climbing hills. The gear ratios are relatively tall, prioritizing fuel economy over responsiveness. Compared to the 1.4-liter Punto II, the 1.2 feels noticeably slower, particularly in the mid-range. However, the lighter engine weight contributes to nimble handling in urban environments. The steering is light and easy, making it ideal for navigating tight city streets.
Equipment & Trim Levels
The base-level 1.2-liter Punto II 3-door was typically equipped with basic, but functional, features. Standard equipment generally included power steering, central locking, front airbags, and an adjustable steering column. Interior upholstery was typically a durable cloth material. Optional extras included air conditioning, electric front windows, and a radio/CD player. Higher trim levels, such as the Active or Dynamic, added features like alloy wheels, body-colored bumpers, and upgraded interior trim. The 3-door configuration itself was a cost-saving measure, appealing to buyers who didn’t require the practicality of rear doors.
Chassis & Braking
The Punto II utilizes a relatively simple chassis design. The front suspension consists of MacPherson struts, while the rear suspension employs a torsion beam. This setup provides a comfortable ride quality, although it’s not particularly sporty. The front brakes are ventilated discs, providing adequate stopping power, while the rear brakes are drums. ABS (Anti-lock Braking System) was standard equipment, enhancing safety. The Punto II’s relatively lightweight construction (870 kg / 1918 lbs) helps to offset the modest engine output, contributing to reasonable handling and braking performance.
Market Reception & Comparison
The 1.2-liter Punto II 3-door was generally well-received as an affordable and economical city car. Critics praised its fuel efficiency and practicality, but noted its lack of performance. Compared to the 1.4-liter Punto II, the 1.2 offered significantly lower running costs but at the expense of driving enjoyment. The 1.4-liter provided a noticeable boost in power and torque, making it a more versatile option for those who frequently drove on highways or carried passengers. In terms of reliability, the 1.2-liter engine proved to be generally robust, although regular maintenance was essential. Fuel economy figures of around 41.3 US mpg combined were competitive for its class.
Legacy
The Fiat Punto II 1.2 60 hp remains a common sight on European roads today, testament to its durability and affordability. In the used car market, these models are typically very inexpensive to purchase, making them attractive to budget-conscious buyers. While not a performance icon, the 1.2-liter Punto II served as a reliable and practical mode of transportation for many years. The engine, while simple, is relatively easy to repair and maintain, and spare parts are readily available. Its enduring presence highlights its success as a value-oriented small car.
