| General information | |
|---|---|
| Brand | Fiat |
| Model | Siena |
| Generation | Siena (178) |
| Type (Engine) | 1.7 TD (72 Hp) |
| Start of production | 1996 year |
| End of production | 2000 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 14.8 sec |
| Acceleration 0 – 62 mph | 14.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 14.1 sec |
| Maximum speed | 164 km/h 101.9 mph |
| Weight-to-power ratio | 14.8 kg/Hp, 67.6 Hp/tonne |
| Weight-to-torque ratio | 7.8 kg/Nm, 128.6 Nm/tonne |
| Engine specs | |
| Power | 72 Hp @ 4500 rpm. |
| Power per litre | 42.4 Hp/l |
| Torque | 137 Nm @ 2500 rpm. 101.05 lb.-ft. @ 2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 176 A5.000 |
| Engine displacement | 1698 cm3 103.62 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82.6 mm 3.25 in. |
| Piston Stroke | 79.2 mm 3.12 in. |
| Compression ratio | 20.3:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Precombustion chamber injection |
| Engine aspiration | Turbocharger |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.1 l 7.5 US qt | 6.25 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1065 kg 2347.92 lbs. |
| Trunk (boot) space – minimum | 500 l 17.66 cu. ft. |
| Trunk (boot) space – maximum | 850 l 30.02 cu. ft. |
| Fuel tank capacity | 48 l 12.68 US gal | 10.56 UK gal |
| Dimensions | |
| Length | 4100 mm 161.42 in. |
| Width | 1614 mm 63.54 in. |
| Height | 1440 mm 56.69 in. |
| Wheelbase | 2360 mm 92.91 in. |
| Front track | 1388 mm 54.65 in. |
| Rear (Back) track | 1378 mm 54.25 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
| Front brakes | Disc |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 175/70 R13 |
| What is the body type, Fiat Siena (178)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| How fast is the car, 1996 Siena (178) 1.7 TD (72 Hp)? | 164 km/h | 101.9 mph 0-100 km/h: 14.8 sec 0-60 mph: 14.1 sec |
| How much power, Fiat Siena Sedan 1996 1.7 TD (72 Hp)? | 72 Hp, 137 Nm 101.05 lb.-ft. |
| What is the engine size, Fiat Siena Sedan 1996 1.7 TD (72 Hp)? | 1.7 l 1698 cm3 103.62 cu. in. |
| How many cylinders, 1996 Fiat 1.7 TD (72 Hp)? | 4, Inline |
| What is the drivetrain, Fiat Siena (178) Sedan 1996 1.7 TD (72 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 1996 Fiat Siena Sedan? | 4100 mm 161.42 in. |
| How wide is the vehicle, 1996 Fiat Siena Sedan? | 1614 mm 63.54 in. |
| What is the curb weight, 1996 Fiat Siena (178) 1.7 TD (72 Hp)? | 1065 kg 2347.92 lbs. |
| How much trunk (boot) space, 1996 Fiat Siena Sedan? | 500 – 850 l 17.66 – 30.02 cu. ft. |
| How many gears, What type is the gearbox, 1996 Fiat Siena (178) 1.7 TD (72 Hp)? | 5, manual transmission |
