| General information | |
|---|---|
| Brand | Fiat |
| Model | Scudo |
| Generation | Scudo III (facelift 2023) Panel Van |
| Type (Engine) | 1.5 Multijet (120 Hp) L2 |
| Start of production | November, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 2-3 |
| Doors | 4-5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 6.6 l/100 km 35.6 US mpg 42.8 UK mpg 15.2 km/l |
| CO2 emissions (WLTP) | 172 g/km |
| Fuel Type | Diesel |
| Emission standard | Euro 6d-Final |
| Engine specs | |
| Power | 120 Hp @ 3750 rpm. |
| Power per litre | 80.1 Hp/l |
| Torque | 300 Nm @ 1750 rpm. 221.27 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | DV5RUC |
| Engine displacement | 1499 cm3 91.47 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 84.8 mm 3.34 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.75 l 6.08 US qt | 5.06 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Trunk (boot) space – minimum | 5300 l 187.17 cu. ft. |
| Trunk (boot) space – maximum | 5800 l 204.83 cu. ft. |
| Fuel tank capacity | 69 l 18.23 US gal | 15.18 UK gal |
| AdBlue tank | 22.4 l 5.92 US gal | 4.93 UK gal |
| Dimensions | |
| Length | 4983 mm 196.18 in. |
| Width | 1920 mm 75.59 in. |
| Width including mirrors | 2204 mm 86.77 in. |
| Height | 1895 mm 74.61 in. |
| Wheelbase | 3275 mm 128.94 in. |
| Front track | 1627 mm 64.06 in. |
| Rear (Back) track | 1600 mm 62.99 in. |
| Front overhang | 904 mm 35.59 in. |
| Rear overhang | 803 mm 31.61 in. |
| Ride height (ground clearance) | 150 mm 5.91 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Trailing arm |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R16; 215/60 R17 |
| Wheel rims size | 16; 17 |
| What is the body type, Fiat Scudo III (facelift 2023) Panel Van? | Van, 4-5 Doors, 2-3 Seats |
|---|---|
| What is the fuel economy, Fiat Scudo III (facelift 2023) Panel Van 1.5 Multijet (120 Hp) L2? | 6.6 l/100 km 35.6 US mpg 42.8 UK mpg 15.2 km/l |
| How ECO is the car, Fiat Scudo 1.5 Multijet (120 Hp) L2? | 172 g/km CO2 Euro 6d-Final |
| How much power, Fiat Scudo Van 2023 1.5 Multijet (120 Hp) L2? | 120 Hp, 300 Nm 221.27 lb.-ft. |
| What is the engine size, Fiat Scudo Van 2023 1.5 Multijet (120 Hp) L2? | 1.5 l 1499 cm3 91.47 cu. in. |
| How many cylinders, 2023 Fiat 1.5 Multijet (120 Hp) L2? | 4, Inline |
| What is the drivetrain, Fiat Scudo III (facelift 2023) Panel Van Van 2023 1.5 Multijet (120 Hp) L2? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2023 Fiat Scudo Van? | 4983 mm 196.18 in. |
| How wide is the vehicle, 2023 Fiat Scudo Van? | 1920 mm 75.59 in. |
| How much trunk (boot) space, 2023 Fiat Scudo Van? | 5300 – 5800 l 187.17 – 204.83 cu. ft. |
| How many gears, What type is the gearbox, 2023 Fiat Scudo III (facelift 2023) Panel Van 1.5 Multijet (120 Hp) L2? | 6, manual transmission |
